fwl-zephyrus 26.7.10

Atmospheric escape models of exoplanets.

ZEPHYRUS is the atmospheric escape module of the PROTEUS coupled atmosphere-interior evolution framework. It computes the rate at which an exoplanet loses its atmosphere to space under high-energy stellar irradiation.

Given a planet's mass and radius, the radius at which XUV radiation is absorbed, the stellar XUV flux at the planet, and an escape efficiency, ZEPHYRUS returns the energy-limited mass-loss rate. An optional tidal correction after Erkaev et al. (2007) enhances the rate for close-in or eccentric orbits, and two forms of the XUV-heated cross section are available. The stellar XUV flux is typically supplied by MORS evolution tracks.

Named after Zephyrus, the Greek god of the west wind and a messenger of spring. Pronounced ZEF-ir-us.

Escape model

Energy-limited (EL) escape: the deposited XUV power divided by the gravitational binding energy of the escaping gas, with an optional tidal enhancement K_tide. The XUV cross section scales as Rp * Rxuv**2 (default) or Rxuv**3, and the tidal factor applies only outside the Roche lobe (R_Hill / R_XUV > 1).

Documentation

Full documentation is at proteus-framework.org/ZEPHYRUS, including:

• Getting started: installation and the quickest path to a first run.
• Tutorial: a first escape calculation for the Sun-Earth system.
• How-to guides: install, run the tests, build the documentation.
• Explanations: model overview, coupling to PROTEUS, limitations, and the testing suite.
• API reference and validation anchors: every public function with NumPy-style docstrings, plus the reference-pinned test inventory.

Installation

pip install fwl-zephyrus

Or, for development:

git clone https://github.com/FormingWorlds/ZEPHYRUS.git
cd ZEPHYRUS
pip install -e .[develop,docs]

The docs extra pulls in Zensical so you can build this documentation locally with zensical serve.

Input data

ZEPHYRUS uses MORS for the stellar XUV flux, which needs a set of stellar evolution tracks from the OSF repository. Set the FWL_DATA environment variable to the directory where the data should live, then download the tracks:

export FWL_DATA=/your/local/path/FWL_DATA   # add to ~/.bashrc to persist
mors download all

Quick start

import numpy as np
import mors
from zephyrus.escape import EL_escape
from zephyrus.constants import au2cm, au2m, ergcm2stoWm2
from zephyrus.planets_parameters import Me, Re, a_earth, e_earth

# XUV flux at Earth from a solar-mass star, over its evolution (MORS tracks)
star = mors.Star(Mstar=1.0, Omega=1.0)
Lxuv = star.Tracks['Lx'] + star.Tracks['Leuv']          # erg s-1
Fxuv = Lxuv / (4 * np.pi * (a_earth * au2cm) ** 2)      # erg s-1 cm-2
Fxuv_SI = Fxuv * ergcm2stoWm2                           # W m-2

# Energy-limited mass-loss rate [kg s-1] across the star's history.
# a, e and Ms only enter the tidal branch (tidal_contribution=True).
mdot = EL_escape(
    tidal_contribution=False,
    a=a_earth * au2m, e=e_earth,
    Mp=Me, Ms=1.0, epsilon=0.15,
    Rp=Re, Rxuv=Re, Fxuv=Fxuv_SI,
)   # aligned with star.Tracks['Age']

See the first-run tutorial for the full walkthrough.

License

Apache License 2.0. ZEPHYRUS is part of the PROTEUS framework.
