flux3-mlx

FLUX 3 Image Klein on Apple Silicon. Text-to-image, editing with up to 10 reference images and bounding-box layout, in MLX, validated against Black Forest Labs' reference implementation.

pip install "flux3-mlx[pup] @ git+https://github.com/felix-ab/flux3-mlx"
flux3-mlx "a ceramicist's studio at golden hour, shelves of glazed bowls" --upsample --out studio.png

On first use, the weights download from the Hugging Face Hub, with no account or gating needed. By downloading them you agree to the FLUX Kommunity License.

Models

Each model repo bundles the transformer, the Qwen3-VL-4B text encoder (8-bit) and the VAE. There is no 4-bit model on purpose. In our tests, 4-bit added 5–23% high-frequency grain and changed design details (see Validation), so it does not meet the bar for this release.

Usage

# text-to-image; long, fully described prompts work best, or let the upsampler write one
flux3-mlx "Full-color photograph, ..." --width 1216 --height 832 --seed 7 --out a.png
flux3-mlx "a red bicycle in the rain" --upsample --out b.png

# edit: the first reference sets the output size
flux3-mlx "put a red bandana around the dog's neck" --image dog.png --upsample --out edit.png

# combine up to 10 references
flux3-mlx "the woman from the first image wearing the jacket from the second" --image a.png --image b.png --upsample

# layout with bounding boxes ([y_min, x_min, y_max, x_max] in 0-1)
flux3-mlx "hot-air balloons over a green valley at sunrise" --boxes boxes.json --upsample

from flux3_mlx import Flux3Klein

pipe = Flux3Klein.from_pretrained("8bit", upsampler="4bit")
image, record = pipe("a ceramicist's studio at golden hour", seed=3)
image.save("studio.png")

Every image gets a .json record next to it: final prompt, seed, size, steps, time and peak memory. Seeds are compatible with the BFL reference: the same seed gives the same starting noise as torch.randn on the CPU, so reference outputs can be reproduced on a Mac.

Performance (M4 Pro, 20-core GPU, 48 GB)

At 1 MP the model is compute-bound, so quantization buys memory, not speed. Klein's distilled checkpoint needs 16 steps. Do not lower the step count to save time: at 4 steps the output is visibly under-denoised and grainy, in BFL's own code too.

Validation

All comparisons are against BFL's reference code (45e57c9) and BFL's published example outputs.

• Text encoder: same chat template and token ids. Hidden-state cosine is ≥ 0.9999 (mean) at all 8 tapped layers.

• VAE: encode and decode match the reference (cos 1.000000).

• Transformer: per-step velocity cos 0.9999 (text-to-image and edit).

• End to end, BFL man_dog (1024², seed 7): BF16 port vs BFL's published B200 image is 35.9 dB, visually indistinguishable. 8-bit is 34.2 dB.

• Edit and layout examples (6-bit): 3_bandana 45.5 dB, balloons 35.4 dB vs BFL's images.

• Quantization study (5 cases, texture = high-frequency energy relative to BF16, 1.00 = identical):

  DiT	Texture	Verdict
  8-bit	0.99	shipped
  6-bit	1.00	shipped
  5-bit	0.95	blurs
  4-bit (g32 / g64 / mixed)	1.05–1.18	grain, design changes

Memory: the VAE runs its convolutions in row strips with a one-row halo, over global GroupNorm statistics, and its attention in query chunks. The output is identical to the full-tensor computation, but a 1024² decode needs 3.9 GB instead of 14 GB, and a 4 MP edit reference can be encoded in 8 GB.

Licenses

• This code: Apache-2.0. It is a port of black-forest-labs/flux-3-image-klein (Apache-2.0); see NOTICE.
• FLUX 3 Image Klein weights, including these MLX conversions: FLUX Kommunity License. Non-commercial use; commercial use of outputs is limited to Qualifying Users (under US$5M revenue) and comes with content-filtering and AI-disclosure duties.
• Qwen3-VL-4B text encoder and prompt upsampler: Apache-2.0.

This is an independent community port. It is not affiliated with or endorsed by Black Forest Labs.
