Pre-release

This release is a pre-release and may not be stable for production use.

Workflow Documentation Status codecov pre-commit DOI

FINCHnmr : [FI]tti[N]g 13[C] 1[H] HSQC [NMR]

FINCHnmr is lightweight toolkit for fitting 2D heteronuclear single-quantum coherence nuclear magnetic resonance (HSQC NMR) data to a known library of substances. This predicts the presence and relative concentration of these compounds, and the residual (error) can be interpreted as the sum of the remaining unknown compounds present. For a live demonstration, visit our HuggingFace space or try it out on streamlit's community cloud. Although originally designed to work with (1H-13C) data, FINCHnmr will work with any 2D NMR as long as the library used matches the sample being predicted / analyzed.

There are two approaches to generating the spectral libraries. Both methods are demonstrated in the documentation.

  1. Library spectra are taken directly from the Biological Magnetic Resonance Bank (BMRB). These spectra are automatically padded and resized so that they match the extent (2D grid) and resolution of the wild spectra being fit.
  2. Library spectra are reconstructed from a feature list of peak locations by placing bivariate Gaussians at these locations; assumptions must be made about the spread of these distributions in both dimentions of frequency shift space.

Installation

We recommend creating a virtual environment or, e.g., a conda environment then installing finchnmr with pip:

$ pip install finchnmr

You can also install from this GitHub repo source:

$ git clone git@github.com:mahynski/finchnmr.git
$ cd finchnmr
$ pip install .
$ python -m pytest # Optional unittests

Documentation

Documentation is hosted at https://finchnmr.readthedocs.io/ via readthedocs.

The logo was generated using Google Gemini with the prompt "Design a logo involving a finch and NMR" on Nov. 9, 2024.

License Information

  • See LICENSE.md for more information.
  • Any mention of commercial products is for information only; it does not imply recommendation or endorsement by NIST.
