A performant NumPy extension for Galois fields and their applications

Project description

Galois: A performant NumPy extension for Galois fields and their applications

PyPI version PyPI - Downloads Supported Versions Read the Docs GitHub Workflow Status Codecov Twitter

The main idea of the galois package can be summarized as follows. The user creates a "Galois field array class" using GF = galois.GF(p**m). A Galois field array class GF is a subclass of np.ndarray and its constructor x = GF(array_like) mimics the call signature of np.array(). A Galois field array x is operated on like any other NumPy array, but all arithmetic is performed in GF(p^m) not Z or R.

Internally, the Galois field arithmetic is implemented by replacing NumPy ufuncs. The new ufuncs are written in Python and then just-in-time compiled with Numba. The ufuncs can be configured to use either lookup tables (for speed) or explicit calculation (for memory savings).

Features

Roadmap

  • Elliptic curves over Galois fields
  • Number-theoretic transform, DFT over Galois fields
  • Group and ring arrays
  • GPU support

Documentation

The documentation for galois can be found at https://galois.readthedocs.io/en/stable/. It includes installation instructions, basic usage, tutorials, a development guide, an API reference, and release notes.

Installation

The latest version of galois can be installed from PyPI using pip.

python3 -m pip install galois

Versioning

This project uses semantic versioning. Releases are versioned major.minor.patch. Major releases introduce API-changing features. Minor releases add features and are backwards compatible with other releases in major.x.x. Patch releases fix bugs in a minor release and are backwards compatible with other releases in major.minor.x.

Releases before 1.0.0 are alpha and beta releases. Alpha releases are 0.0.alpha. There is no API compatibility guarantee for them. They can be thought of as 0.0.alpha-major. Beta releases are 0.beta.x and are API compatible. They can be thought of as 0.beta-major.beta-minor.

Basic Usage

Galois field arrays

Class construction

Galois field array classes are created using the galois.GF() class factory function.

>>> import numpy as np

>>> import galois

>>> GF256 = galois.GF(2**8)

>>> print(GF256)
<class 'numpy.ndarray over GF(2^8)'>

These classes are subclasses of galois.FieldArray (which itself subclasses np.ndarray) and have galois.FieldClass as their metaclass.

>>> isinstance(GF256, galois.FieldClass)
True

>>> issubclass(GF256, galois.FieldArray)
True

>>> issubclass(GF256, np.ndarray)
True

A Galois field array class contains attributes relating to its Galois field and methods to modify how the field is calculated or displayed. See the attributes and methods in galois.FieldClass.

# Summarizes some properties of the Galois field
>>> print(GF256.properties)
GF(2^8):
  characteristic: 2
  degree: 8
  order: 256
  irreducible_poly: x^8 + x^4 + x^3 + x^2 + 1
  is_primitive_poly: True
  primitive_element: x

# Access each attribute individually
>>> GF256.irreducible_poly
Poly(x^8 + x^4 + x^3 + x^2 + 1, GF(2))

The galois package even supports arbitrarily-large fields! This is accomplished by using NumPy arrays with dtype=object and pure-Python ufuncs. This comes at a performance penalty compared to smaller fields which use NumPy integer dtypes (e.g., np.uint32) and have compiled ufuncs.

>>> GF = galois.GF(36893488147419103183); print(GF.properties)
GF(36893488147419103183):
  characteristic: 36893488147419103183
  degree: 1
  order: 36893488147419103183
  irreducible_poly: x + 36893488147419103180
  is_primitive_poly: True
  primitive_element: 3

>>> GF = galois.GF(2**100); print(GF.properties)
GF(2^100):
  characteristic: 2
  degree: 100
  order: 1267650600228229401496703205376
  irreducible_poly: x^100 + x^57 + x^56 + x^55 + x^52 + x^48 + x^47 + x^46 + x^45 + x^44 + x^43 + x^41 + x^37 + x^36 + x^35 + x^34 + x^31 + x^30 + x^27 + x^25 + x^24 + x^22 + x^20 + x^19 + x^16 + x^15 + x^11 + x^9 + x^8 + x^6 + x^5 + x^3 + 1
  is_primitive_poly: True
  primitive_element: x

Array creation

Galois field arrays can be created from existing NumPy arrays.

