firelens-monitor 1.0.40

Multi-vendor firewall monitoring solution with real-time metrics collection

A comprehensive real-time monitoring solution for multiple firewall vendors including Palo Alto Networks, Fortinet FortiGate, and Cisco Firepower. Features persistent data storage, enhanced web dashboard, intelligent timezone handling, and per-second session sampling for accurate throughput metrics.

Version 1.0.40

Core Features

• Multi-Vendor Firewall Support: Monitor firewalls from multiple vendors
  • Palo Alto Networks: Full support (PAN-OS API)
  • Fortinet FortiGate: Full support (REST API with token authentication)
  • Cisco Firepower: Full support (FDM and FMC REST APIs)
    • FDM (Firepower Device Manager) - Local management for single devices
    • FMC (Firepower Management Center) - Centralized management for multi-device deployments
    • OAuth2 token authentication (FDM) and HTTP Basic Auth (FMC)
    • Device discovery for FMC-managed devices
  • Vendor-specific admin forms with dynamic field visibility
  • Vendor-specific metrics dashboards and charts
  • VDOM support for FortiGate multi-tenant deployments
• Vendor-Agnostic Database Architecture: Scalable multi-vendor design
  • Dedicated metrics tables per vendor (palo_alto_metrics, fortinet_metrics)
  • Schema version tracking with automatic migrations
  • Existing databases upgrade seamlessly on service restart
• Enhanced Fortinet Visualization: Dual-axis charts for better insights
  • FortiGate Metrics chart: Memory % (left axis) / NPU Sessions (right axis)
  • Session Statistics chart: Active Sessions (left axis) / Setup Rate (right axis)
  • Vendor-aware hover summary with all Fortinet metrics
• Native SSL/TLS Support: Secure HTTPS access out of the box
  • Auto-generated self-signed certificate on first startup (1-year validity)
  • HTTPS enabled by default on port 8443
  • HTTP to HTTPS redirect (port 8080 to 8443)
  • Admin UI for uploading custom SSL certificates
  • Certificate status monitoring with expiry warnings
• Enhanced Security: Comprehensive security hardening
  • Bcrypt password hashing (12 rounds)
  • CSRF protection on all state-changing operations
  • Rate limiting on login endpoints (5 requests/minute)
  • Security headers (X-Frame-Options, CSP, X-Content-Type-Options)
  • XXE protection with defusedxml
  • Secure session management with absolute timeout (8 hours)
• Web-Based Admin Panel: Full firewall management through the web interface
  • Form-based authentication with configurable credentials
  • Random secure password generated during installation
  • Add, edit, and remove firewalls without service restart
  • Test connection button validates credentials before saving
  • Hot-reload: Changes take effect immediately
  • Enable/disable monitoring per firewall
  • Password change via web UI with complexity requirements
  • SAML/SSO authentication for enterprise identity providers
  • CA certificate management for custom SSL verification
  • SSL/TLS certificate management for web dashboard
• Multi-Firewall Support: Monitor multiple firewalls simultaneously with individual configurations
• Persistent Data Storage: SQLite database ensures data survives application restarts
• Per-Second Session Sampling: Continuous background sampling of session info for accurate throughput and PPS capture
• Production-Ready Performance: Enterprise-grade optimizations for long-running deployments
• Modern UI with Dark Mode:
  • Professional color palette (Primary Blue, Light Blue, Charcoal, Cool Grey)
  • Dark mode toggle with localStorage persistence across pages
  • Theme-aware chart rendering with proper contrast
  • Smooth transitions and responsive design
  • CSS architecture consolidation for easy maintenance
• Enhanced Web Dashboard:
  • Overview page listing all monitored firewalls with hardware info badges
  • Detailed firewall views with customizable date/time ranges
  • Real-time CPU aggregation toggles (Mean/Max/P95)
  • CPU chart visibility controls (show/hide Management/Data Plane independently)
  • Enhanced throughput and PPS statistics (Mean/Max/Min/P95)
  • CSV download functionality for filtered data with comprehensive metrics
  • 30-second intelligent caching for reduced database load
  • Firewall hardware detection (model, version, series)
• Critical Management CPU Fix: Corrected CPU calculation for PA-3400/5400 series firewalls
• Intelligent Timezone Handling: Automatic detection and conversion between local and UTC times
• Modular Architecture: Clean separation across multiple Python modules and packages for better maintainability
  • Web dashboard refactored into web_dashboard/ package with separate route modules
  • Each route module under 800 lines for easy navigation and maintenance
• Automatic Schema Migration: Database automatically adds new columns for enhanced statistics

