Forge Doctor API

Deterministic, offline-first, evidence-first engine for API architecture intelligence.

Forge Doctor ("the Doctor") inspects API projects — contracts, source code, configuration, and exported runtime artifacts — and produces structured, evidence-bearing findings. It never calls a model, never fetches a URL, and never guesses: anything it cannot establish from local evidence is surfaced as an explicit UnknownFact.

Status: 0.2.0 — the full deterministic surface is implemented (scan, diff, diagnose, inventory, lab, handoff). This is not a stable public API commitment; interfaces may still change before 1.0.

Design principles

The Doctor is the deterministic half of the Forge product family: it observes and classifies. Agentic code generation lives in api-forge (a separate project); this repository has no dependency on it.

Installation

pip install forge-doctor-api            # from PyPI — Python >= 3.11
pip install 'forge-doctor-api[graphql]' # optional: graphql-core for GraphQL parsing

From a checkout (development):

pip install .            # runtime deps: typer, rich, pyyaml
pip install .[graphql]   # optional: graphql-core for GraphQL parsing

Requirements: Python >= 3.11. For development:

pip install pytest ruff mypy types-PyYAML build
python -m pytest -q
python -m ruff check .
python -m mypy src

Portable install (Forge contract)

The checkout also carries the Forge family's portable-installation contract — clone once, setup once:

./setup.sh          # or .\setup.ps1 — venv + wheel + ~/.forge registry

Installing the Forge into a consumer project (managed .mcp.json key + AGENTS.md marker block, sha256-ledgered) is deliberately a checkout script, not a forge-doctor-api verb: the package boundary bans os/subprocess imports across src/ and the 0.2.0 RC window forbids new CLI commands. Same verbs, same receipts as sibling forges:

python scripts/forge_install.py install --dry-run   # plan only
python scripts/forge_install.py install --yes       # apply to a repo
python scripts/forge_install.py status|doctor|repair
python scripts/forge_install.py uninstall [--purge]
python scripts/forge_install.py update|mcp-verify

# Optional local web UI over the same real services (127.0.0.1, session token)
python scripts/forge_portal.py [--no-browser] [--port N] [--root DIR]

theforge install auto delegates here automatically via the install_command field in forge.json.

Quickstart

# Full deterministic scan of a project directory
forge-doctor-api scan ./my-service

# Scan + CI gate: fail on new breaking changes vs a baseline contract
forge-doctor-api scan ./my-service --fail-on breaking --baseline ./last-release

# Emit SARIF for GitHub code scanning, or a compact agent-readable format
forge-doctor-api scan . --format sarif --out results.sarif
forge-doctor-api scan . --format agent

Exit codes: 0 scan ran and gate passed · 1 gate failed · 2 usage/misconfiguration error.

Command tour

forge-doctor-api scan TARGET        all pipelines + optional §178 gate
forge-doctor-api inventory TARGET   fleet answers over a workspace or repo
forge-doctor-api diff OLD NEW       semantic contract diff + typed events
forge-doctor-api diff OLD NEW --pr  + PR-intel summary and blast radius
forge-doctor-api fingerprint FILE   semantic fingerprint of a contract
forge-doctor-api graph TARGET       merged contract/route/client graph
forge-doctor-api blast-radius O N   operation → clients → services impact
forge-doctor-api diagnose TARGET    root-cause episodes from evidence
forge-doctor-api explain DIR TOKEN  evidence chain for one finding
forge-doctor-api lab [labs]         Forge Lab corpus: precision/recall
forge-doctor-api contract diff O N  contract-level diff
forge-doctor-api contract compat …  compatibility classification
forge-doctor-api runtime requests   per-request execution table
forge-doctor-api runtime baseline   performance baselines per endpoint
forge-doctor-api runtime regress…   regressions vs baseline
forge-doctor-api security inspect   passive security evidence + findings
forge-doctor-api reliability inspect  timeouts/retries/idempotency/SLOs
forge-doctor-api reliability path     hop-by-hop effective policy

--help on any command lists its options. See docs/cli.md for the full reference.

What it understands

• Contracts: OpenAPI 3.x (YAML/JSON), AsyncAPI, GraphQL SDL + introspection, gRPC .proto.
• Source: FastAPI route discovery, client call-site extraction (Python/JS/TS), GraphQL client queries (gql tagged literals).
• Config: timeouts, retries, rate limits, idempotency headers, authentication/CORS/mTLS/TLS evidence, gateway routes, ownership files, policy files.
• Runtime: OTLP/OTEL JSON traces, access-log records — ingested as compact per-request summaries (raw spans are not retained).

From those inputs it produces: OAS/ASYNC/GQL/GRPC contract checks, contract-drift and semantic compatibility diffs, client impact and blast radius, versioning/deprecation analysis, observability + performance regression findings, reliability checks (retry amplification, SLO budgets), passive OWASP API Top-10 candidates, policy violations, an API digital twin, root-cause diagnosis, safe-fix classification, multi-repo workspace analysis, fleet intelligence, migration portability assessments, and compact handoff bundles for agentic tools.

Documentation

• docs/architecture.md — pipeline layout, models, determinism contract
• docs/cli.md — every command, option, and exit code
• docs/output-formats.md — console/JSON/JSONL/SARIF/agent + CI gate
• docs/checks.md — finding model, namespaces, confidence semantics
• docs/compatibility.md — cross-protocol diff taxonomy, decision tables, client-impact coverage
• docs/runtime-evidence.md — trace/log ingestion, history, perf & SLOs
• docs/runtime-scale.md — streaming bounds, memory curve, perf budget gate, snapshot formats
• docs/policies.md — policy files, inheritance, exceptions, ownership
• docs/workspace-fleet.md — multi-repo manifests + inventory
• docs/knowledge-packs.md — versioned knowledge data + plugin SDK
• docs/migration.md — portability assessments + decision briefs
• docs/handoff.md — ApiHandoffBundle, DoctorApi, Forger routing
• docs/infrastructure.md — gateway/mesh declared config + Kubernetes/IaC evidence
• docs/cache.md — declared cache policies, layers, invalidation risk
• docs/lab.md — Forge Lab corpus, ground truth, precision/recall
• docs/output-contract.md — v1 export schemas (json/jsonl/sarif/agent/report) + evolution rules
• docs/forger-boundary.md — Doctor ↔ API Forge ↔ The Forger typed boundary
• docs/release-policy.md — versioning, public surfaces, release checklist, SBOM
• docs/release-v0.1.md — quality gate, packaging, hermetic proofs
• docs/roadmap.md — shipped coverage vs planned waves
• docs/adr/ — architecture decision records
• docs/development.md — repo layout, test/lint/typecheck, adding a check

Repository layout

src/forge_doctor_api/   engine (analyzers, checks, models, CLI)
tests/                  pytest suite (offline-blocked sockets)
labs/                   Forge Lab corpus: golden + adversarial fixtures
factory/                Loop Factory specs, run records, quality gate
.github/workflows/      doctor-scan.yml CI gate
docs/                   documentation

Graph Studio

forge-doctor-api graph . --view|--ui projects the service graph through forge/ForgeGraphView/v1 and serves the embedded local explorer (declinable at install via --components). Full docs: the-forge/docs/graph-studio/.
