flask-s3-viewer 1.3.0

Flask S3 Viewer is a powerful extension that makes it easy to browse S3 in any Flask application.

Flask S3 Viewer

Browse, upload, and manage Amazon S3 buckets from any Flask application.

v1.0 is a major rewrite. Modern UI (Tailwind + HTMX, dark mode), Flask 3 support, hardened path-traversal defenses, Flask extension pattern, type hints, pytest + moto test suite, GitHub Actions CI. See migration guide if upgrading from 0.x.

Highlights

• Modern UI — Tailwind CSS, HTMX-driven partial updates, light/dark mode, inline heroicons. Parent-folder (..) row and logged-in user widget in the header. No build pipeline required for end users (CSS ships pre-built).
• Optional auth — Hook framework (auth_callback + permission_callback with per-action constants) plus built-in Google OAuth via the [auth] extra. Auth routes (/auth/{login,callback,logout}) live outside the namespace prefix so one redirect URI covers every viewer on the app.
• Smart search — Case-insensitive substring match, Unicode-safe (Korean / Japanese / accented Latin), NFC-normalised so macOS uploads match the browser IME, scoped to the current folder, and surfaces matching child folder rows.
• Secure by default — Rejects path-traversal tokens (.., ., //, \) at every prefix boundary. Cache directory escape blocked by realpath containment, and cache files are stored as JSON with restrictive file permissions.
• Flask extension pattern — FlaskS3Viewer(app, namespace=...) auto-registers. Supports multiple buckets per app via add_new_one(...). Works with init_app(app) for deferred binding.
• Multi-bucket — Independent namespaces, optional per-bucket CloudFront / external object_hostname.
• Presigned uploads — Multi-file presigned POST flow for large files; default form upload also supported.
• Caching — File-system JSON cache with TTL; automatically invalidated on writes (search bypasses the cache, and authenticated listings are user-isolated).
• Tested — 203 pytest cases, ruff + mypy clean, moto-based S3 mock.

Installation

pip install flask_s3_viewer

Requires Python 3.10+, Flask 3.0+, boto3 1.34+.

Quick start

from flask import Flask
from flask_s3_viewer import FlaskS3Viewer
from flask_s3_viewer.aws.ref import Region

app = Flask(__name__)

# Auto-register. No `register()` call needed.
FlaskS3Viewer(
    app,
    namespace="my-bucket",
    object_hostname="https://cdn.example.com",  # optional CloudFront host
    config={
        "profile_name": "default",
        "region_name": Region.SEOUL.value,
        "bucket_name": "my-bucket",
        "cache_dir": "/tmp/flask_s3_viewer",
        "use_cache": True,
        "ttl": 86400,
    },
)

@app.route("/")
def index():
    return "App index"

if __name__ == "__main__":
    app.run(debug=True, port=3000)

Visit http://localhost:3000/my-bucket/files to browse the bucket.

Branding (title + logo)

FlaskS3Viewer(
    app,
    namespace="my-bucket",
    title="ACME File Vault",
    logo_path="/opt/acme/assets/logo.svg",   # local file, auto inlined as a data: URI
    # or: logo_url="https://cdn.acme.io/logo.svg",
    logo_link_url="https://intranet.acme.io/dashboard",  # optional (v1.3+)
    config={...},
)

logo_path reads the file once at construction time and embeds it as a data: URI so you don't need a separate static route. logo_url accepts any browser-resolvable URL (CDN, url_for("static", filename=...), etc.). logo_path takes precedence.

logo_link_url (v1.3+) overrides the click target of the header logo + title anchor. When set, the anchor renders as a plain <a href="..."> pointing at the configured URL and the default HTMX listing reset is disabled — useful when the brand mark should return users to an external dashboard / home page. Omit to keep the v1.2 in-place HTMX swap. With add_new_one, omit to inherit the parent value, pass None to drop the parent's override on a child namespace, or pass a different string to override per namespace.

Customizing templates (template_folder)

Scaffold a writable copy of the bundled templates with the CLI, edit, then point the viewer at that folder:

# Templates only (default — covers most theming needs)
flask_s3_viewer -p ./fsv-templates

# Or, fork the entire UI bundle (templates + static/css/app.css + htmx + core.js)
flask_s3_viewer -p ./fsv-templates --with-static

FlaskS3Viewer(
    app,
    namespace="my-bucket",
    template_folder="./fsv-templates",   # files here win over bundled defaults
    config={...},
)

Behind the scenes the extension prepends a FileSystemLoader(template_folder) to the app's Jinja loader via ChoiceLoader, so any not-overridden template (e.g. error.html when you only edited files.html) still resolves against the bundle. Other blueprints' template resolution is untouched.

