Granular Audio Musaicing Toolkit for Python

Project description

GAMuT: Granular Audio Musaicing Toolkit


Description

GAMuT is a high-level, user-friendly granular audio musaicing toolkit implemented in Python. Some audio examples of audio musaicing made with GAMuT can be found here.


Installation

To install gamut, simply run the pip install gamut command in the terminal.


Documentation

Broadly speaking, the audio musaicing pipeline with GAMuT is the following:

  1. build a corpus from one or more sound files.
  2. get an audio musaicing recipe from the corpus, given a target sound file.
  3. cook the audio musaicing recipe and write it into sound file.

To do this, a small collection of functions are included:

Main functions

  • build_corpus(): Takes a folder directory, or an audio file directory, or a list of directories to audio files, and returns a dict object (i.e. the corpus). The output can be saved as a .gamut file with the dict_to_gamut() function, for later use in get_audio_recipe().

    • Required arguments:
      • input_dir (str or list): Input audio file/folder directory, or list of audio file directories, from which to build a corpus.
    • Optional arguments:
      • max_duration (int): maximum duration to analyze for all sound files in input_dir. If set to None, all sound files are analyzed in full. (Default: None)
      • n_mfcc (int): number of MFCC bands. (Default: 13)
      • hop_length (int): gap between subsequent frames, in samples. (Default: 512)
      • frame_length (int): size of analysis window, in samples. (Default: 1024)
      • kd (int): maximum number of MFCC bands to use for data query tree. If set to None, a number is internally chosen based on the number of data samples.(Default: None)
    • Returns (dict): corpus dictionary object.
  • get_audio_recipe(): Takes an audio sample directory/path (i.e. the target) and a dict object (i.e. the corpus), and returns another dict object containing the instructions to rebuild the target using grains from the corpus. The output can be saved as a .gamut file with the dict_to_gamut() function, for later use in cook_recipe().

    • Required arguments:
      • target_path (str): directory of target sound file.
      • corpus_dict (dict): dictionary object containing corpus.
    • Optional arguments:
      • max_duration (int): maximum duration to analyze for target sound file. If set to None, the sound file is analyzed in full.(Default: None)
      • hop_length (int): gap between subsequent frames, in samples. (Default: 512)
      • frame_length(int): size of analysis window, in samples. (Default: 1024)
      • kn: number of best matches (KNN) to include in recipe. (Default: 8)
    • Returns (dict): target recipe dictionary object.
  • cook_recipe(): Takes a dict object (i.e. the recipe), and returns an array of audio samples, intended to be written as an audio file.

    • Required arguments:
      • recipe_dict (dict): directory object containing audio recipe.
    • Optional arguments:
      • grain_dur (int, float or list): fixed value or envelope break points for grain duration, in seconds. (Default: 0.1)
      • stretch_factor (int, float or list): fixed value or envelope break points for strech factor (i.e. speed). (Default: 1)
      • onset_var (int, float or list): fixed value or envelope break points for grain onset variation, in seconds. (Default: 0)
      • target_mix (int, float or list)*: fixed value or envelope break points for wet/dry mix, in the range of 0.0 to 1.0. (Default: 0)
      • pan_depth (int, float or list): fixed value or envelope break points for panning depth (>= 0). (Default: 5)
      • kn (int): maximum number of best matches to choose from for each grain. (Default: 8)
      • n_chans (int): number of output channels. (Default: 2)
      • envelope (str or list): list of envelope break points, or string specifying window types. (Default: 'hann')
      • sr (int): sampling rate of output. If set to None, the target's sampling rate is used. (Default: None)
      • frame_length_res (int): window size quantization unit. Larger windows increase efficiency at the expense of resolution in grain duration. (Default: 512)
    • Returns (ndarray): numpy array of audio samples.

Additionally, the following functions are included to read and write audio and .gamut[1] files:

  • dict_to_gamut(): writes dict object into a .gamut file. This function is a simple wrapper of numpy.save().
    • Required arguments:
      • dict (dict): dictionary containing corpus or recipe data.
      • output_dir (str): output directory for .gamut file.
    • Returns (NoneType): None
  • dict_from_gamut(): reads a .gamut file as a dict object. This function is a simple wrapper of numpy.load().
    • Required arguments:
      • output_dir (str): input directory for .gamut file.
    • Returns (dict): dictionary containing corpus or recipe data.
  • write_audio(): writes an ndarray as audio. This function is a simple wrapper of soundfile.write().
    • Required arguments:
      • output_dir (str): output directory of audio file. Output file format must be .wav, .aif, or .aiff.
      • ndarray (ndarray): numpy array containing audio samples.
    • Optional arguments:
      • sr (int): audio sampling rate of output file. (Default: 44100)
      • bit_depth (int): audio bit rate of output file. (Default: 24)
    • Returns (NoneType): None
  • play_audio(): plays back an ndarray as audio. This function is a simple wrapper of sounddevice.write().
    • Required arguments:
      • ndarray (ndarray): numpy array containing audio samples.
    • Optional arguments:
      • sr (int): audio sampling rate. (Default: 44100)
    • Returns (NoneType): None

[1]: .gamut is a custom binary data format used for storing GAMuT corpora and recipe data. This file is simply a renaming of Numpy's .npy file extension.


