About the suite

drf-react-by-schema is a suite that builds headless Django + React applications directly from your models:

• drf-react-by-schema-django (PyPI) — generates the DRF API (serializers, viewsets, filters, schemas) from your models;

• drf-react-by-schema-react (npm) — consumes those schemas to build the React forms, grids and CRUD interfaces;

• drf-react-by-schema-oauth — OAuth 2.1 authorization/resource server that issues the tokens both the API and this MCP server accept;

• drf-react-by-schema-mcp (this package) — the generic MCP server that exposes the same API to MCP clients.

About this package

A DRBS project already exposes a rich DRF API generated from its models. This package mounts a FastMCP server that proxies that API to MCP clients, so an assistant can:

• understand the system before acting (knowledge) — the project’s endpoints, conventions and per-model field schemas, fetched from the base package’s GET /drbs/schema/;

• read any /api/... endpoint (consultar), count and sum filtered sets without downloading them (resumo) and identify the logged-in account (minha_conta);

• write — opt-in per project — with criar (POST) and editar (PATCH); DELETE is never exposed.

It is deliberately generic: the tool surface is bounded by a fixed set of generic tools plus any project shortcuts, not one tool per model. The same OAuth token authenticates /mcp and /api/..., and the project’s DRF permissions and OAuth scopes (read/write) remain the authority.

Compatibility

The base DRBS package supports Django ≥ 3.2, and some deployments are still on Django 3.2. This package therefore supports Django 3.2 through 5.x (and the 2.x django-oauth-toolkit line pulled in by drf-react-by-schema-oauth). It requires Python ≥ 3.10 (the mcp SDK).

Pre-requisites

• Django ≥ 3.2

• djangorestframework

• drf-react-by-schema-oauth (installed automatically) — provides the OAuth server and the DRF authentication/scopes

• mcp (installed automatically)

Quick start

1. Install:

   pip install drf-react-by-schema-mcp

2. Add the app (after the OAuth package) and include the URLs:

   INSTALLED_APPS = [
       ...
       'oauth2_provider',
       'drf_react_by_schema_oauth',
       'drf_react_by_schema_mcp',
   ]

   urlpatterns = [
       ...
       path('', include('drf_react_by_schema_oauth.urls')),
       path('', include('drf_react_by_schema_mcp.urls')),  # Protected Resource Metadata
   ]

3. Mount the MCP endpoint (see Mounting /mcp).

4. Configure (all keys optional):

   DRBS_MCP = {
       'WRITE': False,       # read-only by default
       'KNOWLEDGE': True,    # schema-aware knowledge() + write validation
       'RESOURCE_URL': '/mcp',
       'SHORTCUTS': [],      # dotted paths to project-specific tools
   }

Mounting /mcp

/mcp speaks the MCP streamable-http transport, a long-lived ASGI application (it cannot be served from a synchronous WSGI URLconf). There are two supported deployments:

• Combined — one ASGI process serves both Django and /mcp:

  # asgi.py
  from drf_react_by_schema_mcp.server import get_mcp_asgi_application

  application = get_mcp_asgi_application()

• Standalone — a second ASGI process serves only /mcp (point DRBS_MCP['API_URL'] at the Django host) and the reverse proxy routes /mcp to it:

  python -m drf_react_by_schema_mcp.server
  # or: uvicorn drf_react_by_schema_mcp.server:get_mcp_asgi_application --factory

In both cases the endpoint is protected: an unauthenticated request answers 401 with WWW-Authenticate: Bearer resource_metadata="…", so an MCP client can discover the OAuth server (RFC 9728) and start the flow automatically.

Connecting an MCP client

Point a remote MCP client at https://<host>/mcp with OAuth (no secret file):

"example": {
  "type": "remote",
  "url": "https://<host>/mcp",
  "enabled": true,
  "oauth": {}
}

With opencode that is opencode mcp auth example, followed by opencode mcp debug example.

Tools

The generic tools mirror the DRF API. List endpoints return the results list; detail/object endpoints return the object; metadados=True returns the full {count, next, previous, sum_rows, facets, results} envelope.

