Drinx: Dataclass Registry in JAX

Drinx: Dataclass Registry in JAX 🥂

Often it is useful to have structures in a program containing a mixture of JAX arrays and non-JAX types (e.g. strings, ...). But, this makes it difficult to pass these objects through JAX transformations. Drinx solves this by allowing dataclass fields to be declared as static. Moreover, drinx introduces numerous quality-of-life features when working with dataclasses in JAX.

Installation

You can install drinx simply via

pip install drinx

If you want to use the GPU-acceleration from JAX, you can install afterwards:

pip install jax[cuda]

Quickstart

Below you can find some examples to get you quickly started with drinx. But, beware, there are so much more features available, which are documented in detail in our Documentation

Decorator style

Use @drinx.dataclass as a drop-in replacement for @dataclasses.dataclass. The class is automatically frozen and registered as a JAX pytree:

import jax
import jax.numpy as jnp
import drinx

@drinx.dataclass
class Params:
    weights: jax.Array
    bias: jax.Array

params = Params(weights=jnp.ones((3,)), bias=jnp.zeros((3,)))

# Works transparently with JAX transforms
doubled = jax.tree_util.tree_map(lambda x: x * 2, params)

Static fields

Fields that should not be traced by JAX (e.g. shapes, dtypes, hyperparameters) are marked with static_field or field(static=True). Changing a static field triggers recompilation under jit:

@drinx.dataclass
class Model:
    weights: jax.Array
    hidden_size: int = drinx.static_field(default=128)

@jax.jit
def forward(model, x):
    # hidden_size is a compile-time constant; weights are traced
    return model.weights[:model.hidden_size] @ x

model = Model(weights=jnp.ones((128, 32)))

Inheritance style

Subclass DataClass instead of using the decorator. The transform is applied automatically — no @dataclass needed:

class Model(drinx.DataClass):
    weights: jax.Array
    learning_rate: float = drinx.static_field(default=1e-3)

model = Model(weights=jnp.ones((10,)))

Dataclass options are forwarded via the class definition, or alternatively by using a combination of inheritance and decorator.

class Config(drinx.DataClass, kw_only=True, order=True):
    hidden_size: int = drinx.static_field(default=128)
    num_layers: int = drinx.static_field(default=4)

# This is the recommended way: Typechecker will recognize the kw_only argument correctly
@drinx.dataclass(kw_only=True, order=True)
class Config(drinx.DataClass):
    hidden_size: int = drinx.static_field(default=128)
    num_layers: int = drinx.static_field(default=4)

Functional updates with aset

Because drinx dataclasses are frozen, fields cannot be mutated in place. aset performs a functional update and returns a new instance. It supports nested paths using -> as a separator, integer indices [n], and string dictionary keys ['k']. Note that this function is only available when inheriting the drinx.Dataclass, but not from the decorator.

class Inner(drinx.DataClass):
    w: jax.Array

class Outer(drinx.DataClass):
    inner: Inner
    bias: jax.Array

outer = Outer(inner=Inner(w=jnp.ones((3,))), bias=jnp.zeros((1,)))

# Update a top-level field
outer2 = outer.aset("bias", jnp.ones((1,)))

# Update a nested field
outer3 = outer.aset("inner->w", jnp.zeros((3,)))

JAX transforms

Drinx dataclasses work with all JAX transforms out of the box:

class State(drinx.DataClass):
    x: jax.Array
    step_size: float = drinx.static_field(default=0.1)

# jit
@jax.jit
def update(state):
    # updated_copy is convenience wrapper for altering top-level attributes
    return state.updated_copy(x=state.x - state.step_size)

def loss(state):
    return jnp.sum(state.x ** 2)

grads = jax.grad(loss)(State(x=jnp.array([1.0, 2.0, 3.0])))

@jax.vmap
def scale(state):
    return state.x * 2

batched = State(x=jnp.array([[1.0, 2.0], [3.0, 4.0]]))
result = scale(batched)  # shape (2, 2)

Visualization

tree_diagram and tree_summary let you inspect any JAX pytree at a glance:

class Encoder(drinx.DataClass):
    w: jax.Array
    b: jax.Array

class Model(drinx.DataClass):
    encoder: Encoder
    head: jax.Array

model = Model(encoder=Encoder(w=jnp.ones((16, 32)), b=jnp.zeros((16,))), head=jnp.ones((4, 16)))

print(drinx.tree_diagram(model))
# Model
# ├── .encoder:Encoder
# │   ├── .w=f32[16,32] ∈ [1.0, 1.0], μ=1.0, σ=0.0
# │   └── .b=f32[16] ∈ [0.0, 0.0], μ=0.0, σ=0.0
# └── .head=f32[4,16] ∈ [1.0, 1.0], μ=1.0, σ=0.0

print(drinx.tree_summary(model))
# ┌──────────────┬──────────┬───────┬────────┐
# │Name          │Type      │Count  │Size    │
# ├──────────────┼──────────┼───────┼────────┤
# │.encoder.w    │f32[16,32]│512    │2.00KB  │
# ├──────────────┼──────────┼───────┼────────┤
# │.encoder.b    │f32[16]   │16     │64.00B  │
# ├──────────────┼──────────┼───────┼────────┤
# │.head         │f32[4,16] │64     │256.00B │
# ├──────────────┼──────────┼───────┼────────┤
# │Σ             │Tree      │592    │2.31KB  │
# └──────────────┴──────────┴───────┴────────┘

Documentation

For more examples and a detailed documentation, check out the API here.

Comparison to Alternatives

There exist a number of other libraries, which also integrate dataclass functionality with JAX. The most similar libraries to drinx are jax_dataclass and pytreeclass, though pytreeclass is unfortunately no longer actively maintained. Other libraries that are not specifically focusing on dataclasses, but have some functionality for them included, are the chex.dataclass, flax.struct or tjax.dataclass.

The main differences between the libraries are:

• Static Fields:: drinx.field(static=True) or drinx.static_field() can be used to mark dataclass attributes as static. The pytreeclass and flax library support a similar system. jax_dataclass supports static fields through marking an attribute as Annotated[..., Static]. chex and tjax do not support static attributes.
• Attribute Updates: drinx implements the .at["attribute"].set() syntax for functional updates of top-level attributes and .aset() for updates of nested structures. The .at[].set() syntax is also supported by pytreeclass, which heavily inspired our implementation. tjax implements a context manager which allows for updates of frozen classes, but this is non-functional and makes the usage in jit transforms difficult. flax implements a .replace() function for changing top-level attributes, but not nested updates. chex only support updates through creating a new object.
• Static Type Checking: Both drinx and jax_dataclass are thin wrappers around the python dataclass and consequently have full type checking support. All other libraries have some limitations with regards for type checking, for example kw_only does not work in tjax or flax.
• Visualization: drinx implements some nice visualizations through drinx.tree_diagram and drinx.tree_summary which is heavily inspired by the pytreeclass library. Other libraries do not implement visualization tools out of the box.

Citation

TODO: add citation once published
