FlexPosit: Tunable Fractional Precision for LLM Inference Accelerators (MICRO 2026)

FlexPosit received all three MICRO 2026 artifact badges. To reproduce the paper's results exactly, use FlexPosit_artifact.

FlexPosit is a Posit-based mixed-precision quantization framework for LLMs. It allocates higher precision to the channel windows whose quantization most affects perplexity. The paper tunes precision by combining Posit(4,1) and Posit(5,1) across channel windows; other Posit formats can be selected through the configuration. This repo contains:

• flexposit, a Python package for quantizing HuggingFace models with FlexPosit.
• hardware/, the RTL of the FlexPosit datapath, part of the test-chip version of FlexPosit in an ongoing 12 nm tapeout shuttle.

Install

pip install flexposit               # Python >= 3.10; includes WikiText-2 perplexity
pip install "flexposit[eval]"       # optional: adds lm-evaluation-harness for downstream tasks (ARC, HellaSwag, ...)

For the command-line scripts and the hardware, clone the repo and install it in editable mode instead:

git clone https://github.com/hplp/FlexPosit && cd FlexPosit
pip install -e ".[dev]"

Quick start

Use the Python API to quantize a model from your own code: load it, quantize it to a target average bit width, then evaluate or save it. For example, Mistral-7B at 4.4 bits:

import flexposit

model, tok = flexposit.load_model("mistral-7b")          # preset name, HF id or local path

# 4.4 bits on average, using the sensitivity ranking shipped for this model
# (uniform Posit(4,1) is bits=4.0 and needs no sensitivity)
state = flexposit.quantize(model, flexposit.FlexPositConfig(bits=4.4), sensitivity="mistral-7b")

print(flexposit.wikitext2_perplexity(model, tok))        # WikiText-2, seqlen 2048
flexposit.eval.lm_eval(model, tok, ["arc_easy"])         # any lm-eval task
flexposit.save(model, tok, state, "out/mistral-7b-flexposit-4.4")

quantize rounds each weight to its channel's Posit format in place, so the model runs anywhere a HuggingFace model runs; state records each channel's Posit size and scale. To sweep many bit widths, use the command line below.

Command line

The scripts run the paper's workflow from the shell: quantize every weight to Posit(4,1), then sweep the average bit width from 4.0 to 5.0 and record WikiText-2 perplexity at each step. Results go to out/.

bash scripts/01_quantize_base.sh phi-2   # quantize weights to Posit(4,1)
bash scripts/02_mpq_sweep.sh    phi-2    # mixed-precision sweep over 4.0–5.0 bits

The shipped sensitivity CSVs hold the PPL-based sensitivity used in the paper. You can also profile your own, with a different configuration (e.g. the channel-window size, i.e. the granularity) or a different method (a Fisher-based one is provided). See docs/cli.md for these options and the tests.

Hardware

hardware/ holds the RTL of a bit-serial FlexPosit accelerator whose Posit precision (4–8 bits) changes per channel window at runtime.

sudo apt install iverilog   # or on macOS: brew install icarus-verilog
pip install numpy           # used by the Python reference model
cd hardware && make test

make test (about a minute) simulates the RTL and checks it bit for bit against a Python model: every FP8 × Posit product on a single PE, then random matrix tiles through the whole array.

Supported models

Each has a pre-computed sensitivity CSV bundled with the package (flexposit.shipped_sensitivity()); the CLIs and the Python API accept the short names, both for the model and for sensitivity=.

Layout

src/flexposit/       Python package (API, quantizers, mixed precision, sensitivity)
src/flexposit/data/  sensitivity CSVs for the supported models
scripts/             shell wrappers for the command-line workflow
hardware/            RTL, testbenches and bit-exact model
docs/cli.md          command-line guide
tests/               test suite

Development

pip install -e ".[dev]"
ruff check src tests
pytest                     # CPU, a few seconds, no downloads
make -C hardware test      # RTL regression, needs Icarus Verilog

Issues and pull requests are welcome.

Paper & citation

Preprint (arXiv): https://arxiv.org/abs/2609.04724

@misc{gao2026flexposit,
  title         = {FlexPosit: Tunable Fractional Precision for LLM Inference Accelerators},
  author        = {Gao, Yimin and Dai, Liangtao and Yin, Jun and Guo, Xinfei and Stan, Mircea},
  year          = {2026},
  eprint        = {2609.04724},
  archivePrefix = {arXiv},
  primaryClass  = {cs.AR},
  doi           = {10.48550/arXiv.2609.04724}
}

License

MIT; see LICENSE.

Contact

Yimin Gao yg9bq@virginia.edu
