The extension for matplotlib, Altair, and Plotly animations

Project description

gif

GitHub Travis PyPI Downloads

About

The extension for Altair, matplotlib, and Plotly animations.

Installation

gif is installed at the command line:

pip install -U gif

Depending on which flavour of gif you plan to use you'll likely need some additional dependencies:

pip install "gif[altair]"
pip install "gif[matplotlib]"
pip install "gif[plotly]"

Note: gif[altair] uses Selenium, which requires a properly configured chromedriver or geckodriver.

Usage (Altair)

Imports and data:

import random
import altair as alt
import pandas as pd
import gif

df = pd.DataFrame({
    't': list(range(10)) * 10,
    'x': [random.randint(0, 100) for _ in range(100)],
    'y': [random.randint(0, 100) for _ in range(100)]
})

Decorate a plot function with gif.frame and return an Altair object:

@gif.frame
def plot(i):
    d = df[df['t'] == i]
    chart = alt.Chart(d).encode(
        x=alt.X('x', scale=alt.Scale(domain=(0, 100))),
        y=alt.Y('y', scale=alt.Scale(domain=(0, 100)))
    ).mark_circle()
    return chart

Build a bunch of "frames" with a standard for loop:

frames = []
for i in range(10):
    frame = plot(i)
    frames.append(frame)

Specify the duration between each frame and save:

gif.save(frames, 'example.gif', duration=100, unit="ms", between="frames")

Usage (matplotlib)

Imports and data:

import random
from matplotlib import pyplot as plt
import gif

x = [random.randint(0, 100) for _ in range(100)]
y = [random.randint(0, 100) for _ in range(100)]

(Optional) Set the dots per inch resolution to 300:

gif.options.matplotlib["dpi"] = 300

Decorate a plot function with gif.frame (and don't return anything):

@gif.frame
def plot(i):
    xi = x[i*10:(i+1)*10]
    yi = y[i*10:(i+1)*10]
    plt.scatter(xi, yi)
    plt.xlim((0, 100))
    plt.ylim((0, 100))

Build a bunch of "frames" with a standard for loop:

frames = []
for i in range(10):
    frame = plot(i)
    frames.append(frame)

Specify the duration of the entire gif:

gif.save(frames, 'example.gif', duration=3.5, unit="s", between="startend")

Usage (Plotly)

Imports and data:

import random
import plotly.graph_objects as go
import pandas as pd
import gif

df = pd.DataFrame({
    't': list(range(10)) * 10,
    'x': [random.randint(0, 100) for _ in range(100)],
    'y': [random.randint(0, 100) for _ in range(100)]
})

Decorate a plot function with gif.frame and return a Plotly figure:

@gif.frame
def plot(i):
    d = df[df['t'] == i]
    fig = go.Figure()
    fig.add_trace(go.Scatter(
        x=d["x"],
        y=d["y"],
        mode="markers"
    ))
    fig.update_layout(width=500, height=300)
    return fig

Build a bunch of "frames" with a standard for loop:

frames = []
for i in range(10):
    frame = plot(i)
    frames.append(frame)

Specify the duration (milliseconds) between each frame and save:

gif.save(frames, 'example.gif', duration=100)

Gallery (Altair)

Click on any image to see the source code

covid.gif emoji.gif pyramid.gif
textbooks.gif wave.gif

Gallery (matplotlib)

Click on any image to see the source code

attachment.gif hop.gif phone.gif
seinfeld.gif attachment.gif love.gif

Gallery (Plotly)

Click on any image to see the source code

bubble.gif swirl.gif waterfall.gif

If you have a dope ass animation that you think should be in the Gallery, submit a PR!