# Represents an existing numpy array
>>> array = np.random.randint(0, GF256.order, 10, dtype=int); array
array([ 31, 254, 155, 154, 121, 185,  16, 246, 216, 244])

# Explicit Galois field array creation -- a copy is performed
>>> GF256(array)
GF([ 31, 254, 155, 154, 121, 185,  16, 246, 216, 244], order=2^8)

# Or view an existing numpy array as a Galois field array -- no copy is performed
>>> array.view(GF256)
GF([ 31, 254, 155, 154, 121, 185,  16, 246, 216, 244], order=2^8)

Or they can be created from "array-like" objects. These include strings representing a Galois field element as a polynomial over its prime subfield.

# Arrays can be specified as iterables of iterables
>>> GF256([[217, 130, 42], [74, 208, 113]])
GF([[217, 130,  42],
    [ 74, 208, 113]], order=2^8)

# You can mix-and-match polynomial strings and integers
>>> GF256(["x^6 + 1", 2, "1", "x^5 + x^4 + x"])
GF([65,  2,  1, 50], order=2^8)

# Single field elements are 0-dimensional arrays
>>> GF256("x^6 + x^4 + 1")
GF(81, order=2^8)

Galois field arrays also have constructor class methods for convenience. They include:

  • FieldArray.Zeros, FieldArray.Ones, FieldArray.Identity, FieldArray.Range, FieldArray.Random, FieldArray.Elements

Galois field elements can either be displayed using their integer representation, polynomial representation, or power representation. Calling FieldClass.display will change the element representation. If called as a context manager, the display mode will only be temporarily changed.

>>> a = GF256(["x^6 + 1", 0, 2, "1", "x^5 + x^4 + x"]); a
GF([65,  0,  2,  1, 50], order=2^8)

# Set the display mode to represent GF(2^8) field elements as polynomials over GF(2) with degree less than 8
>>> GF256.display("poly");

>>> a
GF([α^6 + 1, 0, α, 1, α^5 + α^4 + α], order=2^8)

# Temporarily set the display mode to represent GF(2^8) field elements as powers of the primitive element
>>> with GF256.display("power"):
...     print(a)

GF([α^191, 0, α, 1, α^194], order=2^8)

# Resets the display mode to the integer representation
>>> GF256.display();

Field arithmetic

Galois field arrays are treated like any other NumPy array. Array arithmetic is performed using Python operators or NumPy functions.

In the list below, GF is a Galois field array class created by GF = galois.GF(p**m), x and y are GF arrays, and z is an integer np.ndarray. All arithmetic operations follow normal NumPy broadcasting rules.

  • Addition: x + y == np.add(x, y)
  • Subtraction: x - y == np.subtract(x, y)
  • Multiplication: x * y == np.multiply(x, y)
  • Division: x / y == x // y == np.divide(x, y)
  • Scalar multiplication: x * z == np.multiply(x, z), e.g. x * 3 == x + x + x
  • Additive inverse: -x == np.negative(x)
  • Multiplicative inverse: GF(1) / x == np.reciprocal(x)
  • Exponentiation: x ** z == np.power(x, z), e.g. x ** 3 == x * x * x
  • Logarithm: np.log(x), e.g. GF.primitive_element ** np.log(x) == x
  • COMING SOON: Logarithm base b: GF.log(x, b), where b is any field element
  • Matrix multiplication: A @ B == np.matmul(A, B)
>>> x = GF256.Random((2,5)); x
GF([[166,  71, 214, 164, 228],
    [168, 202,  73,  54, 180]], order=2^8)

>>> y = GF256.Random(5); y
GF([ 25, 102, 131, 233, 188], order=2^8)

