fitcheck

Predict how much VRAM a LoRA/QLoRA fine-tune will need — before you launch it.

fitcheck reads a model's config.json from the Hugging Face Hub (~2 KB, never the weights) and computes peak training memory as a sum of six components: base model weights, LoRA adapter weights, optimizer states, gradients, activations, and CUDA runtime overhead. Every number is arithmetic over hidden_size, num_hidden_layers, intermediate_size, num_key_value_heads and your training flags, so no GPU, no CUDA install, and no model download is involved — the tool runs the same on a laptop as on the machine you're sizing for. You get the total, the per-component breakdown, a fits/doesn't-fit verdict against a specific card, and the largest micro-batch that still fits.

fitcheck infer prices the other half of the job — serving a trained model, where the budget is resident weights plus the KV cache — from the same config and the same math. And fitcheck advise sweeps the knobs instead of pricing one setting: what each axis costs, how far each one goes before it stops fitting, and the configs sitting right at that edge.

Accuracy status (v0.1.2, 2026-09-02): measured, and the measurements moved the formulas. Ten real training runs on a Tesla T4 — three models, three sequence lengths, both attention kernels — put the five physical components within 3.4% of measured peak (mean 0.8%). The full total, which includes the CUDA-overhead heuristic and is what the fits/doesn't-fit verdict uses, is within 14.7% (mean 5.5%). All of the remaining error is in that one heuristic. Getting here changed three things in the activation formula and moved the reference numbers — see Validation for the table and what is still unmeasured.

---

Mode A — one-liner

fitcheck meta-llama/Llama-3.1-8B --qlora --lora-r 64 --batch-size 4 --seq-len 2048 --optimizer adamw --flash-attn --gpu 4090

[!NOTE] One screenshot on this page is still stale: the compare capture further down was taken before the v0.1.2 activation fix and shows the older totals. Its layout is current; its numbers are not. Every other capture here is current. The authoritative figures are in Validation and in docs/SPEC.md.

Exit code is 0 if the config fits, 1 if it doesn't, 2 if the estimate couldn't be run — so fitcheck ... && accelerate launch ... works as a guard in front of a training job.

Llama and Gemma are gated on the Hub, so that command needs hf auth login or an HF_TOKEN first — see Hugging Face access. Public models like Qwen/Qwen2.5-14B and mistralai/Mistral-7B-v0.3 need no token at all.

---

Mode B — interactive REPL

Run fitcheck with no model ID and you get a session instead. Flags typed at the memory prompt stick, so moving one dial doesn't mean retyping the whole line.

help lists the command surface:

explain names the largest component and prices every toggle by re-running the whole estimate with one flag flipped — never by hand-summing component deltas, so the 5% that CUDA overhead picks up is included automatically. Two lines are load-bearing. Gradient accumulation costs 0 MiB, because gradients accumulate in place. And for this config, turning Flash Attention off also costs 0 MiB: under checkpointing the peak is the larger of the LM-head hump and one layer's recompute, and with a 128k vocabulary the LM head wins either way. A tool that promised a saving there would be wrong.

compare puts the same config on several cards, and leads with the point — the peak is identical everywhere, only the ceiling moves, so the max micro-batch column is the interesting one.

Also available: optimize (largest micro-batch that fits, plus a config actually worth running), advise / sweep (the whole map at once — see below), show, reset, and gpus.

---

Inference — fitcheck infer

Serving a model is a different budget from training one. There are no gradients, no optimizer states and no saved activations. What stays resident is the weights plus the KV cache, and the cache grows with every request you keep in flight.

fitcheck infer NousResearch/Meta-Llama-3.1-8B --gpu 4090

That is the ungated Llama-3.1-8B mirror, so it runs with no token — see Hugging Face access.