Performance & Stability

• Memory Leak Prevention: Fixed unbounded memory growth with bounded deques and queues
  • Stable ~200MB memory usage
  • Automatic cleanup of old in-memory samples (2 hours retention)
  • Proper session and connection cleanup on shutdown
• Query Optimization: Eliminated N+1 query problems with batch queries
  • Dashboard: 181 queries to 14 queries (92% reduction)
  • Interface API: 21 queries to 1 query (95% reduction)
  • Page load: <500ms
• Database Performance: Connection pooling and intelligent indexing
  • Connection pool (max 10 connections) reduces overhead by 90%+
  • Optimized indexes for time-series queries
  • CPU usage: <5% steady state
• Resource Management: Automatic garbage collection and memory monitoring
  • Periodic GC every 5 minutes prevents memory fragmentation
  • Memory monitoring with psutil for health tracking
  • Bounded queues (maxsize=1000) prevent overflow

Key Highlights

• All CPU Aggregation Methods: Automatically collects Mean, Max, and P95 data plane CPU metrics
• Per-Second Sampling: Background threads sample session info every second for accurate metrics
• Enhanced Throughput/PPS Metrics: Automatically computes Mean, Max, Min, and P95 for both throughput and packets per second
• Interactive Time Filtering: Select specific date/time ranges with proper timezone conversion
• Comprehensive Data Export: Download filtered CSV data with all statistics (8+ metrics per data point)
• Persistent Configuration: YAML-based configuration with validation and hot-reload capabilities
• Database-Driven: All metrics stored in SQLite with automatic cleanup and retention management
• Sampling Quality Metadata: Track sample count, success rate, and sampling period for quality assessment
• Comprehensive Testing: 218 unit tests validate all critical functionality (100% pass rate)

Project Structure

FireLens/
├── pyproject.toml               # Python packaging configuration (PEP 517/518)
├── MANIFEST.in                  # Package data inclusion rules
├── LICENSE                      # MIT License
├── README.md                    # This file
├── config.yaml                  # YAML configuration file
│
├── src/firelens/                # Main Python package
│   ├── __init__.py              # Package version and exports
│   ├── __main__.py              # python -m firelens support
│   ├── cli.py                   # CLI entry points (firelens, firelens-ctl)
│   ├── resources.py             # Asset path discovery for templates/static
│   ├── app.py                   # Main FireLensApp class
│   ├── config.py                # Configuration management with admin support
│   ├── database.py              # Data persistence with connection pooling
│   ├── collectors.py            # Multi-threaded collection with hardware detection
│   ├── interface_monitor.py     # Interface monitoring with bounded deques
│   ├── ssl_manager.py           # SSL/TLS certificate generation
│   ├── cert_manager.py          # CA certificate management
│   ├── saml_auth.py             # SAML/SSO authentication handler
│   │
│   ├── web_dashboard/           # Web dashboard package (FastAPI)
│   │   ├── __init__.py          # Package exports
│   │   ├── app.py               # EnhancedWebDashboard class
│   │   ├── cache.py             # SimpleCache with TTL
│   │   ├── session.py           # SessionManager for authentication
│   │   ├── helpers.py           # Auth helpers and password validation
│   │   ├── middleware.py        # Security headers middleware
│   │   └── routes/              # Route modules (FastAPI APIRouter)
│   │       ├── dashboard.py     # Dashboard & metrics API
│   │       ├── auth.py          # Login, logout, password
│   │       ├── saml.py          # SAML/SSO authentication
│   │       ├── admin.py         # Firewall management CRUD
│   │       ├── certificates.py  # CA certificate management
│   │       └── ssl.py           # SSL/TLS management
│   │
│   ├── vendors/                 # Multi-vendor support framework
│   │   ├── __init__.py          # Vendor registry
│   │   ├── base.py              # Abstract base classes
│   │   ├── palo_alto.py         # Palo Alto Networks adapter (full)
│   │   ├── fortinet.py          # Fortinet FortiGate adapter (full)
│   │   └── cisco_firepower.py   # Cisco Firepower adapter (FDM + FMC)
│   │
│   ├── templates/               # Jinja2 HTML templates
│   │   ├── dashboard.html       # Main dashboard
│   │   ├── firewall_detail.html # Detailed metrics view
│   │   ├── admin_*.html         # Admin panel pages
│   │   └── ...
│   │
│   └── static/                  # Static web assets
│       ├── css/styles.css       # Consolidated stylesheet
│       ├── js/                  # JavaScript files
│       └── img/                 # Logo images
│
├── docker/                      # Docker deployment
│   ├── Dockerfile               # Multi-stage production build
│   ├── docker-compose.yml       # Container orchestration
│   └── config.yaml.template     # Default container config
│
├── packaging/                   # System packages
│   ├── debian/                  # Debian/Ubuntu .deb package
│   │   ├── control              # Package metadata
│   │   ├── rules                # Build rules
│   │   ├── firelens.service     # systemd service
│   │   ├── postinst             # Post-install script
│   │   └── prerm                # Pre-remove script
│   └── rpm/                     # RHEL/CentOS .rpm package
│       └── firelens-monitor.spec
│
├── .github/workflows/           # GitHub Actions CI/CD
│   ├── ci.yml                   # Test on PR/push (Python 3.9-3.13)
│   ├── release.yml              # Publish to PyPI, Docker, deb/rpm on tag
│   └── docker.yml               # Build dev image on push to main
│
├── scripts/                     # Build and utility scripts
│   └── build.sh                 # Local build script
│
├── tests/                       # Unit test suite (218 tests)
│   ├── test_certificates.py     # CA certificate tests
│   ├── test_collectors.py       # Hardware detection & CPU tests
│   ├── test_config.py           # Configuration tests
│   ├── test_database.py         # Database tests
│   ├── test_memory_leaks.py     # Memory leak tests
│   ├── test_vendors.py          # Multi-vendor tests
│   └── test_web_dashboard.py    # Web dashboard tests
│
├── run_tests.sh                 # Test runner script
└── check_python_version.py      # Python compatibility checker