# y is broadcast over the last dimension of x
>>> x + y
GF([[191,  33,  85,  77,  88],
    [177, 172, 202, 223,   8]], order=2^8)

Linear algebra

The galois package intercepts relevant calls to NumPy's linear algebra functions and performs the specified operation in GF(p^m) not in R. Some of these functions include:

  • np.dot, np.vdot, np.inner, np.outer, np.matmul, np.linalg.matrix_power
  • np.linalg.det, np.linalg.matrix_rank, np.trace
  • np.linalg.solve, np.linalg.inv
>>> A = GF256.Random((3,3)); A
GF([[151, 147, 229],
    [162, 192,  59],
    [ 52, 213,  37]], order=2^8)

>>> b = GF256.Random(3); b
GF([154, 193, 235], order=2^8)

>>> x = np.linalg.solve(A, b); x
GF([114, 170, 178], order=2^8)

>>> np.array_equal(A @ x, b)
True

Galois field arrays also contain matrix decomposition routines not included in NumPy. These include:

  • FieldArray.row_reduce, FieldArray.lu_decompose, FieldArray.lup_decompose

NumPy ufunc methods

Galois field arrays support NumPy ufunc methods. This allows the user to apply a ufunc in a unique way across the target array. The ufunc method signature is <ufunc>.<method>(*args, **kwargs). All arithmetic ufuncs are supported. Below is a list of their ufunc methods.

  • <method>: reduce, accumulate, reduceat, outer, at
>>> X = GF256.Random((2,5)); X
GF([[210,  67, 167, 137,  95],
    [104,  74, 178,  13, 142]], order=2^8)

>>> np.multiply.reduce(X, axis=0)
GF([ 63, 169, 209, 171, 161], order=2^8)
>>> x = GF256.Random(5); x
GF([210,  49,  66, 251, 148], order=2^8)

>>> y = GF256.Random(5); y
GF([  3, 123, 247, 144, 197], order=2^8)

>>> np.multiply.outer(x, y)
GF([[107, 245,  37, 192,  98],
    [ 83,  67, 183, 146, 140],
    [198,  93, 248, 206, 128],
    [ 16, 170, 178,  83,  68],
    [161,  89,  38, 116, 209]], order=2^8)

Polynomials over Galois fields

The galois package supports polynomials over Galois fields with the galois.Poly class. galois.Poly does not subclass np.ndarray but instead contains a FieldArray of coefficients as an attribute (implements the "has-a", not "is-a", architecture).

Polynomials can be created by specifying the polynomial coefficients as either a FieldArray or an "array-like" object with the field keyword argument.

>>> p = galois.Poly([172, 22, 0, 0, 225], field=GF256); p
Poly(172x^4 + 22x^3 + 225, GF(2^8))

>>> coeffs = GF256([33, 17, 0, 225]); coeffs
GF([ 33,  17,   0, 225], order=2^8)

>>> p = galois.Poly(coeffs, order="asc"); p
Poly(225x^3 + 17x + 33, GF(2^8))

Polynomials over Galois fields can also display their coefficients as polynomials over their prime subfields. This can be quite confusing to read, so be warned!

>>> print(p)
Poly(225x^3 + 17x + 33, GF(2^8))

>>> with GF256.display("poly"):
...     print(p)

Poly((α^7 + α^6 + α^5 + 1)x^3 + (α^4 + 1)x + (α^5 + 1), GF(2^8))

Polynomials can also be created using a number of constructor class methods. They include:

  • Poly.Zero, Poly.One, Poly.Identity, Poly.Random, Poly.Integer, Poly.String, Poly.Degrees, Poly.Roots
# Construct a polynomial by specifying its roots
>>> q = galois.Poly.Roots([155, 37], field=GF256); q
Poly(x^2 + 190x + 71, GF(2^8))

>>> q.roots()
GF([ 37, 155], order=2^8)

Polynomial arithmetic is performed using Python operators.

