flash-mineru 1.0.0

Fast Inference Architecture for MinerU

Flash-MinerU ⚡️📄

简体中文 | English

Accelerating the VLM Inference Pipeline of the open-source PDF parsing project MinerU with Ray

Flash-MinerU is a lightweight and low-intrusion acceleration project. Its goal is to leverage Ray’s parallel and distributed capabilities to parallelize and accelerate the most time-consuming stage in MinerU — the VLM (Vision-Language Model) inference stage — thereby significantly improving the overall throughput of PDF → Markdown processing.

This project is positioned as a parallelization and engineering accelerator, rather than a reimplementation of MinerU’s core algorithms. Its design goals include:

• Minimal dependencies, lightweight installation
  • One-click install & run via pip install flash-mineru
  • Tested in domestic computing environments such as METAX
• Maximum reuse of MinerU’s original logic and data structures
  • Preserving algorithmic behavior and output consistency
• Multi-GPU / multi-process / multi-cluster friendly
  • Designed for large-scale batch PDF processing, easy to scale up

---

✨ Features

• 🚀 Ray-based parallel inference
  PDF pages / images are sliced into batches and dispatched to multiple Ray actors for parallel execution

• 🧠 VLM inference acceleration
  Focuses on the VLM inference stage in MinerU; currently defaults to vLLM for high-throughput inference

• 🧩 Low-intrusion design
  Retains MinerU’s original intermediate structures (middle_json) and Markdown generation logic

---

🎯 How pipeline parallelism helps

MinerU’s PDF→Markdown path is a multi-stage pipeline (e.g. page rendering → VLM → Markdown). If every batch must finish all stages before the next batch starts, workers and GPUs wait on each other—that shows up as idle gaps (“bubbles”) on a timeline and under-used accelerators. Flash-MinerU (default MineruEngine) overlaps several logical batches across those stages: while one batch sits in VLM, another can be rendering or writing Markdown, so compute stays busier end-to-end without changing MinerU’s operators.

Left — bubble schedule (before) Per-batch serialization; visible GPU idle gaps.

Right — pipelined (Flash-MinerU) Overlapped batches; GPUs keep working.

---

📦 Installation

Basic installation (lightweight mode)

Suitable if you have already installed the inference backend manually (e.g., vLLM), or are using an image with a prebuilt environment:

pip install flash-mineru

Install with vLLM backend enabled (optional)

If you want Flash-MinerU to install vLLM as the inference backend for you:

pip install flash-mineru[vllm]

---

🚀 Quickstart

Minimal Python API example

from flash_mineru import MineruEngine

# Path to PDFs
pdfs = [
    "resnet.pdf",
    "yolo.pdf",
    "text2sql.pdf",
]

engine = MineruEngine(
    model="<path_to_local>/MinerU2.5-2509-1.2B",
    # Model can be downloaded from https://huggingface.co/opendatalab/MinerU2.5-2509-1.2B
    batch_size=2,              # PDFs per logical batch
    replicas=3,                # Parallel vLLM / model instances
    num_gpus_per_replica=0.5, # Fraction of GPU memory per instance (vLLM KV cache)
    save_dir="outputs_mineru", # Output directory for parsed results
    inflight=4,                # Pipeline parallelism depth (v1.0.0 default path; try 8 on large hosts)
)

# Legacy v0.0.4 sequential batching (deprecated): from flash_mineru import MineruEngineLegacy

results = engine.run(pdfs)
print(results)  # list[list[str]], dir name of the output files

Output structure

• Each PDF’s parsing results will be generated under:

  <save_dir>/<pdf_name>/


• The Markdown file is located by default at:

  <save_dir>/<pdf_name>/vlm/<pdf_name>.md


---

📊 Benchmark

Scripts: English · 简体中文

Results (368 PDFs, ~8× A100 class machine)

Method	Inference configuration	Total time
Flash-MinerU v1.0.0	MineruEngine, 8 replicas, inflight 8	~8.5 min
MinerU (vanilla)	Eight hand-spawned mineru processes (this repo’s Benchmark-mineru.py parallel mode, one GPU per process, vlm-auto-engine)	~14 min
Flash-MinerU v0.0.4	MineruEngineLegacy, 8 replicas × 1 GPU, batch size 16	~23 min
MinerU (vanilla)	vLLM, single GPU	~65 min

Commands: docs/BENCHMARK.md.

Summary

• v1.0.0 is about ~1.7× faster wall time than the eight-process baseline (~8.5 min vs ~14 min)
• v0.0.4 (MineruEngineLegacy) is slower than that baseline (~23 min), which highlights what pipeline parallelism adds versus “many full stacks in parallel”
• ~65 min single-GPU is the same-corpus reference baseline

Experimental setup (expand)

• Dataset: 23 paper PDFs (≈9–37 pages each) × 16 copies → 368 files; default folder test/sample_pdfs
• Versions: MinerU v2.7.5; Flash-MinerU v0.0.4 = MineruEngineLegacy (sequential stages per batch); v1.0.0 = MineruEngine (pipeline parallelism, default API)
• Hardware: single host, 8 × NVIDIA A100

Note: Throughput-focused. Output shape matches MinerU. Upstream does not ship a polished official multi-GPU “one click” path; the eight-process row is our benchmark script sharding eight separate mineru runs.

---

🗺️ Roadmap

• Benchmark scripts & docs — docs/BENCHMARK.md
• Support for more inference backends (e.g., sglang)
• Service-oriented deployment (HTTP API / task queue)
• Sample datasets and more comprehensive documentation

---

🤝 Acknowledgements

• MinerU This project is built upon MinerU’s overall algorithm design and engineering practices, and parallelizes its VLM inference pipeline. The mineru_core/ directory contains code logic copied from and adapted to the MinerU project. We extend our sincere respect and gratitude to the original authors and all contributors of MinerU. 🔗 Official repository / homepage: https://github.com/opendatalab/MinerU

• Ray Provides powerful abstractions for distributed and parallel computing, making multi-GPU and multi-process orchestration simpler and more reliable. 🔗 Official website: https://www.ray.io/ 🔗 Official GitHub: https://github.com/ray-project/ray

• vLLM Provides a high-throughput, production-ready inference engine (currently the default backend). 🔗 Official website: https://vllm.ai/ 🔗 Official GitHub: https://github.com/vllm-project/vllm

---

📜 License

AGPL-3.0

Notes: The mineru_core/ directory in this project contains derivative code based on MinerU (AGPL-3.0). In accordance with the AGPL-3.0 license requirements, this repository as a whole is released under AGPL-3.0 as a derivative work. For details, please refer to the root LICENSE file and mineru_core/README.md.
