goatd for Python

Python bindings for goatd, built with PyO3 and maturin.

Install

pip install goatd

Wheels cover CPython 3.10 and later on Linux x86-64, macOS arm64 and Windows x64. Anywhere else, pip builds from the source distribution, which needs a Rust toolchain and a C++20 compiler.

Use

import goatd

graph = goatd.Graph(4, [(0, 1), (1, 2), (2, 3), (3, 0), (0, 2)])
td = goatd.decompose(graph, order="portfolio", budget_ms=100)

td.treewidth        # 2
td.bags             # [[0, 1, 2], [0, 2, 3], [0, 3], [3]]
td.edges            # [(0, 1), (1, 2), (2, 3)] — pairs of positions in td.bags
td.validate(graph)  # raises goatd.Error if td does not decompose graph
print(td.to_td())   # PACE .td text

Options and formats

decompose takes the solver's knobs under the solver's names: order is one of minfill, mindegree, nested-dissection, flowcutter and portfolio; seed breaks ties; ties="sample" and weights control weighted sampling for the two greedy orders; steps gives flowcutter a repeatable step budget in place of a clock; refine=True re-cuts the result along FlowCutter separators. An argument the chosen order cannot act on raises ValueError naming both. Budgets are milliseconds, so the name is budget_ms rather than the command line's --budget.

goatd.Graph.from_gr and TreeDecomposition.from_td read the PACE formats; to_gr and to_td write them.

goatd is single-threaded. The interpreter lock is released for the whole of a solve, so a caller can decompose several graphs at once from Python threads.

Building from source

The extension builds the goatd sources in the repository, so it needs a Rust toolchain, a C++20 compiler for the vendored FlowCutter, and maturin.

PEP 639 resolves license-files against the directory holding pyproject.toml and forbids .., so the two notice files are copied in from the repository root first rather than kept here in a second copy:

mkdir -p bindings/python/notices
cp LICENSE docs/THIRD-PARTY.md bindings/python/notices/
pip install maturin
maturin build --release --manifest-path bindings/python/Cargo.toml

maturin develop installs the extension into the active virtualenv for pytest bindings/python/tests.
