fedcast 0.1.1b1

A modular framework for time series forecasting using federated learning, built on top of the Flower framework

FedCast: Federated Learning for Time Series Forecasting

FedCast is a comprehensive Python framework designed for time series forecasting using federated learning. It leverages the powerful Flower (flwr) framework to enable privacy-preserving, decentralized model training on distributed time series data.

Project Overview

The core goal of FedCast is to provide a modular, extensible, and easy-to-use platform for researchers and practitioners to develop and evaluate personalized federated learning strategies for time series analysis. The framework addresses the unique challenges of time series forecasting in federated settings, where data privacy, communication efficiency, and model personalization are critical concerns.

Problem Statement

Traditional centralized approaches to time series forecasting require all data to be collected at a central location, which poses significant challenges:

• Privacy Concerns: Sensitive time series data (medical, financial, IoT) cannot be shared
• Communication Overhead: Large-scale time series data is expensive to transmit
• Heterogeneity: Different clients may have varying data distributions and patterns
• Personalization: Global models may not perform well for individual client patterns

FedCast addresses these challenges through federated learning, enabling collaborative model training while keeping data distributed and private.

Architecture

FedCast is built on a modular architecture that seamlessly integrates with the Flower framework while providing specialized components for time series forecasting:

Core Components

1. Flower Integration Layer

• Direct integration with Flower's core functionality
• Custom client and server implementations
• Support for both synchronous and asynchronous federated learning
• Preservation of all Flower features and capabilities

2. Data Management

• Time Series Datasets: Support for multiple data types (synthetic, energy, medical, financial, IoT, network, weather)
• Data Validation: Automatic data cleaning and validation
• Transformation Pipelines: Flexible data preprocessing
• Heterogeneous Data Handling: Support for varying data distributions across clients
• Automatic Downloading: Built-in data source connectors with caching

3. Model Management

• Model Registry: Centralized model factory system
• Version Control: Model serialization and deserialization
• Adaptation: Model personalization and fine-tuning
• Architecture Support: MLP, Linear models, and extensible framework for custom models

4. Federated Learning Strategies

• Communication-Efficient Algorithms: FedLAMA reduces communication overhead by up to 70%
• Robust Aggregation: FedNova addresses objective inconsistency in heterogeneous settings
• Personalization: FedTrend and other specialized strategies for time series
• Standard Algorithms: FedAvg, FedProx, FedOpt, SCAFFOLD, and more

5. Evaluation & Experimentation

• Time Series Metrics: Specialized evaluation metrics for forecasting tasks
• MLflow Integration: Comprehensive experiment tracking and logging
• Visualization: Automatic plotting of training progress and results
• Grid Experiments: Automated testing across multiple configurations

6. Telemetry & Monitoring

• MLflow Logger: Centralized experiment tracking
• Performance Monitoring: Real-time training metrics
• Result Analysis: Comparative analysis tools

Design Principles

• Modularity: Clear separation of concerns with independent, replaceable components
• Extensibility: Plugin architecture for easy integration of new algorithms and data sources
• Privacy-First: Built-in privacy preservation mechanisms
• Performance: Optimized for communication efficiency and computational speed
• Reproducibility: Comprehensive logging and experiment tracking

Key Features

• Federated Time Series Forecasting: Train models on time-series data without centralizing it
• Built on Flower: Extends the robust and flexible Flower framework
• Modular Architecture: Easily customize components like data loaders, models, and aggregation strategies
• Personalization: Supports various strategies for building models tailored to individual clients
• Communication Efficiency: Advanced strategies like FedLAMA reduce communication overhead significantly
• Comprehensive Evaluation: Specialized metrics and visualization tools for time series forecasting
• Experiment Tracking: Full MLflow integration for reproducible research
• Multiple Data Sources: Support for synthetic, real-world, and domain-specific datasets

Technical Stack

• Python 3.12+: Core programming language
• Flower: Federated learning framework foundation
• PyTorch: Deep learning model implementation
• Pandas/NumPy: Data manipulation and numerical computing
• MLflow: Experiment tracking and model management
• Poetry: Dependency management and packaging
• Pytest: Testing framework

Quick Start Example

from fedcast.datasets import SinusDataset
from fedcast.cast_models import MLP
from fedcast.federated_learning_strategies import FedTrend
from fedcast.experiments import run_federated_experiment

# Load time series data
dataset = SinusDataset(num_clients=10, sequence_length=100)

# Define model architecture
model = MLP(input_size=100, hidden_size=64, output_size=1)

# Choose federated learning strategy
strategy = FedTrend()

# Run federated learning experiment
results = run_federated_experiment(
    dataset=dataset,
    model=model,
    strategy=strategy,
    num_rounds=50
)

# Results are automatically logged to MLflow
print(f"Final accuracy: {results['final_accuracy']}")

Getting Started

Installation

Option 1: Install from PyPI (Recommended)

pip install fedcast

Note: FedCast is currently in Beta (v0.1.1b1). While the core functionality is stable, some features may still be under development. We welcome feedback and contributions!

Option 2: Install from source

1. Clone the repository:

   git clone <repository-url>
   cd FedCast


2. Install dependencies: This project uses Poetry for dependency management and packaging.

   poetry install


   Or install directly with pip:

   pip install -e .


Quick Start

After installation, you can start using FedCast:

import fedcast
from fedcast.datasets import load_sinus_dataset
from fedcast.cast_models import MLPModel
from fedcast.federated_learning_strategies import build_fedavg_strategy

# Create a dataset
dataset = load_sinus_dataset(partition_id=0)

# Create a model
model = MLPModel()

# Create a federated learning strategy
strategy = build_fedavg_strategy()

# Your federated learning experiment here...

Development

Running Tests

To ensure the reliability and correctness of the framework, we use pytest for testing.

To run the full test suite, execute the following command from the root of the project:

poetry run pytest

This will automatically discover and run all tests located in the tests/ directory.

Running Experiments

FedCast provides several ways to run federated learning experiments:

1. Basic Experiments

Run individual experiments with specific configurations:

# FedAvg experiment
poetry run python fedcast/experiments/basic_fedavg.py

# FedTrend experiment
poetry run python fedcast/experiments/basic_fedtrend.py

2. Grid Search Experiments

Run comprehensive experiments across multiple configurations:

# Run all combinations of datasets, models, and strategies
poetry run python fedcast/experiments/grid_all.py

3. Custom Experiments

Create your own experiment scripts by importing FedCast components:

from fedcast.datasets import YourDataset
from fedcast.cast_models import YourModel
from fedcast.federated_learning_strategies import YourStrategy

# Implement your custom experiment logic

Monitoring and Visualization

MLflow UI

View experiment results, compare runs, and analyze performance:

mlflow ui --host 127.0.0.1 --port 5000

Access the UI at http://127.0.0.1:5000 to:

• Track experiment parameters and metrics
• Compare different federated learning strategies
• Visualize training progress and convergence
• Download model artifacts and results

Automatic Plotting

FedCast automatically generates plots for:

• Training and validation losses per round
• Client-specific performance metrics
• Communication efficiency comparisons
• Model convergence analysis

Plots are saved in runs/<experiment_name>/ directory.

Supporters

This project is supported by the Bundesministerium für Forschung, Technologie und Raumfahrt (BMFTR). We are grateful for their support, without which this project would not be possible.