>>> p
Poly(225x^3 + 17x + 33, GF(2^8))

>>> q
Poly(x^2 + 190x + 71, GF(2^8))

>>> p + q
Poly(225x^3 + x^2 + 175x + 102, GF(2^8))

>>> divmod(p, q)
(Poly(225x + 57, GF(2^8)), Poly(56x + 104, GF(2^8)))

>>> p ** 2
Poly(171x^6 + 28x^2 + 117, GF(2^8))

Polynomials over Galois fields can be evaluated at scalars or arrays of field elements.

>>> p = galois.Poly.Degrees([4, 3, 0], [172, 22, 225], field=GF256); p
Poly(172x^4 + 22x^3 + 225, GF(2^8))

# Evaluate the polynomial at a single value
>>> p(1)
GF(91, order=2^8)

>>> x = GF256.Random((2,5)); x
GF([[212, 211, 244, 125,  75],
    [113, 139, 247, 223, 106]], order=2^8)

# Evaluate the polynomial at an array of values
>>> p(x)
GF([[158, 129,  28, 122, 186],
    [184, 132, 179,  49, 223]], order=2^8)

Polynomials can also be evaluated in superfields. For example, evaluating a Galois field’s irreducible polynomial at one of its elements.

# Notice the irreducible polynomial is over GF(2), not GF(2^8)
>>> p = GF256.irreducible_poly; p
Poly(x^8 + x^4 + x^3 + x^2 + 1, GF(2))

>>> GF256.is_primitive_poly
True

# Notice the primitive element is in GF(2^8)
>>> alpha = GF256.primitive_element; alpha
GF(2, order=2^8)

# Since p(x) is a primitive polynomial, alpha is one of its roots
>>> p(alpha, field=GF256)
GF(0, order=2^8)

Forward error correction codes

To demonstrate the FEC code API, here is an example using BCH codes. Other FEC codes have a similar API.

>>> import numpy as np

>>> import galois

>>> bch = galois.BCH(15, 7); bch
<BCH Code: [15, 7, 5] over GF(2)>

>>> bch.generator_poly
Poly(x^8 + x^7 + x^6 + x^4 + 1, GF(2))

# The error-correcting capability
>>> bch.t
2

A message can be either a 1-D vector or a 2-D matrix of messages. Shortened codes are also supported. See the docs for more details.

# Create a matrix of two messages
>>> M = galois.GF2.Random((2, bch.k)); M
GF([[1, 1, 0, 1, 0, 1, 1],
    [1, 1, 0, 1, 1, 1, 0]], order=2)

Encoding the message(s) is performed with encode().

>>> C = bch.encode(M); C
GF([[1, 1, 0, 1, 0, 1, 1, 0, 0, 1, 0, 0, 0, 1, 1],
    [1, 1, 0, 1, 1, 1, 0, 0, 0, 0, 1, 0, 1, 0, 0]], order=2)

Decoding the codeword(s) is performed with decode().

# Corrupt the first bit in each codeword
C[:,0] ^= 1; C
GF([[0, 1, 0, 1, 0, 1, 1, 0, 0, 1, 0, 0, 0, 1, 1],
    [0, 1, 0, 1, 1, 1, 0, 0, 0, 0, 1, 0, 1, 0, 0]], order=2)

bch.decode(C)
GF([[1, 1, 0, 1, 0, 1, 1],
    [1, 1, 0, 1, 1, 1, 0]], order=2)

Performance

To compare the performance of galois and native NumPy, we'll use a prime field GF(p). This is because it is the simplest field. Namely, addition, subtraction, and multiplication are modulo p, which can be simply computed with NumPy arrays (x + y) % p. For extension fields GF(p^m), the arithmetic is computed using polynomials over GF(p) and can't be so tersely expressed in NumPy.

Lookup performance

For fields with order less than or equal to 2^20, galois uses lookup tables for efficiency. Here is an example of multiplying two arrays in GF(31) using native NumPy and galois with ufunc_mode="jit-lookup".