Installation

Prerequisites

• Python 3.9+ (tested on Python 3.9 through 3.13)
• Access to firewall API (API keys generated automatically)
• For SAML support: libxmlsec1-dev system package

Installation Methods

FireLens can be installed via pip, Docker, or from source.

---

Option 1: Install via pip (Recommended)

# Install from PyPI
pip install firelens-monitor

# Verify installation
firelens --version

# Create configuration file
firelens create-config --output config.yaml

# Edit configuration with your firewall details
nano config.yaml

# Start monitoring
firelens --config config.yaml

System dependencies for SAML support:

# Ubuntu/Debian
sudo apt-get install libxmlsec1-dev libxmlsec1-openssl pkg-config

# RHEL/CentOS/Fedora
sudo dnf install xmlsec1-openssl-devel pkg-config

---

Option 2: Install via Docker

# Pull the image
docker pull ghcr.io/mancow2001/firelens:latest

# Or use docker-compose
cd docker/
cp config.yaml.template config.yaml
nano config.yaml  # Configure your firewalls

docker-compose up -d

# Access dashboard at https://localhost:8443

docker-compose.yml features:

• Persistent data volumes for database and logs
• Health checks with automatic restart
• Environment variable overrides
• Resource limits (512MB memory, 1 CPU)

---

Option 3: Install from Source

# Clone the repository
git clone https://github.com/mancow2001/FireLens.git
cd FireLens

# Create virtual environment
python3 -m venv venv
source venv/bin/activate  # On Windows: venv\Scripts\activate

# Install in development mode
pip install -e ".[dev]"

# Run tests to verify
pytest tests/ -v

# Create configuration
firelens create-config --output config.yaml

# Start monitoring
firelens --config config.yaml

---

CLI Commands

After installation, two commands are available:

firelens - Main application

firelens --version                    # Show version
firelens --help                       # Show help
firelens create-config -o config.yaml # Create example config
firelens --config config.yaml         # Start monitoring
firelens --port 9090                  # Override web port
firelens --log-level DEBUG            # Set log level

firelens-ctl - Service control (for systemd deployments)

firelens-ctl status    # Show service status
firelens-ctl start     # Start service
firelens-ctl stop      # Stop service
firelens-ctl restart   # Restart service
firelens-ctl logs      # Follow service logs
firelens-ctl config    # Show configuration

Configuration

Primary Configuration: config.yaml (Recommended)

# Global settings
global:
  output_dir: "./output"
  database_path: "./data/metrics.db"
  web_dashboard: true
  web_port: 8080
  log_level: "INFO"

  # Admin panel configuration
  admin:
    enabled: true
    username: "fireAdmin"
    password_hash: "$2b$12$..."  # Bcrypt hashed password (auto-generated on install)
    password_reset_required: false
    session_timeout_minutes: 60
    secure_cookies: true  # Set to false if not using HTTPS