Multiple buckets

viewer = FlaskS3Viewer(app, namespace="primary", config={...})
viewer.add_new_one(namespace="backups", config={...})

Each namespace gets its own URL prefix and its own configuration.

Deferred initialization

viewer = FlaskS3Viewer(namespace="my-bucket", config={...})

def create_app():
    app = Flask(__name__)
    viewer.init_app(app)
    return app

Accessing the underlying boto3 client

from flask import current_app
from flask_s3_viewer import FlaskS3Viewer

# Inside a request:
client = current_app.extensions["flask_s3_viewer"]["my-bucket"]._s3

# Or via the helper:
client = FlaskS3Viewer.get_boto_client(app, "my-bucket")
session = FlaskS3Viewer.get_boto_session(app, "my-bucket")

Configuration

All config keys are forwarded to the underlying S3 client:

Key	Type	Default	Notes
bucket_name	str	—	Required.
profile_name	str | None	None	Uses boto3 default credential chain if None.
region_name	str | None	None	e.g. ap-northeast-2.
endpoint_url	str | None	None	Custom S3 endpoint (MinIO, etc.).
access_key	str | None	None	Prefer profiles / IAM roles.
secret_key	str | None	None
session_token	str | None	None
verify	bool | str	False	TLS verify (or path to CA bundle).
base_path	str	""	Object key prefix scope for this viewer.
use_cache	bool	False	File-system JSON cache.
cache_dir	str | None	None	Required when use_cache=True.
ttl	int (seconds)	300	Cache time-to-live.
timezone	str | None	None	IANA timezone for Modified display, e.g. Asia/Seoul. If None, boto3's original timestamp string is shown.
role_arn	str | None	None	If set, the wrapper runs STS AssumeRole on top of the base credentials and uses the returned temporary keys (cross-account, multi-tenant).
role_session_name	str | None	"flask-s3-viewer"	Identifier for the assumed session.
external_id	str | None	None	Forwarded to STS for cross-account roles that require it.
duration_seconds	int | None	None	Lifetime of the assumed credentials in seconds (15 min – 12 h).
mfa_serial	str | None	None	MFA device ARN/serial for STS AssumeRole.
token_code	str | None	None	One-time MFA code (paired with mfa_serial).
token_code_callback	callable	None	Alternative to token_code — called once to prompt the user.

Constructor options:

Option	Notes
app	Flask app (optional; pass later via init_app(app)).
namespace	Unique per app. Becomes the URL prefix.
object_hostname	External link prefix (e.g. CloudFront).
allowed_extensions	set[str] | None — only allow these uploads.
upload_type	"default" (multipart form post) or "presign".
title	Heading + browser tab title text. Default "Flask S3 Viewer".
logo_url	URL of a custom logo image (absolute, url_for(...), or /static/...).
logo_path	Local filesystem path to a logo image — auto-inlined as a data: URI. Takes precedence over logo_url.
logo_link_url	(v1.3+) Overrides the header logo + title anchor click target. When set, replaces the default HTMX listing reset with standard navigation.
template_folder	Directory whose Jinja files override the bundled templates (Flask ChoiceLoader pattern). Seed it via the CLI scaffold.

AWS authentication

flask-s3-viewer defers to boto3's default credential chain, so these all work out of the box:

• Static keys (access_key / secret_key / session_token)
• Named profile (profile_name='my-profile') — including profiles with role_arn + source_profile in ~/.aws/config (boto3 handles AssumeRole automatically)
• AWS_* environment variables
• EC2 IMDS / ECS task role / AWS SSO cache / EKS IRSA (Web Identity OIDC) — picked up automatically when nothing else is set.

For workflows that need explicit STS AssumeRole (cross-account, multi-tenant, ad-hoc role delegation from a base credential), pass role_arn in the config:

FlaskS3Viewer(
    app,
    namespace="cross-account",
    config={
        "bucket_name": "target-bucket",
        "region_name": "us-east-1",
        # Base credentials come from the default chain (profile/env/IRSA).
        "role_arn": "arn:aws:iam::123456789012:role/AppRole",
        "external_id": "shared-secret",          # optional
        "role_session_name": "my-app",           # default: "flask-s3-viewer"
        "duration_seconds": 3600,                # 15 min – 12 h
    },
)

For MFA-protected roles, supply a token (or a callback for interactive prompting):

FlaskS3Viewer(
    app,
    namespace="mfa-account",
    config={
        "bucket_name": "secure-bucket",
        "region_name": "us-east-1",
        "role_arn": "arn:aws:iam::123456789012:role/AdminRole",
        "mfa_serial": "arn:aws:iam::123456789012:mfa/alice",
        "token_code_callback": lambda: input("MFA code: ").strip(),
    },
)

Authentication & permissions

flask-s3-viewer ships with two opt-in layers. The package works exactly as before with no auth wiring — both default to "allow everyone".