Accepted querystring parametros (combinable): page (100 rows/page), search (text), ordering (- for descending), sum_rows (comma-separated numeric fields), and the grid filter field / operator / value. The three filter keys may each be a list; items match positionally and combine with AND. Common operators: equals, contains, startsWith, endsWith, isAnyOf, is, not, after, before, onOrAfter, onOrBefore, entre ("start,end"), isEmpty, isNotEmpty. field accepts relation paths with __. Equality on a foreign key compares the related object’s label (__str__/nome/slug), not its id; to filter by id use field="<fk>__id" with operator="is".

sum_rows items may also carry facets: medida|dimensao[|dimensao...] [|limite] (|-separated). medida is a numeric field or count; each dimensao must be a foreign key, a field with choices or a boolean — and may be a nested forward relation with __ (e.g. categoria__regiao); a trailing all-digits part is the top-N limite (ordered by the measure). Each measure still reports its <medida>_total flat, and the grouped buckets come back under facets.

# one page of 2026 entries
consultar("/api/widget/",
          {"field": "publicado_em", "operator": "entre",
           "value": "2026-01-01,2026-12-31", "page": 1})

# count + sums for the whole filter, without the list
resumo("/api/widget/", ["preco", "peso"],
       {"field": "publicado_em", "operator": "entre",
        "value": "2026-01-01,2026-12-31"})

# nº de itens por categoria (e total de preço)
resumo("/api/widget/", ["preco", "count|categoria"])

# top-5 categorias por preço, tabela cruzada com tipo
resumo("/api/widget/", ["preco|categoria|5", "count|categoria|tipo"])

# nº de itens por região da categoria (relação aninhada)
resumo("/api/widget/", ["count|categoria__regiao"])

Schema awareness

Instead of guessing /api/<model>/ paths and field names, the assistant can ask the project what it looks like. knowledge reads the base package’s machine-readable schema endpoint, GET /drbs/schema/ (see drf-react-by-schema, the base package’s “Machine-readable schema” section), with the caller’s Bearer token:

• knowledge() — a compact overview: every top-level endpoint (modelo/model/app_label/caminho/tipo/verbose names), the API conventions (pagination, ordering/search/sum_rows, grid-filter operators), the schema stamp and the project’s about (the project root’s ABOUT.md, when present).

• knowledge(modelo="widget") — that model’s field schema (types, choices, required, read_only…, with related_model on each relation field), the valid sum_rows measures and dimensions (medidas/dimensoes) and the model class docstring. Field documentation travels inside the schema as each field’s description — distinct from help_text, which is the text the React UI shows the end user. Both are opt-in on the Django side (a model docstring, or description="..." passed to a schema field) and trimmed when served. The name is matched in any case/style, as the endpoint name, the underlying Django model name, or an /api/... path.

The bundle is schema-only: the React-only TypeScript artifacts (interface/enums) and the auto-generated nested *Related* viewsets are deliberately not shipped, so each relation field instead carries a related_model (query /api/<model>/ and constrain with the grid filter rather than navigating a nested route).

The bundle is fetched once per MCP process and cached in memory, keyed by its stamp: later calls send If-None-Match and a 304 Not Modified reuses the cache, while a changed schema (new stamp) transparently replaces it. Nothing is written to disk and the schema is never exposed as an MCP resource — it reaches the agent only as knowledge() output.

When the project exposes /drbs/schema/, criar/editar validate the payload against the same schema before sending it — required fields, read_only fields, value types and choice options — and return a field-level error without calling the API if it is invalid (e.g. "preco: campo obrigatório ausente."). A valid payload is forwarded unchanged.

If the project does not expose the endpoint (drf-react-by-schema < 0.27 or SCHEMA_ENDPOINT off), knowledge reports it as unavailable and writes are not validated — the server keeps working as a plain proxy.

Shortcuts

Register project-specific tools with dotted paths; each is a callable taking the MCP Context first (exactly like the generic tools) and is exposed under its own name:

DRBS_MCP = {
    "SHORTCUTS": ["myproject.mcp.saldo_ferias"],
    # optionally limit/rename the surface:
    "TOOLS": ["consultar", "resumo", {"ferias": "saldo_ferias"}],
}

Settings

DRBS_MCP is a single dict; every key is optional.

Security model

• Stateless proxy — no credentials are stored server-side; the caller’s Bearer token is forwarded to /api/... on every call.

• Read-only by default — writes require WRITE=True and a token carrying the write scope and the project’s DRF permissions.

• No ``DELETE`` — only GET/POST/PATCH are exposed.

• Schema is structure, not data — /drbs/schema/ carries the generated picture (models, fields, endpoints, static config) only: no row data and no secrets; it is fetched with the caller’s own token and the project’s existing auth.

• Scope enforcement is the project’s: read for safe methods, write for unsafe ones, via drf_react_by_schema_oauth.permissions.HasScope.

License

GPLv3 — Cooperativa EITA.