The same thing is a REPL command, on the model and GPU already loaded. Its flags are sticky like memory's, but they are a separate set — serving computes in fp16 where training defaults to bf16, so the two never share a value. That makes re-pricing the same model one short line:

4-bit weights take the same 8B model from 16,851 MiB down to 6,586 MiB: the weights line falls from 15,317 to 5,541 MiB and the CUDA buffers shrink with it. The KV cache does not move at all, because --quant is the weight format and --precision is the compute dtype — a 4-bit deployment still serves an fp16 cache.

compare ... --infer puts one serving config on several cards. The peak is identical on all of them, so the interesting column is how many concurrent requests each card can hold:

The cache is the part people under-budget. fitcheck prints its price per token and per request — 0.125 MiB and 256 MiB for Llama-3.1-8B at 2,048 tokens — and --seq-len and --concurrent are interchangeable: 4 requests of 2,048 tokens cost exactly what 1 request of 8,192 costs. Every request is assumed to hold its full context, so the number is a worst case; a paged engine like vLLM allocates less until the cache fills up.

---

Config advisor — fitcheck advise

A breakdown tells you what one config costs. It does not tell you which dial to turn. advise sweeps batch size, sequence length and LoRA rank together and answers the two questions that actually decide a run: what does each axis cost, and how far can each one go before it stops fitting.

fitcheck advise meta-llama/Llama-3.1-8B --gpu 4090 --qlora --flash-attn \
  --lora-targets q,k,v,o --seq-lens 512,1024,2048,4096,8192

The screen is four blocks: what is held fixed versus what is swept, the frontier (the configs at the edge of what fits, one pasteable command per row), the wall (the exact ceiling on each axis), and the price of each axis.

For Llama-3.1-8B QLoRA on a 4090, the price table settles the argument on its own:

Change from batch 2 × seq 2048, rank 64	Cost	New total
rank 64 → 32	−416 MiB	19,623.87
rank 64 → 128	+832 MiB	20,871.87
tokens/step ÷2 (batch 1)	−5,284 MiB	14,756.27
tokens/step ×2 (batch 4 or seq 4096)	+10,567 MiB	30,607.07 — does not fit

Doubling tokens/step costs about 12.7× what doubling the rank costs. Rank is not the knob stopping you — and the ceiling proves it: at rank 64 the wall is 4,096 tokens/step, and dropping all the way to rank 8 does not buy a single extra token. Meanwhile at 4,096 tokens/step the rank can go up to 330 before the card runs out.

Two details that make the numbers trustworthy. Every ceiling is found by bisection over the full estimator, not read off the grid — this grid stops at rank 256 while the real wall is 330, so a grid-only answer would be wrong. And --seq-lens is required, because there is no honest default: sweeping past a model's real context length in silence would be worse than asking. --max-seq-len is a guard that rejects a too-long swept length, not a generator.

advise is also a REPL command (alias sweep), and it shares the sticky training flags with memory — advise --qlora --flash-attn sets them for both, so there is no second copy to drift. In a session --seq-lens stops being required once you have given it, because a session remembers.

advise says what each axis costs and where the wall is; the REPL's optimize says what to run. They are deliberately different questions.

---

Installation

pip install fitcheck-llm

Python 3.10+. Runtime dependencies are click, rich, and huggingface-hub — no torch, no CUDA.

Hugging Face access

Most models need no authentication at all — fitcheck Qwen/Qwen2.5-14B and fitcheck mistralai/Mistral-7B-v0.3 work on a fresh machine with no token and no login.

Gated repos are the exception, and that includes Llama and Gemma — the models used in most of the examples here. For those, accept the license on the model page, then either log in:

hf auth login

or set the token in the environment, which is what you want in CI or a container:

export HF_TOKEN=hf_...

Without it you get a clear error rather than a stack trace:

Error: Could not read config.json for 'meta-llama/Llama-3.1-8B': This model is gated on
Hugging Face. Accept its license on the model page, then run: hf auth login

Once a config.json is in the Hub cache, fitcheck runs offline.

