geoclide

A python package for geometric calculations in the three-dimensional Euclidean space

Mustapha Moulana
HYGEOS website
Documentation

Features

Basic geometric objects: vectors, points, normals, rays and bounding boxes
Geometric transformations: translations, scales and rotations
Ray intersection tests with shapes: spheres, spheroids, disks, triangles and triangle meshes
Vectorized calculations with numpy: sets of objects and/or sets of rays can be processed at once
Intersection results returned as xarray datasets, gathering the intersection information and the shape attributes
Visualization of the quadrics and triangle meshes, and reading/writing of triangle meshes (netcdf4, and formats supported by trimesh as stl, ply, ...)

Installation

The installation can be performed using one of the following commands:

$ conda install -c conda-forge geoclide

$ pip install geoclide

$ pip install git+https://github.com/hygeos/geoclide.git

Quickstart

Perform an intersection test between a ray and a sphere, and get the intersection information as an xarray dataset:

>>> import geoclide as gc
>>> sphere = gc.Sphere(radius=1.)
>>> ray = gc.Ray(o=gc.Point(-2., 0., 0.8), d=gc.Vector(1., 0., 0.))
>>> ds = gc.calc_intersection(sphere, ray)
>>> ds['thit'].values, ds['phit'].values
(array(1.4), array([-0.6,  0. ,  0.8]))

Create a triangle mesh, place it in the scene with a transformation, then intersect it with the same ray:

>>> import numpy as np
>>> vertices = np.array([[-5., -5., 0.], [5., -5., 0.],
...                      [-5., 5., 0.], [5., 5., 0.]])
>>> faces = np.array([[0, 1, 2], [2, 3, 1]])
>>> translate = gc.get_translate_tf(gc.Vector(2.5, 0., 0.))
>>> rotate = gc.get_rotate_y_tf(-90.)
>>> mesh = gc.TriangleMesh(vertices, faces, otw=translate*rotate)
>>> ds = gc.calc_intersection(mesh, ray)
>>> ds['is_intersection'].values, ds['thit'].values
(array(True), array(4.5))
>>> ds['phit'].values
array([2.5, 0. , 0.8])

Documentation

The complete documentation is available at hygeos.github.io/geoclide. It includes example notebooks (basics, remote sensing applications, quadrics visualization and numpy acceleration) and the full API reference. The docstrings are also available from the built-in help function, e.g. help(gc.calc_intersection).

License

Geoclide is licensed under the Apache License 2.0, see LICENSE.txt.