Examples

  • Basic: generates corpus, recipe, and audio in a single script — very slow, not recommended.
# imports
from gamut import gamut

# set target sound
target = './my_soundfile.wav'

# set corpus folder containing audio samples
audio_files = './my_audio_folder/'

 # build corpus
corpus = gamut.build_corpus(audio_files)

 # make target recipe
recipe = gamut.get_audio_recipe(target, corpus)

# cook target recipe
audio_array = gamut.cook_recipe(recipe)

# write output into audio file
gamut.write_audio('./output.wav', audio_array)

# plays back audio file
gamut.play_audio(audio_array)
  • Build corpus: Builds and writes .gamut corpus into file for future reuse.
# imports
from gamut import gamut

# set path to audio folder
audio_files = './my_audio_folder/'

# build corpus from folder
my_corpus = gamut.build_corpus(folder_dir=audio_files)

# set corpus output path
outfile_path = './my_corpus.gamut'

# write corpus into disk
gamut.dict_to_gamut(dict=my_corpus, outpath=outfile_path)
  • Make recipe: Makes and writes .gamut recipe into file for future reuse.
# imports
from gamut import gamut

# path of audio target
target_path = './my_target_sound.wav'

# gamut corpus path
corpus_path = './my_corpus.gamut'

# load corpus
corpus = gamut.dict_from_gamut(corpus_path)

# build audio recipe
target_recipe = gamut.get_audio_recipe(target_path=target_path, corpus_dict=corpus)

# set recipe output path
outfile_path = './my_recipe.gamut'

# write recipe into disk
gamut.dict_to_gamut(dict=target_recipe, outpath=outfile_path)
  • Cook recipe: Generates and writes audio file (.wav, .aif. or .aif) from .gamut recipe.
# imports
from gamut import gamut

# audio recipe path
recipe_path = './my_recipe.gamut'

# load corpus
recipe = gamut.dict_from_gamut(recipe_path)

# cooking settings
envelope = [0, 1, 0.5, 0.1, 0] # grain amplitude envelope (type: str, int, float or list -- if str, use scipy.signal.windows types)
grain_dur = [0.05, 0.25] # grain duration (type: int, float, or list)
sr = 44100 # output sampling rate (type: int)
pan_depth = [1, 40] # depth of panning across channels (>= 0) (type: int, float or list)
target_mix = [0, 0.5] # dry/wet mix of input target (0.0-1.0) (type: int, float, or list)

# cook audio recipe
audio_array = gamut.cook_recipe(recipe_dict=recipe,
                        grain_dur=grain_dur,
                        target_mix=target_mix,
                        pan_depth=pan_depth,
                        envelope=envelope,
                        sr=sr)

# set audio output path
outfile_path = './output.wav'

# write audio into disk
gamut.write_audio(path=outfile_path,
            ndarray=audio_array,
            sr=sr,
            bit_depth=24)

# plays back audio file
gamut.play_audio(audio_array)

License

ISC License Copyright (c) 2022, Felipe Tovar-Henao

Permission to use, copy, modify, and/or distribute this software for any purpose with or without fee is hereby granted, provided that the above copyright notice and this permission notice appear in all copies.

THE SOFTWARE IS PROVIDED "AS IS" AND THE AUTHOR DISCLAIMS ALL WARRANTIES WITH REGARD TO THIS SOFTWARE INCLUDING ALL IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS. IN NO EVENT SHALL THE AUTHOR BE LIABLE FOR ANY SPECIAL, DIRECT, INDIRECT, OR CONSEQUENTIAL DAMAGES OR ANY DAMAGES WHATSOEVER RESULTING FROM LOSS OF USE, DATA OR PROFITS, WHETHER IN AN ACTION OF CONTRACT, NEGLIGENCE OR OTHER TORTIOUS ACTION, ARISING OUT OF OR IN CONNECTION WITH THE USE OR PERFORMANCE OF THIS SOFTWARE.