---

Usage

Mode A

# QLoRA on a 4090 — the shorthand expands to --quant nf4 --precision bf16 --grad-checkpoint
fitcheck meta-llama/Llama-3.1-8B --qlora --lora-r 64 --batch-size 4 --seq-len 2048 --flash-attn

# All seven target modules, 8-bit optimizer, on a 16 GB T4
fitcheck mistralai/Mistral-7B-v0.3 --qlora --lora-r 32 --lora-targets full --optimizer adam8bit --batch-size 2 --seq-len 1024 --flash-attn --gpu t4

# Full fine-tuning in mixed precision (adds the FP32 master weight copy).
# This one reports "doesn't fit" and exits 1 — which is the useful answer.
fitcheck Qwen/Qwen2.5-14B --no-lora --precision bf16 --batch-size 1 --gpu a100-80

# Why is it that big, and what would each knob save?
fitcheck meta-llama/Llama-3.1-8B --qlora --lora-r 64 --batch-size 4 --explain

# A card that isn't in the database
fitcheck meta-llama/Llama-3.1-8B --qlora --vram-mib 32768

# Machine-readable, for CI
fitcheck meta-llama/Llama-3.1-8B --qlora --batch-size 4 --json

--list-gpus prints the 22-card database. --verbose adds the per-layer activation breakdown. --no-color for logs. -V for the version. fitcheck --help has the full option surface.

Mode B

fitcheck                          # bare session
fitcheck --qlora --gpu 4090       # flags without a MODEL_ID seed the session

model meta-llama/Llama-3.1-8B     # fetch config.json
gpu 4090                          # set the target card
memory --qlora --lora-r 64 --batch-size 4 --flash-attn
memory --batch-size 8             # flags are sticky; only the batch size changes
explain                           # largest component + price of every toggle
optimize                          # a batch size worth running, not just the ceiling
compare 3090 t4 a100-40           # same config, several cards
infer --quant nf4 --double-quant  # serving instead of training: weights + KV cache
compare a100-40 t4 --infer        # the serving config across cards
advise --seq-lens 1024,2048,4096  # sweep the knobs: axis prices, ceilings, frontier
reset                             # flags back to defaults

Inference

# Weights + KV cache for one 2,048-token request
fitcheck infer meta-llama/Llama-3.1-8B --gpu 4090

# 4-bit serving, with double quantization for the smaller scale overhead
fitcheck infer meta-llama/Llama-3.1-8B --quant nf4 --double-quant --gpu 4090

# 8 concurrent requests at 8k context -- 14,919 MiB, still fits a 4090
fitcheck infer meta-llama/Llama-3.1-8B --quant nf4 --double-quant --seq-len 8192 --concurrent 8

# Doesn't fit: fp16 weights alone are 15,317 MiB and a T4 has 14,000 usable. Exits 1.
fitcheck infer meta-llama/Llama-3.1-8B --gpu t4

# Machine-readable, for CI
fitcheck infer meta-llama/Llama-3.1-8B --quant nf4 --json

Exit codes are the training command's: 0 fits, 1 doesn't fit, 2 couldn't run. --gpu, --vram-mib and --no-color behave the same too. fitcheck infer --help has the full flag list.

Advisor

# The full map: axis prices, per-axis ceilings, and the frontier
fitcheck advise meta-llama/Llama-3.1-8B --gpu 4090 --qlora --flash-attn --seq-lens 512,1024,2048,4096,8192

# Narrow the sweep to the axes you can actually change
fitcheck advise meta-llama/Llama-3.1-8B --gpu 4090 --qlora --seq-lens 2048 --batch-sizes 1,2,4,8

# Refuse to price a context length the model cannot serve
fitcheck advise meta-llama/Llama-3.1-8B --gpu 4090 --qlora --seq-lens 8192,16384 --max-seq-len 8192

# Machine-readable, for CI
fitcheck advise meta-llama/Llama-3.1-8B --gpu 4090 --qlora --seq-lens 2048,4096 --json

--seq-lens is required in Mode A and optional in the session. Exit codes: 0 at least one swept config fits, 1 none of them does, 2 couldn't run — which includes a --seq-lens past --max-seq-len. fitcheck advise --help has the full flag list.