Layer 1: hook framework (no extra dependency)

Plug in your existing login system with two callables:

from flask_s3_viewer.auth import ACTION_LIST, ACTION_UPLOAD, ACTION_DELETE

def who_is_asking(request):
    """Return the user's email (or any opaque id) — None means anonymous."""
    return request.headers.get("X-Forwarded-Email")

def can_they(email, action, namespace, key):
    """Authorize a single action. action is one of the ACTION_* constants."""
    if action == ACTION_DELETE:
        return email.endswith("@admin.example.com")
    return True

FlaskS3Viewer(
    app, namespace="bucket",
    auth_callback=who_is_asking,
    permission_callback=can_they,
    config={...},
)

The five action constants are ACTION_LIST, ACTION_DOWNLOAD, ACTION_UPLOAD, ACTION_DELETE, ACTION_PRESIGN.

RBAC bucket switcher

For multi-bucket apps, keep hard authorization in permission_callback and use visible_namespaces_callback(email, registry) to control which buckets appear in the header switcher:

RBAC = {
    "[e-mail]": {"assets", "private"},
    "[e-mail]": {"assets"},
}

def visible_buckets(email, registry):
    return RBAC.get(email, set())

def can_they(email, action, namespace, key):
    return namespace in RBAC.get(email, set())

viewer = FlaskS3Viewer(
    app,
    namespace="assets",
    title="Assets",
    auth_callback=who_is_asking,
    permission_callback=can_they,
    visible_namespaces_callback=visible_buckets,
    config={...},
)

viewer.add_new_one(
    namespace="private",
    title="Private",
    config={...},
)

The switcher only hides inaccessible namespaces from the UI. Direct URL access is still checked by permission_callback, so RBAC remains server-side.

Layer 2: built-in Google OAuth (optional [auth] extra)

pip install "flask_s3_viewer[auth]"

app.secret_key = "..."  # required — signs the session cookie

FlaskS3Viewer(
    app, namespace="bucket",
    google_client_id="...apps.googleusercontent.com",
    google_client_secret="...",
    allowed_emails=["[e-mail]"],
    allowed_domains=["example.com"],
    config={...},
)

Installs /auth/login, /auth/callback, /auth/logout as app-level routes (outside the FlaskS3Viewer namespace prefix). Configure the redirect URI as https://<host>/auth/callback in Google Cloud Console — one URI per app even when you mount multiple namespaces. Anonymous browser visits to a protected page are redirected through Google sign-in automatically.

Mix and match: pass your own auth_callback / permission_callback even when Google is enabled, or use email_allowlist() as a permission builder for non-Google deployments.

Security

• Path traversal hardening — Every user-supplied prefix is validated. Tokens .., ., empty segments, and \ are rejected with HTTP 400.
• Defense in depth — The cache layer additionally enforces realpath containment, preventing any path that would resolve outside cache_dir.
• Subresource Integrity — Bundled htmx.min.js references its sha384 hash; the Tailwind output is shipped pre-built and signed by the package.
• Credentials — Never log credentials. Prefer named profiles or instance roles over hard-coded keys.

Development

The frontend assets are pre-built and committed to the repo. To rebuild after editing templates:

cd frontend
npm install
npm run build       # writes flask_s3_viewer/blueprints/static/css/app.css

CI verifies the CSS is up to date (git diff --exit-code).

Tests:

pip install -e ".[dev]"
ruff check flask_s3_viewer/ tests/
mypy flask_s3_viewer/
pytest tests/ --cov=flask_s3_viewer

Migrating from 0.x

See MIGRATION.md for the full guide. Highlights:

• Drop s3viewer.register() — the constructor now auto-registers.
• FlaskS3Viewer.get_instance(ns) → FlaskS3Viewer.get_instance(app, ns) (same for get_boto_client, get_boto_session).
• Duplicate namespace registration now raises ValueError instead of silently reusing.
• Unknown namespaces return HTTP 404 instead of 500.
• Single template namespace — template_namespace="base"|"mdl" is ignored with a deprecation warning.
• CLI --template option removed.
• Path-traversal tokens in prefix now return HTTP 400.
• Requires Flask 3.0+ and boto3 1.34+.

License

MIT © Hoiwoong Jung
