fluxim-cs 1.0.3

A python library to control the Characterization Suite software (CS 4.5+).

A python library to control the Characterization Suite software (CS 4.5+).

---

What's New in 1.0

• Control of the Litos Chamber temperature
• Control of the Litos Chamber illumination
• Wait for a specific Chamber/Pixel Status
• Stop the Chamber/Pixel stress

Installation

pip install fluxim-cs

Requirements: Python 3.10+ and Fluxim Characterization Suite software (4.5.1+)

Quick Start

All the examples can be found in this directory.

import fluxim_cs.litos as litos
import time
#In this example different temperatures (temperature_list) are sequentially applied to some chambers (chambers_list).
#Once the target temperature is reached an intermediate JV measurement is performed on defined pixels (pixels_list) after a waiting time (settling_time). When the pixels are back in a stressing state the next temperature is set. At the end the chambers are stopped.


if __name__ == "__main__":
    temperature_list=[20,30,40,50,60,70,20]     #list of target temperatures in °C
    chambers_list=["CH1"]                       #list of chambers to which the temperatures are applied
    pixels_list=["CH1.Px1"]                     #list of pixels on which the intermediate measurement is performed
    settling_time=30                            #waiting time after temperature is reached in seconds


    for setT in temperature_list:
        #apply target temperature
        print("Set Temperature" + litos.set_temperature(setT, chambers_list))
        print("Enable Temperature" + litos.enable_temperature(True, chambers_list))
        time.sleep(2)

        #wait for chamber to reach target temperature
        litos.wait_for_status(chambers_list,["Setpoint Reached"])
        print("Setpoint Reached. Apply waiting time:"+str(settling_time))
        time.sleep(settling_time)

        #Start intermediate Measurement
        print("Start Intermediate Meas")
        print(litos.start_intermediate_measurement(pixels_chambers=pixels_list, measurement="JV"))
        litos.wait_for_status(pixels_list,["Constant Voltage","Constant Current","MPP-Tracking"])
        time.sleep(4)


    #Routine finished -> Stop Stressing
    litos.stop_stressing(chambers_list)
    print("Chamber stopped: "+str(chambers_list))

License

This project is licensed under the MIT License.