Model support

The parser handles dense decoder-only transformers with a gated (SwiGLU-style) MLP — Llama, Mistral, Qwen2/2.5, Gemma-2/3 and anything config-shaped like them. It reads head_dim when the config declares one rather than assuming hidden_size / num_attention_heads, and it never assumes intermediate_size == 4 × hidden_size; both assumptions are wrong on Gemma-2.

Not modelled: MoE architectures (Mixtral, DeepSeek), encoder-decoder models, sliding-window attention, torch.compile, and multi-GPU sharding (FSDP / DeepSpeed ZeRO). See SPEC.md § 3.7 for the full limitations table.

---

How it compares

	needs a GPU?	component breakdown?	LoRA / QLoRA training?	empirically validated?
fitcheck	no	yes — all 6	yes, GQA-aware	yes — 10 measured runs (see below)
accelerate estimate-memory	no	weights + a coarse training multiplier	no	not published
HF Model Memory Usage Space	no	same, in a web UI	no	not published
vram.asmirnov.xyz	no	yes, but outdated and has many issues	partial	not published

None of these need a GPU — that isn't the differentiator, and claiming it would be dishonest. The gaps fitcheck fills are LoRA/QLoRA-native accounting (adapter memory, optimizer states sized to trainable params only, NF4 scale overhead), GQA-aware dimensions for k_proj/v_proj and the K/V activations, and a CLI that exits nonzero so CI can gate on it.

The honest differentiator is the measured predicted-vs-actual table below. None of the alternatives publish one. That is not a claim that they are wrong — it is a claim that nobody can tell, including their authors. fitcheck's numbers have been checked against real training runs, the checks found three real bugs, and the gaps that remain are listed rather than hidden.

Validation

Ten real training runs, all reproducible from fitcheck.ipynb with scripts/measure.py. One Tesla T4 (sm_75), FP16 compute, QLoRA r=32 [q,k,v,o], AdamW with FP32 states, gradient checkpointing on. Every run loads the real model, applies real LoRA adapters, and runs real training steps.

What "error" means here

PyTorch has two memory counters and neither of them is "VRAM used". Comparing the wrong pair makes a correct formula look broken, so the harness compares three times, like with like:

tier	predicted	measured	what it grades
tensors	the six components minus C_overhead	max_memory_allocated()	the five physical formulas
process	the full fitcheck total	max_memory_reserved() + CUDA context	what you actually see, and what the verdict uses

Both are reported below, because showing only the flattering one would be dishonest.

Results

Model	Config	Attention	Predicted	Measured	Tensors err	Process err
TinyLlama-1.1B	bs=2, seq=512	eager	1,834	1,849	−0.8%	+9.4%
TinyLlama-1.1B	bs=2, seq=1024	eager	2,778	2,876	−3.4%	−7.2%
TinyLlama-1.1B	bs=2, seq=2048	eager	6,702	6,655	+0.7%	−3.2%
TinyLlama-1.1B	bs=2, seq=512	SDPA (no s²)	1,834	1,847	−0.7%	+6.7%
TinyLlama-1.1B	bs=2, seq=1024	SDPA (no s²)	2,510	2,528	−0.7%	+3.1%
TinyLlama-1.1B	bs=2, seq=2048	SDPA (no s²)	3,862	3,897	−0.9%	−4.9%
SmolLM2-1.7B	bs=4, seq=1024	eager	5,280	5,297	−0.3%	−14.7%
SmolLM2-1.7B	bs=4, seq=1024	SDPA (no s²)	5,280	5,281	−0.0%	−0.2%
Qwen2.5-1.5B	bs=2, seq=1024	eager	6,810	6,831	−0.3%	+1.7%
Qwen2.5-1.5B	bs=2, seq=1024	SDPA (no s²)	6,810	6,823	−0.2%	+3.7%