  # SSL/TLS configuration (enabled by default)
  web_ssl:
    enabled: true
    auto_generate: true           # Auto-generate self-signed cert if none exists
    https_port: 8443              # HTTPS port (primary)
    http_port: 8080               # HTTP port (redirects to HTTPS)
    redirect_http_to_https: true  # Redirect HTTP to HTTPS
    min_tls_version: "TLSv1.2"

  # Certificate storage directory
  certs_directory: "/opt/FireLens/certs"

# Multiple firewall configurations
firewalls:
  datacenter_fw:
    host: "https://10.100.192.3"
    username: "admin"
    password: "YourPassword"
    type: "palo_alto"           # Vendor type (palo_alto, fortinet, cisco_firepower)
    verify_ssl: false
    enabled: true
    poll_interval: 60           # Recommended: 15-30 seconds for accurate throughput
    interface_monitoring: true  # Enable interface bandwidth monitoring
    auto_discover_interfaces: true

  branch_fw:
    host: "https://192.168.1.1"
    username: "admin"
    password: "BranchPassword"
    type: "palo_alto"
    verify_ssl: false
    enabled: true
    poll_interval: 30           # Shorter interval captures traffic bursts better

  fortigate_fw:
    host: "https://10.100.192.111"
    username: ""                # Optional for Fortinet (ignored with API token)
    password: "your_api_token"  # FortiGate REST API token
    type: "fortinet"
    vdom: "root"                # FortiGate VDOM (default: root)
    verify_ssl: false
    enabled: true
    poll_interval: 60
    interface_monitoring: true
    auto_discover_interfaces: true

  # Cisco Firepower with FDM (local management)
  firepower_fdm:
    host: "https://10.100.192.50"
    username: "admin"
    password: "FirepowerPassword"
    type: "cisco_firepower"
    management_mode: "fdm"      # FDM for local device management
    verify_ssl: false
    enabled: true
    poll_interval: 60
    interface_monitoring: true
    auto_discover_interfaces: true

  # Cisco Firepower with FMC (centralized management)
  firepower_fmc:
    host: "https://fmc.example.com"
    username: "api_user"
    password: "ApiPassword"
    type: "cisco_firepower"
    management_mode: "fmc"      # FMC for centralized management
    device_id: "abc123-device-uuid"  # UUID of managed device (discovered via admin UI)
    verify_ssl: false
    enabled: true
    poll_interval: 60
    interface_monitoring: true
    auto_discover_interfaces: true

Configuration Options

Global Settings

• output_dir: Directory for data storage
• database_path: SQLite database location
• web_dashboard: Enable/disable web interface
• web_port: Web dashboard port
• log_level: Logging verbosity (DEBUG, INFO, WARNING, ERROR)

Firewall Settings

• host: Firewall management URL (include https://)
• username/password: API credentials
• verify_ssl: SSL certificate verification
• enabled: Enable/disable monitoring for this firewall
• poll_interval: Polling frequency in seconds (recommended: 15-30 for throughput capture)

Performance Tip: Use poll_interval: 15-30 seconds to capture traffic bursts and transient events accurately. The per-second sampling will then aggregate these periods into meaningful statistics.

Usage

Running FireLens

# Start with default configuration search
firelens

# Use specific configuration file
firelens --config /etc/firelens/config.yaml

# Override web port
firelens --port 9090

# Set log level
firelens --log-level DEBUG

# Run as Python module
python -m firelens --config config.yaml

Access Points

Dashboard:       https://localhost:8443
Firewall detail: https://localhost:8443/firewall/{name}
Admin panel:     https://localhost:8443/admin
Health API:      https://localhost:8443/api/health

Enhanced Features

Per-Second Session Sampling

The monitor continuously samples session info every second in background threads:

• Automatic Collection: No configuration needed
• Background Processing: Samples collected asynchronously
• Aggregation: Samples aggregated into statistics at each poll interval
• Quality Metrics: Track sample count, success rate, and sampling period
• Minimal Overhead: Uses short timeouts (5s) for fast responses

Multi-Firewall Monitoring

• Independent Configuration: Each firewall has its own polling interval and settings
• Centralized Dashboard: View all firewalls from one interface
• Individual Detail Pages: Deep dive into specific firewall metrics
• Status Indicators: Real-time online/offline status with color coding