In [1]: import numpy as np

In [2]: import galois

In [3]: GF = galois.GF(31)

In [4]: GF.ufunc_mode
Out[4]: 'jit-lookup'

In [5]: a = GF.Random(10_000, dtype=int)

In [6]: b = GF.Random(10_000, dtype=int)

In [7]: %timeit a * b
79.7 µs ± 1 µs per loop (mean ± std. dev. of 7 runs, 10000 loops each)

In [8]: aa, bb = a.view(np.ndarray), b.view(np.ndarray)

# Equivalent calculation of a * b using native numpy implementation
In [9]: %timeit (aa * bb) % GF.order
96.6 µs ± 2.4 µs per loop (mean ± std. dev. of 7 runs, 10000 loops each)

The galois ufunc runtime has a floor, however. This is due to a requirement to view the output array and convert its dtype with astype(). For example, for small array sizes NumPy is faster than galois because it doesn't need to do these conversions.

In [4]: a = GF.Random(10, dtype=int)

In [5]: b = GF.Random(10, dtype=int)

In [6]: %timeit a * b
45.1 µs ± 1.82 µs per loop (mean ± std. dev. of 7 runs, 10000 loops each)

In [7]: aa, bb = a.view(np.ndarray), b.view(np.ndarray)

# Equivalent calculation of a * b using native numpy implementation
In [8]: %timeit (aa * bb) % GF.order
1.52 µs ± 34.8 ns per loop (mean ± std. dev. of 7 runs, 1000000 loops each)

However, for large N galois is strictly faster than NumPy.

In [10]: a = GF.Random(10_000_000, dtype=int)

In [11]: b = GF.Random(10_000_000, dtype=int)

In [12]: %timeit a * b
59.8 ms ± 1.64 ms per loop (mean ± std. dev. of 7 runs, 10 loops each)

In [13]: aa, bb = a.view(np.ndarray), b.view(np.ndarray)

# Equivalent calculation of a * b using native numpy implementation
In [14]: %timeit (aa * bb) % GF.order
129 ms ± 8.01 ms per loop (mean ± std. dev. of 7 runs, 10 loops each)

Calculation performance

For fields with order greater than 2^20, galois will use explicit arithmetic calculation rather than lookup tables. Even in these cases, galois is faster than NumPy!

Here is an example multiplying two arrays in GF(2097169) using NumPy and galois with ufunc_mode="jit-calculate".

In [1]: import numpy as np

In [2]: import galois

In [3]: GF = galois.GF(2097169)

In [4]: GF.ufunc_mode
Out[4]: 'jit-calculate'

In [5]: a = GF.Random(10_000, dtype=int)

In [6]: b = GF.Random(10_000, dtype=int)

In [7]: %timeit a * b
68.2 µs ± 2.09 µs per loop (mean ± std. dev. of 7 runs, 10000 loops each)

In [8]: aa, bb = a.view(np.ndarray), b.view(np.ndarray)

# Equivalent calculation of a * b using native numpy implementation
In [9]: %timeit (aa * bb) % GF.order
93.4 µs ± 2.12 µs per loop (mean ± std. dev. of 7 runs, 10000 loops each)

And again, the runtime comparison with NumPy improves with large N because the time of viewing and type converting the output is small compared to the computation time. galois achieves better performance than NumPy because the multiplication and modulo operations are compiled together into one ufunc rather than two.

In [10]: a = GF.Random(10_000_000, dtype=int)

In [11]: b = GF.Random(10_000_000, dtype=int)

In [12]: %timeit a * b
51.2 ms ± 1.08 ms per loop (mean ± std. dev. of 7 runs, 10 loops each)

In [13]: aa, bb = a.view(np.ndarray), b.view(np.ndarray)

# Equivalent calculation of a * b using native numpy implementation
In [14]: %timeit (aa * bb) % GF.order
111 ms ± 1.48 ms per loop (mean ± std. dev. of 7 runs, 10 loops each)

Linear algebra performance

Linear algebra over Galois fields is highly optimized. For prime fields GF(p), the performance is comparable to the native NumPy implementation (using BLAS/LAPACK).