Predicted and Measured are MiB on the tensors tier.

tier	max abs error	mean abs error
tensors — the five physical formulas	3.4%	0.8%
A_act alone, measured by subtraction	4.6%	0.9%
process — the full total	14.7%	5.5%

How to read this. The physical formulas are right to a few percent. C_overhead is not — the process tier differs from the tensors tier only by that one heuristic, and every bit of the extra error is there. Its fragmentation model assumes a flat 5%; measured fragmentation ran from 6% to 32%, and is worst under eager attention because transient score matrices churn the allocator pool. That is the next thing to fix.

Errors are signed as (predicted − measured) / measured, so a negative number means fitcheck predicted less than reality — the unsafe direction.

What these runs changed

They were not a rubber stamp. Three things in the activation formula were wrong, and each was found by measurement rather than by re-reading the derivation:

1. A_act summed the LM-head hump and the layer recompute. They never coexist — the FP32 logits are freed before the backward pass reaches a decoder layer — so the peak is a max, not a sum.
2. The checkpoint store was L·γbsh. Non-reentrant checkpointing keeps two hidden-state tensors per layer, not one, so it is 2L·γbsh.
3. The eager attention score matrix was billed once. It is materialized about nine times across forward and backward, including two FP32 softmax copies — 9γ, not γ.

Across the wider development set of twenty runs, worst-case error fell from 36.1% to 4.8%.

The third one was found by running the same config twice, changing only the attention kernel: the difference between the two peaks is the cost of the score matrix. On a T4 that meant using SDPA's memory-efficient backend, which — like Flash Attention — never builds the matrix, but unlike Flash Attention runs on pre-Ampere hardware.

A result worth knowing

Flash Attention often saves no memory at all under gradient checkpointing. The score matrix is transient inside one layer's recompute, and A_act takes the max of that against the LM-head hump. For a large-vocabulary model the LM head wins, so removing the matrix changes the peak by nothing — measured at 16 MiB out of 5,297 on SmolLM2, and exactly 0 MiB for the Llama-3.1-8B reference config. Flash still buys speed, and it starts buying memory once the sequence is long enough for the layer hump to overtake the LM head.

What is not measured

Be as clear about the gaps as about the results:

• Any GPU other than this T4. No Ampere or newer card, so no BF16 and no real FlashAttention-2 — the flash code path is validated only through SDPA's memory-efficient backend as a stand-in.
• Gradient checkpointing off. L × A_layer + A_logits is derived, never measured.
• --quant none, --quant int8, full fine-tuning, FP32 compute. Code paths with no measured row.
• Sequences beyond 2048, where the 9γ coefficient multiplies an s² term.
• fitcheck infer in full. Every measured row is a training run. The serving path (resident weights + KV cache) shares the weight formula, which is measured, but the cache term and the serving overhead constant have no measured row of their own.
• Every GPU entry except the T4. The T4 used to claim 15,360 MiB usable of 16,384 when the card actually reports 14,912 MiB total — vendor GB treated as GiB, unsafe direction — and is now corrected to its measured 14_912 / 14_000. It is the only row in gpu_db.py backed by a measurement. The rest are estimates, and h200 / b200 deliberately take the usable_mib that is safe under the pessimistic reading of their vendor GB until someone measures them.

Reproducing any of this needs one command:

python scripts/measure.py TinyLlama/TinyLlama-1.1B-Chat-v1.0 \
    --qlora --precision fp16 --lora-r 32 --batch-size 2 --seq-len 1024 --gpu t4

docs/SPEC.md §3.8 explains what the harness does and why each part of it matters.