Intelligent Timezone Handling

• Automatic Detection: Uses browser timezone for input and display
• Seamless Conversion: Enter times in your local timezone, stored as UTC
• Dual Timestamps: CSV exports include both local and UTC timestamps
• Smart Defaults: Time ranges default to last 6 hours in user's local timezone

Collected Metrics

Firewall Hardware Detection (Auto-Detected)

• Model: Firewall model number (e.g., PA-3430, PA-5420)
• Software Version: PAN-OS version running on firewall
• Family: Firewall series (e.g., 3400, 5400)
• Serial Number: Device serial number
• Hostname: Configured firewall hostname

Management Plane

• CPU Components: User, System, Idle percentages
• Total Management CPU: Combined user + system percentage

Data Plane (Enhanced)

• CPU Mean: Average across all cores (overall health)
• CPU Max: Highest loaded core (bottleneck detection)
• CPU P95: 95th percentile (capacity planning)

Network Performance (Enhanced with Per-Second Sampling)

• Throughput Mean/Max/Min/P95: Mbps statistics over polling interval
• PPS Mean/Max/Min/P95: Packets per second statistics
• Packet Buffer: Maximum buffer utilization across processors

Security Considerations

API Permissions

Create dedicated monitoring users with minimal permissions:

• show system resources (read-only)
• show running resource-monitor (read-only)
• show session info (read-only)

Best Practices

• Strong Passwords: Use complex API credentials
• SSL Verification: Enable certificate verification in production (verify_ssl: true)
• Network Restriction: Limit access to management interfaces
• Credential Management: Store sensitive data in protected configuration files

Testing

Comprehensive Test Suite

The project includes 218 unit tests validating all critical functionality:

# Run all tests (recommended)
./run_tests.sh

# Run with coverage report
./run_tests.sh coverage

# Run specific test suites
./run_tests.sh database    # Database tests only
./run_tests.sh memory      # Memory leak tests only
./run_tests.sh web         # Web dashboard tests only
./run_tests.sh collectors  # Collector tests only

# Quick run without coverage
./run_tests.sh quick

Performance and Scaling

Resource Usage

• Memory: Stable ~200MB for multi-firewall deployments
• Database Growth: ~4KB per firewall per poll
• CPU: <5% steady state
• Network: 4 API calls per firewall per poll interval

Scaling Guidelines

• Small deployment: 1-10 firewalls, 30-60 second poll intervals
• Medium deployment: 10-50 firewalls, 60-120 second poll intervals
• Large deployment: 50+ firewalls, consider multiple instances or longer intervals

Quick Start

Via pip (Recommended)

# 1. Install FireLens
pip install firelens-monitor

# 2. Create configuration
firelens create-config --output config.yaml

# 3. Edit config.yaml with your firewall details
nano config.yaml

# 4. Start monitoring
firelens --config config.yaml

# 5. Access dashboard at https://localhost:8443

Via Docker

# 1. Get the docker files
git clone https://github.com/mancow2001/FireLens.git
cd FireLens/docker

# 2. Configure
cp config.yaml.template config.yaml
nano config.yaml

# 3. Start
docker-compose up -d

# 4. Access dashboard at https://localhost:8443

Via DEB Package (Debian/Ubuntu)

# 1. Download the latest .deb from GitHub Releases
wget https://github.com/mancow2001/FireLens/releases/latest/download/firelens-monitor_<version>_all.deb

# 2. Install the package
sudo apt install ./firelens-monitor_<version>_all.deb

# 3. Edit configuration
sudo nano /etc/firelens/config.yaml

# 4. Start and enable the service
sudo systemctl enable --now firelens

# 5. Access dashboard at https://localhost:8443

Via RPM Package (RHEL/CentOS/Fedora)

# 1. Download the latest .rpm from GitHub Releases
wget https://github.com/mancow2001/FireLens/releases/latest/download/firelens-monitor-<version>.x86_64.rpm

# 2. Install the package (use yum for older systems)
sudo dnf install ./firelens-monitor-<version>.x86_64.rpm

# 3. Edit configuration
sudo nano /etc/firelens/config.yaml

# 4. Start and enable the service
sudo systemctl enable --now firelens

# 5. Access dashboard at https://localhost:8443

From Source

# 1. Clone and install
git clone https://github.com/mancow2001/FireLens.git
cd FireLens
pip install -e ".[dev]"

# 2. Run tests
pytest tests/ -v
# Expected: 218 passed

# 3. Create config and start
firelens create-config --output config.yaml
nano config.yaml
firelens --config config.yaml

License

This project is licensed under the MIT License - see the LICENSE file for details.

---
