flexiflow 1.0.1

A small async component engine with events, state machines, and a minimal CLI.

日本語 | 中文 | Español | Français | हिन्दी | Italiano | Português (BR)

A lightweight async component engine with events, state machines, and a minimal CLI.

A small async component engine with events, state machines, and a minimal CLI.

---

Why FlexiFlow?

Most workflow engines are heavyweight, opinionated, and assume you want a DAG runner. FlexiFlow is none of those things. It gives you:

• Components with declarative rules and pluggable state machines
• An async event bus with priority, filters, and sequential or concurrent delivery
• Structured logging with correlation IDs baked in
• Persistence (JSON for dev, SQLite for production) with snapshot history and pruning
• A minimal CLI so you can demo and debug without writing a harness
• Config introspection (explain()) to validate before you run

All in under 2,000 lines of pure Python. No heavy dependencies. No magic.

---

Install

pip install flexiflow

With optional extras:

pip install flexiflow[reload]   # hot-reload with watchfiles
pip install flexiflow[api]      # FastAPI integration
pip install flexiflow[dev]      # pytest + coverage

---

Quick Start

CLI

# Register a component and start it
flexiflow register --config examples/config.yaml --start

# Send messages through the state machine
flexiflow handle --config examples/config.yaml confirm --content confirmed
flexiflow handle --config examples/config.yaml complete

# Hot-swap rules at runtime
flexiflow update_rules --config examples/config.yaml examples/new_rules.yaml

Embedded (Python)

from flexiflow.engine import FlexiFlowEngine
from flexiflow.config_loader import ConfigLoader

config = ConfigLoader.load_component_config("config.yaml")
engine = FlexiFlowEngine()

# Register and interact
component = engine.create_component(config)
await engine.handle_message(component.name, "start")
await engine.handle_message(component.name, "confirm", content="confirmed")

You can also set FLEXIFLOW_CONFIG=/path/to/config.yaml and omit --config from the CLI.

---

API Overview

Event Bus

# Subscribe with priority (1=highest, 5=lowest)
handle = await bus.subscribe("my.event", "my_component", handler, priority=2)

# Publish with delivery mode
await bus.publish("my.event", data, delivery="sequential")   # ordered
await bus.publish("my.event", data, delivery="concurrent")    # parallel

# Cleanup
bus.unsubscribe(handle)
bus.unsubscribe_all("my_component")

Error policies: continue (log and keep going) or raise (fail fast).

State Machines

Built-in message types: start, confirm, cancel, complete, error, acknowledge.

Load custom states via dotted paths:

initial_state: "mypkg.states:MyInitialState"

Or register entire state packs:

states:
  InitialState: "mypkg.states:InitialState"
  Processing: "mypkg.states:ProcessingState"
  Complete: "mypkg.states:CompleteState"
initial_state: InitialState

Observability Events

Event	When	Payload
engine.component.registered	Component registered	{component}
component.message.received	Message received	{component, message}
state.changed	State transition	{component, from_state, to_state}
event.handler.failed	Handler exception (continue mode)	{event_name, component_name, exception}

Retry Decorator

from flexiflow.extras.retry import retry_async, RetryConfig

@retry_async(RetryConfig(max_attempts=3, base_delay=0.2, jitter=0.2))
async def my_handler(data):
    ...

Persistence

Feature	JSON	SQLite
History	Overwrites	Appends
Retention	N/A	prune_snapshots_sqlite()
Best for	Dev/debugging	Production

from flexiflow.extras import save_component, load_snapshot, restore_component

# JSON: save and restore
save_component(component, "state.json")
snapshot = load_snapshot("state.json")
restored = restore_component(snapshot, engine)

import sqlite3
from flexiflow.extras import save_snapshot_sqlite, load_latest_snapshot_sqlite

conn = sqlite3.connect("state.db")
save_snapshot_sqlite(conn, snapshot)
latest = load_latest_snapshot_sqlite(conn, "my_component")

Config Introspection

from flexiflow import explain

result = explain("config.yaml")
if result.is_valid:
    print(result.format())

---

Error Handling

All exceptions inherit from FlexiFlowError with structured messages (What / Why / Fix / Context):

FlexiFlowError (base)
├── ConfigError      # Configuration validation failures
├── StateError       # State registry/machine errors
├── PersistenceError # JSON/SQLite persistence errors
└── ImportError_     # Dotted path import failures

from flexiflow import FlexiFlowError, StateError

try:
    sm = StateMachine.from_name("BadState")
except StateError as e:
    print(e)  # includes What, Why, Fix, and Context

---

Examples

See examples/embedded_app/ for a complete working example with custom states, SQLite persistence, observability subscriptions, and retention pruning.

---

Security & Data Scope

FlexiFlow is a local-first async component engine library.

• Data accessed: In-process state machine data, optional SQLite persistence for state history
• Data NOT accessed: No cloud sync. No telemetry. No analytics. No network calls. No authentication
• Permissions: File system write only for optional SQLite persistence. No elevated permissions

Full policy: SECURITY.md

---

Scorecard

Category	Score
A. Security	10/10
B. Error Handling	10/10
C. Operator Docs	10/10
D. Shipping Hygiene	10/10
E. Identity (soft)	10/10
Overall	50/50

---

License

MIT -- Copyright (c) 2025-2026 mcp-tool-shop

---

Built by MCP Tool Shop
