F-Layer

Your cloud infrastructure, managed from one configuration.

F-Layer is an open-source infrastructure automation platform for engineers, small teams and applications that need repeatable deployments. Describe your environment, create its resources, check their state and remove the resources belonging to that deployment through the same CLI or Python API.

The main workflow in F-Layer 2.0 is a self-hosted VPN on Yandex Cloud: one server running AmneziaWG 3.1 and VLESS Reality, with separate connection files for each device. You own the cloud account, server and keys; you pay the cloud provider for resources and traffic.

Documentation · English · Русский · 简体中文 · Releases

What you get

• A VPN you control: provision the VM, network, firewall, public IP and disk, install both services, and export private client profiles and native AmneziaVPN QR codes for both protocols.
• Configurable resources: choose CPU, RAM, platform, CPU performance level, disk size and HDD/SSD type in project.toml.
• One deployment lifecycle: inspect status, recover interrupted cloud operations and remove your stack using its retained local state.
• More than VPN: prepare restricted SSH gateways, run HTTP availability and timing checks, or integrate the infrastructure APIs into your application.

Quick Start

Deploy with an AI assistant

Give an assistant with terminal access this task:

Deploy my self-hosted VPN using F-Layer: https://github.com/Fuzzy-Technologies/F-Layer. Read its AI operator guide and use documentation matching the installed package. Ask for my cloud, region and devices. Install a verified package, prepare a private project and show the resources, access rules, costs and cleanup plan. Obtain my approval before creating paid resources. Deploy through F-Layer's public CLI, help import the client profiles, and verify actual traffic. Keep secrets local and report what passed, what remains untested and how to remove the deployment.

The AI operator guide covers the full workflow. The assistant supplies your choices and runs F-Layer; F-Layer supplies the configuration, deployment lifecycle and client artifacts.

Deploy manually

Outcome: a server in your Yandex Cloud folder and private connection files you can import on your devices. Finish by checking real traffic through each protocol.

You need: Linux or a user-managed WSL Linux distribution, Python 3.11+, OpenSSH (ssh and ssh-keygen), and an authenticated Yandex Cloud CLI profile with permissions in your chosen folder. Use an Ubuntu 24.04 amd64 server image. Git and Docker are not required to run the package. Windows can run local package diagnostics; VPN deployment runs inside Linux/WSL.

1. Install and check

Create and activate a virtual environment in Linux/WSL:

python3 -m venv ~/.venvs/flayer
source ~/.venvs/flayer/bin/activate

Download the wheel and build-evidence.json from the v2.0.0 release. Check the wheel SHA-256 against the build evidence, then install from the download directory:

python -m pip install "./f_layer-2.0.0-py3-none-any.whl[vpn]"

After the separate PyPI publication, you can also install with python -m pip install "f-layer[vpn]==2.0.0". The vpn extra installs the cryptography dependency needed for local key generation.

flayer --help
flayer check --format json

Expected: "status": "ok" and exit code 0. This checks the local installation; it does not contact the cloud or test VPN connectivity.

2. Create your project

flayer project init ~/flayer-vpn

Edit ~/flayer-vpn/project.toml before preparing it:

• Set identity.scope_id to your cloud folder ID and choose your project, stack and owner names.
• Set cloud.yc_profile, zone_id and image_id to your actual profile, zone and image. Choose a subnet that does not overlap your other networks.
• Set cloud.management_cidrs to your administrator public IPv4 with /32.
• List your devices with unique tunnel addresses; the template includes laptop. Choose full or split IPv4 routing in [routes].
• Set vless.target_host and server_name to a reachable TLS 1.3 / HTTP/2 target with a matching certificate; replace the example hostname.

For explicit server sizing, uncomment the complete [resources] block in the template:

[resources]
platform_id = "standard-v3"
cores = 2
core_fraction = 50
memory_gib = 2
disk_size_gib = 10
disk_type = "network-hdd"

Check regional availability and the image's minimum disk size. Omitting this block retains the default 2 vCPU, 2 GiB RAM and 20 GiB SSD configuration. See configuration for supported combinations. Keep the project outside Git and shared folders; in WSL, use its Linux filesystem rather than /mnt/c.

3. Prepare and deploy

prepare generates local keys and artifacts without cloud calls. After this step, keep the configuration unchanged and retain the project directory.

flayer vpn prepare --project ~/flayer-vpn

Review the selected resources and their cost. The next command creates paid cloud resources. Replace YOUR_FOLDER_ID with the same identity.scope_id:

flayer vpn deploy --project ~/flayer-vpn --allow-mutation --scope-confirm YOUR_FOLDER_ID
flayer vpn status --project ~/flayer-vpn

Expected: owned cloud resources, both server services reported as services-active, and per-device files under ~/flayer-vpn/artifacts/. Server status alone does not prove that a client can access the Internet.

4. Connect a device

The client guide uses AmneziaVPN 5.0.3.0 on Android. For the template's laptop device, find these files inside your project:

• AmneziaWG: import artifacts/device-laptop-amneziawg/amneziawg.conf.
• VLESS Reality: import artifacts/device-laptop-vless-reality/amnezia.vpn, or open amnezia-qr-01.svg from that directory on another screen and scan it with AmneziaVPN's scanner. If several numbered QR files exist, scan all of them in the same import session.

Connect one protocol at a time. Open an HTTPS site by hostname, verify the server's public IPv4 as your exit address, and check DNS, routing and VPN/TUN settings. This version routes IPv4; disable IPv6 on the client/device to prevent bypass. The project's IPv6 setting does not change your device settings. Keep client files and QR codes private: they grant access to your VPN.

See the client walkthrough for protocol-specific checks and import details.

Manage your deployment

Use flayer vpn status --project ~/flayer-vpn to inspect your server. For an interrupted cloud operation, retain the project and follow the recovery guide. When you want to remove this project's cloud resources:

flayer vpn destroy --project ~/flayer-vpn --allow-mutation --scope-confirm YOUR_FOLDER_ID

Verify removal in the report and cloud folder. Local keys, artifacts and state remain on disk. Disconnecting a client does not remove billable cloud resources.

Current boundaries: Yandex Cloud is the implemented provider. Prepared projects are immutable; in-place resizing, device addition/revocation and key rotation are not available through the VPN CLI. Changing these settings requires a new project and the documented lifecycle for the old deployment.

Explore further

SSH gateway · CLI diagnostics · Python API · Changelog

Built by Fuzzy Technologies. Licensed under Apache 2.0. To contribute, start with CONTRIBUTING.md.