---

How it works

Peak VRAM is modelled as W_base + W_lora + S_optim + G_grad + A_act + C_overhead, one module per term under fitcheck/memory/: base weights (only the transformer linears are packed under --quant — the embeddings, LM head and norms stay unquantized and get upcast to FP32, plus one FP32 NF4 scale per block of 64), LoRA adapters (r × (d_in + d_out) per target, with k_proj/v_proj narrowed to num_kv_heads × head_dim under GQA), optimizer states (trainable params only — 8 bytes/param for AdamW, whose states stay FP32 even when you train in BF16), gradients, activations, and CUDA overhead. estimator.py orchestrates the six and returns a MemoryReport.

Two dtype rules catch people out, and both come from the same peft call. On a quantized base, prepare_model_for_kbit_training upcasts everything trainable to FP32 — so QLoRA's adapters are FP32, not the bf16 you asked for, and the gradients follow them there. --precision is the compute dtype and drives activations; --quant is how the base is stored. They are separate axes on purpose.

Activations are the hard term and the one worth reading about. A_layer sums the twelve tensors autograd saves per decoder layer, plus the (b, n_h, s, s) attention score matrix when Flash Attention is off — billed at 9γ, because eager attention materializes it about nine times across forward and backward. A_logits is four FP32 copies of the (b, s, V) tensor, and for a large-vocabulary model it is usually the single biggest line in the whole budget.

Under gradient checkpointing the peak is not a sum of those:

A_act = 2L·γ·b·s·h  +  max(A_logits, A_layer)

Only the checkpoints are resident for the whole backward pass. The LM-head hump and one layer's recompute are both transient and never overlap, so the peak takes whichever is larger — adding them prices a moment that never happens. This is measured, not assumed, and getting it wrong is what made v0.1.1 under-predict by up to 36%.

max_batch_size is found by bisecting the whole estimator and flooring, never by extrapolating from one point: total(b) is piecewise linear, with a kink wherever that max flips branches.

Serving reuses the same weight term and adds one of its own: 2 · L · (n_kv × head_dim) · s · concurrent · bytes for the KV cache, GQA-narrowed like the rest. max_concurrent is found the same way max_batch_size is — by bisecting the whole estimate and flooring, not by dividing free space by the per-request cache. That shortcut over-counts, because C_overhead is a percentage of a total that itself grows with the cache.

See SPEC.md for the full memory model, and Blueprint.md for the derivations.

---

Contributing

Fork, branch off main, open a PR. Please keep changes to one memory component per PR where possible — the modules are deliberately independent so a formula can be argued about in isolation.

The bar for a merge:

• pytest --cov=fitcheck --cov-report=term-missing -m "not network" is green. Currently 331 offline tests, with 100% line coverage on all seven memory/ modules; ≥80% there is the floor. The -m "not network" filter is not optional: it skips the one test that fetches the gated meta-llama/Llama-3.1-8B for real, which fails without an HF_TOKEN. The offline tests cover the same parsing against a fixture.
• Any change to a formula updates its module, its test, and docs/SPEC.md in the same PR. The Llama-3.1-8B golden numbers in the SPEC appendix are the reference set — if a change moves them, say so explicitly in the PR description.
• Type hints and docstrings on public functions, dataclasses for configs, MiB returned as float. Linting and type checking aren't wired up yet; if you want to add ruff and mypy configs, that's a welcome PR on its own.

CONTRIBUTING.md has the full version, including the two non-negotiable constraints (no torch in the package, config.json only).

The most useful thing you can contribute right now is a measured row on hardware that is not a Tesla T4. Every number in the validation table comes from one card, which means BF16 and real FlashAttention-2 (both need sm_80 or newer) have never been exercised, and the 500 MiB CUDA-context constant has been checked exactly once. If you have an Ampere or newer GPU, one run of scripts/measure.py is worth more to this project than any feature — open it with the measurement issue template.

---

License

MIT. See LICENSE.
