droidrun 0.1.0

A framework for controlling Android devices through LLM agents

🤖 DroidRun

DroidRun is a powerful framework for controlling Android devices through LLM agents. It allows you to automate Android device interactions using natural language commands.

✨ Features

• Control Android devices with natural language commands
• Supports multiple LLM providers (OpenAI, Anthropic, Gemini)
• Easy to use CLI
• Extendable Python API for custom automations
• Screenshot analysis for visual understanding of the device

📦 Installation

🚀 Option 1: Install from PyPI (Recommended)

pip install droidrun

🔧 Option 2: Install from Source

git clone https://github.com/yourusername/droidrun.git
cd droidrun
pip install -e .

📋 Prerequisites

1. An Android device connected via USB or ADB over TCP/IP
2. ADB (Android Debug Bridge) installed and configured
3. DroidRun Portal app installed on your Android device
4. API key for at least one of the supported LLM providers:
   • OpenAI
   • Anthropic
   • Google Gemini

🔧 Setting up ADB

ADB (Android Debug Bridge) is required for DroidRun to communicate with your Android device:

1. Install ADB:

   • Windows: Download Android SDK Platform Tools and extract the ZIP file
   • macOS: brew install android-platform-tools
   • Linux: sudo apt install adb (Ubuntu/Debian) or sudo pacman -S android-tools (Arch)

2. Add ADB to your PATH:

   • Windows: Add the path to the extracted platform-tools folder to your system's PATH environment variable
   • macOS/Linux: Add the following to your ~/.bashrc or ~/.zshrc:

     export PATH=$PATH:/path/to/platform-tools


3. Verify ADB installation:

   adb version


4. Enable USB debugging on your Android device:

   • Go to Settings → About phone
   • Tap Build number 7 times to enable Developer options
   • Go to Settings → System → Developer options (location may vary by device)
   • Enable USB debugging

🛠️ Setup

📱 1. Install DroidRun Portal App

DroidRun requires the DroidRun Portal app to be installed on your Android device:

1. Download the DroidRun Portal APK from the DroidRun Portal repository
2. Use DroidRun to install the portal app:

   droidrun setup --path=/path/to/droidrun-portal.apk


Alternatively, you can use ADB to install it manually:

adb install -r /path/to/droidrun-portal.apk

🔑 2. Set up API keys

Create a .env file in your working directory or set environment variables:

# Choose at least one of these based on your preferred provider
export OPENAI_API_KEY="your_openai_api_key_here"
export ANTHROPIC_API_KEY="your_anthropic_api_key_here"
export GEMINI_API_KEY="your_gemini_api_key_here"

To load the environment variables from the .env file:

source .env

📱 3. Connect to an Android device

Connect your device via USB or set up wireless ADB:

# List connected devices
droidrun devices

# Connect to a device over Wi-Fi
droidrun connect 192.168.1.100

🔄 4. Verify the setup

Verify that everything is set up correctly:

# Should list your connected device and show portal status
droidrun status

💻 Using the CLI

DroidRun's CLI is designed to be simple and intuitive. You can use it in two ways:

🚀 Basic Usage

# Format: droidrun "task description" [options]
droidrun "Open the settings app"

🔌 With Provider Options

# Using OpenAI
droidrun "Open the calculator app" --provider openai --model gpt-4o-mini

# Using Anthropic
droidrun "Check the battery level" --provider anthropic --model claude-3-sonnet-20240229

# Using Gemini
droidrun "Install and open Instagram" --provider gemini --model gemini-2.0-flash

⚙️ Additional Options

# Specify a particular device
droidrun "Open Chrome and search for weather" --device abc123

# Set maximum number of steps
droidrun "Open settings and enable dark mode" --steps 20

📝 Creating a Minimal Test Script

If you want to use DroidRun in your Python code rather than via the CLI, you can create a minimal test script:

#!/usr/bin/env python3
import asyncio
import os
from droidrun.agent.react_agent import ReActAgent
from droidrun.agent.llm_reasoning import LLMReasoner
from dotenv import load_dotenv

# Load environment variables from .env file
load_dotenv()

async def main():
    # Create an LLM instance (choose your preferred provider)
    llm = LLMReasoner(
        llm_provider="gemini",  # Can be "openai", "anthropic", or "gemini"
        model_name="gemini-2.0-flash",  # Choose appropriate model for your provider
        api_key=os.environ.get("GEMINI_API_KEY"),  # Get API key from environment
        temperature=0.2
    )

    # Create and run the agent
    agent = ReActAgent(
        task="Open the Settings app and check the Android version",
        llm=llm
    )

    steps = await agent.run()
    print(f"Execution completed with {len(steps)} steps")

if __name__ == "__main__":
    asyncio.run(main())

Save this as test_droidrun.py, ensure your .env file has the appropriate API key, and run:

python test_droidrun.py

❓ Troubleshooting

🔑 API Key Issues

If you encounter errors about missing API keys, ensure:

1. You've set the correct environment variable for your chosen provider
2. The API key is valid and has appropriate permissions
3. You've correctly sourced your .env file or exported the variables manually

📱 Device Connection Issues

If you have trouble connecting to your device:

1. Ensure USB debugging is enabled on your Android device
2. Check that your device is recognized by ADB: adb devices
3. For wireless connections, make sure your device and computer are on the same network

🤖 LLM Provider Selection

If DroidRun is using the wrong LLM provider:

1. Explicitly specify the provider with --provider (in CLI) or llm_provider= (in code)
2. When using Gemini, ensure you have set GEMINI_API_KEY and specified --provider gemini

💡 Example Use Cases

• Automated UI testing of Android applications
• Creating guided workflows for non-technical users
• Automating repetitive tasks on Android devices
• Remote assistance for less technical users
• Exploring Android UI with natural language commands

👥 Contributing

Contributions are welcome! Please feel free to submit a Pull Request.

📄 License

This project is licensed under the MIT License - see the LICENSE file for details.
