fastapi-depgraph

Introspection of a FastAPI app's Depends() tree: which dependencies each route resolves, which are shared across routes, which aren't cached, and export to ASCII or Mermaid.

Reads route.dependant — the structure FastAPI already builds internally when each route is registered — instead of reparsing signatures by hand.

Install

pip install fastapi-depgraph

Usage — CLI

depgraph show myapp.main:app
depgraph show myapp.main:app --shared --uncached
depgraph export myapp.main:app --format mermaid > graph.mmd

Usage — API

from fastapi_depgraph import inspect_app

report = inspect_app(app)

report.shared_dependencies()    # {callable: ["/route1", "/route2"]}
report.uncached_dependencies()  # ["module.get_request_id", ...]

for route in report.routes:
    print(route.path, route.root.name)

Example

$ depgraph show examples/basic_app.py:app --shared --uncached

GET /users/me
  basic_app.read_current_user (sync)
  └── basic_app.get_current_user (sync)
      ├── basic_app.get_db (async)
      │   └── basic_app.get_settings (sync)
      └── basic_app.get_request_id (sync) [no-cache]
...

Dependencies shared across routes:
  get_current_user: /orders, /orders/{order_id}, /users/me
  get_db: /orders, /orders/{order_id}, /users, /users/me
  get_settings: /orders, /orders/{order_id}, /users, /users/me
  get_request_id: /orders, /orders/{order_id}, /users/me
  get_orders_service: /orders, /orders/{order_id}

Dependencies with use_cache=False:
  basic_app.get_request_id

At a glance: get_db and get_settings get resolved on four different routes — if one gets expensive, that's where to look first. And get_request_id is intentionally marked as uncached (it comes from a per-request header), but in a real case that's the flag that warns you about a use_cache=False someone forgot or added by mistake.

What patterns it handles

Tested, with regression coverage, against the real patterns that broke early versions of this package:

• APIRouter + include_router(), at any level of nesting and with any prefix (/api → /v1 → /items correctly accumulates in the path).
• Dependencies declared on include_router(router, dependencies=[...]) or FastAPI(dependencies=[...]) — an auth guard for an entire router shows up in the tree of every route it covers.
• Apps mounted with app.mount(sub_app) (path caveat below).
• Dependencies parametrized by a factory (def make_limiter(n): def check(): ...; return check) or functools.partial(fn, role="admin"): two instances with different captured/bound values show up as distinct nodes (check{n=5} vs. check{n=10}, require_role(role='admin') vs. require_role(role='editor')) instead of collapsing into one name.
• Depends(SomeClass()) (instance) and Depends(SomeClass) (the class itself) — both "class as a dependency" patterns documented by FastAPI.

Known limitations

• Apps mounted with app.mount(sub_app) are walked (Starlette exposes the sub-app's routes through Mount.routes), but the reported path is relative to the sub-app, without the mount's prefix.
• Only HTTP routes are inspected; WebSocket routes aren't part of the tree (intentionally — Depends() on WebSocket doesn't have per-request caching or the same resolution model, see DESIGN.md §2).
• If two different instances of the same class are used as dependencies on different routes, shared_dependencies() correctly treats them as not shared (it compares by identity), but they're shown with the same label in the tree/Mermaid unless the class itself is a closure — there's no generic way to give an arbitrary instance a readable name.
• app.dependency_overrides (the standard mechanism for injecting test doubles) isn't reflected: the tree shows the dependency as declared in the code, not the one that would actually run under an active override — it's a static graph, see DESIGN.md §2.
• The name of a parametrized dependency includes the repr() of its captured/bound values — if those values are secrets (tokens, API keys passed as defaults), they'll show up in depgraph show/export output. Don't paste that output into public channels without checking what parametrized dependencies your app has.
• Merging the path/dependencies for included routers (include_router) uses, when available, an internal method with no public contract that Starlette exposes to resolve routes at request time; if that shape changes in a future version, the package silently degrades to the previous behavior (no accumulated prefix or inclusion dependencies) instead of failing — the CI matrix runs against several FastAPI versions to catch it early if that happens.

Why

FastAPI's DI system is implicit: nested Depends() resolve with no native way to see the tree. Two questions this package answers that today have no direct way to answer:

• Which expensive dependencies are being recomputed instead of cached (use_cache=False)?
• Which routes share an expensive dependency, so you know where to optimize once instead of in five different places?

See DESIGN.md for the rest of the scope and design decisions.
