fake-rpi 0.1.1

Install

The preferred way to install this is:

pip install fake_rpi

Development

To submit pull requests and do development:

git clone
cd fake_rpi
pip install -e .

Usage

To use as is:

from fake_rpi import GPIO as io
from fake_rpi import smbus
from fake_rpi import toggle_print

# by default it prints everything to std.error
toggle_print(False)  # turn on/off printing

io.setmode(io.BCM)
b = io.input(21)

sm = smbus.SMBus(1)
b = sm.read_byte_data(0x21, 0x32)  # read in a byte

But I need smbus to return a specific byte for unit testing! Ok, then create a child of my smbus like below and modify only the methods you need changed:

from fake_rpi import smbus
from fake_rpi import printf

class MyBus(smbus.SMBus):
        @printf
        def read_byte_data(self, i2c_addr, register):
                ret = 0xff
                if i2c_addr == 0x21:
                        ret = 0x55
                elif i2c_addr == 0x25:
                        ret = 0x11
                return ret

sm = MyBus()
b = sm.read_byte_data(0x21, 0x32)  # read in a byte

kevin@Logan fake_rpi $ ./example.py
<<< WARNING: using fake raspberry pi interfaces >>>

kevin@Logan fake_rpi $ ./example.py
<<< WARNING: using fake raspberry pi interfaces >>>
fake_rpi.RPi.PWM.__init__()
fake_rpi.RPi.PWM.start(5,)
fake_rpi.smbus.SMBus.__init__(1,)
fake_rpi.smbus.SMBus.write_byte_data(1, 2, 3)
fake_rpi.smbus.SMBus.read_byte_data(1, 2): 21
fake_rpi.smbus.SMBus.close()
__main__.MyBus.__init__()
__main__.MyBus.read_byte_data(1, 2): 72
__main__.MyBus.read_i2c_block_data(1, 2, 3): [90, 90, 90]

ToDo

• add serial

• double check interfaces and flush them out better

Change Log
