Firmngin Python SDK

Python SDK for Firmngin device clients, Raspberry Pi. Supports async and sync styles with mTLS, E2EE, entity state, payments, and optional image upload.

Docs: Introduction — Python SDK menu on firmngin.dev/docs

Install

pip install firmngin

Image upload (optional):

pip install firmngin[http]

From Git:

pip install git+https://github.com/firmngin/firmngin-sdk-python.git

Client vs AsyncClient

There are two client classes: Client (sync, blocking) and AsyncClient (async, non-blocking). Both support the same events and payloads. Use AsyncClient in an async context with await client.connect() and await client.run(). Use Client in a sync context with client.connect() and client.run().

Both use ClientConfig.from_file("keys.json") and support the same events.

Quickstart

from firmngin import Client, ClientConfig, Entity, EntityCommand

relay = Entity("relay")
temperature = Entity("temperature")

with Client(ClientConfig.from_file("keys.json")) as client:

    @client.on_entity(relay)
    def handle_relay(command: EntityCommand) -> None:
        print("relay:", command.value)

    client.connect()
    client.push_entity(temperature, 27.5)
    client.run()

Debug mode

Debug is off by default — no banner or console output.

client.set_debug(True)
client.connect()

With debug enabled, connect() prints the Firmngin banner, connection details, and connect/disconnect messages.

Events

Register handlers with client.on(Event.X, handler):

Event	Payload	Description
Event.PAYMENT	Payment	Payment updates
Event.PAYMENT_PENDING	Payment	Payment pending
Event.PAYMENT_SUCCESS	Payment	Payment succeeded
Event.POSTPAID_READY	Payment	Postpaid order ready
Event.INIT	Init	Device init payload
Event.DISPENSE	Dispense	Vending SKU list to dispense
Event.MERCHANT_STATUS	str	Merchant status string
Event.VERIFICATION	Verification	Verification result
Event.PIN	Verification	PIN display
Event.DEVICE_STATUS	DeviceStatus	Device lifecycle
Event.ENTITY_COMMAND	EntityCommand	Any entity command
Event.ACTIVE_SESSION	ActiveSession	Active paid session
Event.METADATA_PENDING	str	Pending-payment metadata JSON
Event.METADATA_ACTIVE_SERVICE	str	Active-service metadata JSON
Event.METADATA_EXPIRED	str	Expired-payment metadata JSON
Event.METADATA_SUCCESS	str	Successful-payment metadata JSON
Event.METADATA_POSTPAID_READY	str	Postpaid-ready metadata JSON
Event.ERROR	Exception	Runtime error

Metadata events pass the decrypted payload as a JSON string — parse it in your handler.

Event.POSTPAID_READY uses the same Payment fields as pending and successful payments: item title, price, order ID, and quantity (always 1 for postpaid). When the catalog item has postpaid-ready metadata, it is delivered separately through Event.METADATA_POSTPAID_READY.

Every Payment also exposes mutually exclusive payment-type booleans: is_post_paid / is_pre_paid. These flags are separate from is_pending and is_success.

Init business mode

Use is_service_mode / is_vending_mode to detect business mode:

@client.on(Event.INIT)
def on_init(init: Init) -> None:
    if init.is_vending_mode:
        print("vending mode")

Vending dispense

When business mode is vending, a paid order delivers catalog SKUs to dispense. Handle with Event.DISPENSE / Dispense:

from firmngin import Dispense, Event

@client.on(Event.DISPENSE)
def on_dispense(dispense: Dispense) -> None:
    if not dispense.is_valid:
        return
    for sku in dispense.skus:
        print("dispense:", sku)

When the service enters on_active_service, optional catalog metadata is delivered separately through Event.METADATA_ACTIVE_SERVICE. Like the other metadata events, the payload remains a decrypted raw JSON string.

import json

@client.on(Event.METADATA_PENDING)
def on_metadata(raw_json: str) -> None:
    data = json.loads(raw_json)

Per-entity commands:

@client.on_entity(Entity("relay"))
def on_relay(command: EntityCommand) -> None:
    print(command.value)

API overview

Import	Role
AsyncClient	Async device client
Client	Sync blocking client
ClientConfig	Runtime settings
KeysConfig	keys.json loader
Event	Event names for client.on(...)
Entity, Payment, Init, Dispense, …	Typed payloads

Device keys

Download keys.json from the Firmngin dashboard. The SDK accepts dashboard fields including server_fingerprint_bytes (20-byte Arduino-style fingerprint) and picks the right TLS validation mode automatically.

The generated service_ca_cert is the trust anchor for HTTPS device services at ota.firmngin.dev, including image upload. MQTT continues to use ca_cert independently.

Never commit real keys. See keys.json.example.

For a local development broker, add these fields to keys.json:

{
  "firmngin_broker_addr": "192.168.100.31",
  "firmngin_broker_port": 1883,
  "firmngin_no_tls": true,
  "firmngin_api_base_url": "http://192.168.100.31:8080/api/v1",
  "firmngin_ota_base_url": "http://192.168.100.31:8080/api/v1/ota"
}

The broker fields only change the MQTT connection. firmngin_no_tls sends MQTT traffic without TLS and must only be used in a trusted development network. firmngin_api_base_url configures HTTP device-service requests. The OTA URL is reserved for OTA support and is not consumed by an OTA executor yet.

Image upload

pip install firmngin[http]

await client.upload_image(Entity("camera"), "snapshot.jpg")

Examples

See examples/.

License

MIT — see LICENSE.
