Exelog: Meticulous logging for Apache Spark

Enabling meticulous logging for Spark Applications

Exelog is a refactored logging module that provides a decorator based approach to ensure standard Python logging from PySpark Executor nodes also.

Why?

The problem: logging from Spark executors doesn't work with normal logging

In Apache Spark, the actual data processing is done in what's called "executors", which are separate processes that are separate from the "driver" program. For end users, full control is only over the driver process, but not so much over the executor processes.

For example, in the PySpark driver program we can set up standard python logging as desired, but this setup is not replicated in the executor processes. There are no out-of-the-box logging handlers for executors, so all logging messages from executors are lost. Since Python 3.2 however, when there are no handlers, there is still a "improvised" handler that will show warning() and error() messages in their bare format on standard error, but for proper logging we probably need something more flexible and powerful than that.

Illustration in interactive PySpark shell:

>>> import os, logging
>>> logging.basicConfig(level=logging.INFO)

>>> def describe():
...     return "pid: {p}, root handlers: {h}".format(p=os.getpid(), h=logging.root.handlers)
...
>>> describe()
'pid: 8915, root handlers: [<StreamHandler <stderr> (NOTSET)>]'

>>> sc.parallelize([4, 1, 7]).map(lambda x: describe()).collect()
['pid: 9111, root handlers: []', 'pid: 9128, root handlers: []', 'pid: 9142, root handlers: []']

The initial describe() happens in the driver and has root handlers because of the basicConfig() beforehand. However, the describe() calls in the map() happen in separate executor processes (note the different PIDs) and got no root handlers.

Exelog: Logging Spark executor execution one decorator at a time

Various ways for setting up logging for executors may be found on the internet. It usually entails sending and loading a separate file containing logging configuration code. Depending on the use case, managing this file may be difficult. One of the approaches is here

In contrast, Exelog takes a decorator based approach. We just have to decorate the data processing functions which we are passing to map(), filter(), sortBy(), etc.

A very minimal example:

@exelog.enable_info_logging
def process(x):
    logger.info("Got {x}".format(x=x))
    return x * x

result = rdd.map(process).collect()

What will happen here is that the first time process() is called in the executor, basic logging is set up with INFO level, so that logging messages are not lost.

Options and finetuning

The enable_exelog decorator will do a basic logging setup using logging.basicConfig(), and desired options can be directly provided to the decorator as illustrated in the following example using the interactive PySpark shell:

>>> import logging
>>> from exelog import enable_exelog
>>> logger = logging.getLogger("example")

>>> @enable_exelog(level=logging.INFO)
... def process(x):
...     logger.info("Got {x}".format(x=x))
...     return x * x
...
>>> sc.parallelize(range(5)).map(process).collect()
INFO:example:Got 0
INFO:example:Got 1
INFO:example:Got 3
INFO:example:Got 2
INFO:example:Got 4
[0, 1, 4, 9, 16]

To improve readability or code reuse, you can of course predefine decorators:

with_logging = enable_exelog(
    level=logging.INFO,
    format="[%(process)s/%(name)s] %(levelname)s %(message)s"
)

@with_logging
def process(x):
    ...

exelog also defines some simple predefined decorators:

# Predefined decorator for stderr/NOTSET logging
enable_notset_logging = enable_exelog(level=logging.NOTSET)

# Predefined decorator for stderr/DEBUG logging
enable_debug_logging = enable_exelog(level=logging.DEBUG)

# Predefined decorator for stderr/INFO logging
enable_info_logging = enable_exelog(level=logging.INFO)

# Predefined decorator for stderr/WARN logging
enable_warn_logging = enable_exelog(level=logging.WARN)

# Predefined decorator for stderr/ERROR logging
enable_error_logging = enable_exelog(level=logging.ERROR)

# Predefined decorator for stderr/CRITICAL logging
enable_critical_logging = enable_exelog(level=logging.CRITICAL)

Fine-grained logging set up

If the logging.basicConfig() API is not flexible enough for your desired setup, you can also inject more advanced setup code with the initialized_call decorator. This decorator is not limited to logging setup, it just expects a callable (that can be called without arguments). A very simple example:

@exelog.initialized_call(lambda: print("Executor logging enabled"))
def process(x):
    ....

This will print "Executor logging enabled" the first time the process function is called in each executor.