In [1]: import numpy as np

In [2]: import galois

In [3]: GF = galois.GF(31)

In [4]: A = GF.Random((100,100), dtype=int)

In [5]: B = GF.Random((100,100), dtype=int)

In [6]: %timeit A @ B
720 µs ± 5.36 µs per loop (mean ± std. dev. of 7 runs, 1000 loops each)

In [7]: AA, BB = A.view(np.ndarray), B.view(np.ndarray)

# Equivalent calculation of A @ B using the native numpy implementation
In [8]: %timeit (AA @ BB) % GF.order
777 µs ± 4.6 µs per loop (mean ± std. dev. of 7 runs, 1000 loops each)

For extension fields GF(p^m), the performance of galois is close to native NumPy linear algebra (about 10x slower). However, for extension fields, each multiplication operation is equivalently a convolution (polynomial multiplication) of two m-length arrays and polynomial remainder division with the irreducible polynomial. So it's not an apples-to-apples comparison.

Below is a comparison of galois computing the correct matrix multiplication over GF(2^8) and NumPy computing a normal integer matrix multiplication (which is not the correct result!). This comparison is just for a performance reference.

In [1]: import numpy as np

In [2]: import galois

In [3]: GF = galois.GF(2**8)

In [4]: A = GF.Random((100,100), dtype=int)

In [5]: B = GF.Random((100,100), dtype=int)

In [6]: %timeit A @ B
7.13 ms ± 114 µs per loop (mean ± std. dev. of 7 runs, 100 loops each)

In [7]: AA, BB = A.view(np.ndarray), B.view(np.ndarray)

# Native numpy matrix multiplication, which doesn't produce the correct result!!
In [8]: %timeit AA @ BB
651 µs ± 12.4 µs per loop (mean ± std. dev. of 7 runs, 1000 loops each)

Acknowledgements

  • This library is an extension of, and completely dependent on, NumPy.
  • We heavily rely on Numba and its just-in-time compiler for optimizing performance of Galois field arithmetic.
  • We use Frank Luebeck's compilation of Conway polynomials.
  • We also use Wolfram's compilation of primitive polynomials.
  • We extensively use SageMath for generating test vectors.
  • We also use Octave for generating test vectors.

Many thanks!

Citation

If this library was useful to you in your research, please cite us. Following the GitHub citation standards, here is the recommended citation.

Bibtex:

@misc{Hostetter_Galois_2020,
    title = {{Galois: A performant NumPy extension for Galois fields}},
    author = {Hostetter, Matt},
    month = {11},
    year = {2020},
    url = {https://github.com/mhostetter/galois},
}

APA:

Hostetter, M. (2020). Galois: A performant NumPy extension for Galois fields [Computer software]. https://github.com/mhostetter/galois

Project details


Download files

Download the file for your platform. If you're not sure which to choose, learn more about installing packages.

Files for galois, version 0.0.21
Filename, size File type Python version Upload date Hashes
Filename, size galois-0.0.21-py3-none-any.whl (783.1 kB) File type Wheel Python version py3 Upload date Hashes View
Filename, size galois-0.0.21.tar.gz (99.3 kB) File type Source Python version None Upload date Hashes View

Supported by

AWS AWS Cloud computing Datadog Datadog Monitoring Facebook / Instagram Facebook / Instagram PSF Sponsor Fastly Fastly CDN Google Google Object Storage and Download Analytics Huawei Huawei PSF Sponsor Microsoft Microsoft PSF Sponsor NVIDIA NVIDIA PSF Sponsor Pingdom Pingdom Monitoring Salesforce Salesforce PSF Sponsor Sentry Sentry Error logging StatusPage StatusPage Status page
