gpmap-v2

Live interactive tour: gpmap-v2.streamlit.app (source under examples/streamlit/).

A typed, Rust-accelerated container and simulator toolkit for genotype-phenotype maps.

gpmap-v2 is a clean-break rewrite of harmslab/gpmap. It exposes the same conceptual model (a GenotypePhenotypeMap backed by a pandas DataFrame) with a locked schema, vectorized hot paths, and a PyO3 Rust core for the operations that used to be inner Python loops.

Why

• Fast. String-encoded genotypes are replaced with packed uint8 matrices. The encoding step (genotypes_to_binary) runs rayon-parallel in Rust. Construction is 5x faster than v1 at L=16 (65k genotypes), and binary_packed is a free cached lookup afterward -- no repeated re-encoding on each access.
• Typed. Full type hints, mypy-checked, strict mode.
• Safe. Cartesian-product enumeration is size-guarded out of the box (SpaceTooLargeError). No more silent 10^26 allocations.
• Stable surface. The container and encoding_table schema are locked in SCHEMA.md for downstream consumers.
• Modern tooling. uv + maturin + pyproject.toml. Automated releases via python-semantic-release. OIDC-based PyPI publishing.

Install

pip install gpmap-v2

Or with uv:

uv add gpmap-v2

Python 3.10+. Prebuilt wheels ship for Linux (x86_64, aarch64), macOS (x86_64, aarch64), and Windows (x64).

Quick start

from gpmap import GenotypePhenotypeMap

gpm = GenotypePhenotypeMap(
    wildtype="AAA",
    genotypes=["AAA", "AAT", "ATA", "TAA", "ATT", "TAT", "TTA", "TTT"],
    phenotypes=[0.1, 0.2, 0.2, 0.6, 0.4, 0.6, 1.0, 1.1],
    stdeviations=[0.05] * 8,
)

gpm.genotypes        # np.ndarray of strings, shape (8,)
gpm.phenotypes       # np.ndarray[float64], shape (8,)
gpm.binary_packed    # np.ndarray[uint8], shape (8, 3) - the fast path
gpm.binary           # np.ndarray of '0'/'1' strings - back-compat accessor
gpm.n_mutations      # per-genotype Hamming weight
gpm.encoding_table   # pandas DataFrame per SCHEMA.md
gpm.data             # pandas DataFrame view for Jupyter

Simulating landscapes

from gpmap.simulate import NKSimulation, MountFujiSimulation
import numpy as np

sim = NKSimulation(
    wildtype="AAAA",
    mutations={i: ["A", "T"] for i in range(4)},
    K=2,
    rng=np.random.default_rng(0),
)
sim.phenotypes.shape  # (16,)

I/O round-trips

from gpmap import to_json, read_json, to_csv, read_csv

to_json(gpm, "map.json")
gpm2 = read_json("map.json")

to_csv(gpm, "map.csv")   # writes map.csv + map.csv.meta.json
gpm3 = read_csv("map.csv")

Public API surface

The full list of stable exports lives in gpmap.__all__. The ones downstream consumers depend on (notably epistasis-v2) are:

• GenotypePhenotypeMap, GenotypePhenotypeMap.from_dataframe
• get_encoding_table, genotypes_to_binary, genotypes_to_binary_packed
• upper_transform, lower_transform
• StandardDeviationMap, StandardErrorMap
• SpaceTooLargeError, SchemaError, UnknownLetterError
• read_csv, read_json, read_pickle, read_excel (and to_* counterparts)
• All simulators under gpmap.simulate

The load-bearing schema contract (column names, dtypes, invariants) is in SCHEMA.md. Breaking changes to that document bump the major version.

Benchmarks vs v1

Measured on Windows 11 against gpmap==0.7.0. Full biallelic space (AT alphabet), timeit best-of-5. See benchmarks/vs_v1.py for scripts and setup.

v2 encodes eagerly at construction (Rust, parallel). v1 encodes lazily, so construction is cheaper but binary access costs extra on every call. The table below times construction including encoding for v2 and just object setup for v1.

binary_packed access after construction: v2 ~0 ms (cached); v1 binary access at L=16 costs ~11 ms per call (re-encoded each time from the underlying pandas column).

Development

git clone https://github.com/lperezmo/gpmap-v2
cd gpmap-v2
uv sync
uv run maturin develop --release
uv run pytest
uv run ruff check python/gpmap tests

A typical dev inner loop after editing Rust:

uv run maturin develop --release && uv run pytest

Consuming from another local project

gpmap-v2 is designed to be consumed as an editable dependency during co-development with sister packages (e.g. epistasis-v2). In the consumer's pyproject.toml:

[tool.uv.sources]
gpmap-v2 = { path = "/absolute/path/to/gpmap-v2", editable = true }

[project]
dependencies = ["gpmap-v2"]

Then uv sync or uv add gpmap-v2 in the consumer. Imports remain import gpmap.

Migration from v1 (harmslab/gpmap)

gpmap-v2 is not wire-compatible with v1. Key differences:

• Distribution name is gpmap-v2 on PyPI; import path is still gpmap.
• The encoding_table column genotype_index has been renamed to site_index to match its actual meaning. The old name is still readable via a deprecated alias.
• read_dataframe is now from_dataframe.
• binary_packed (uint8 2D) is exposed alongside the string-form binary. Prefer the packed form for any hot-path consumer.
• JSON files must carry "schema_version": "1". Legacy files are readable with a warning.
• upper_transform and lower_transform are now genuinely distinct (v1 had a copy-paste bug where they were identical).
• stats.unbiased_var honors the axis kwarg (v1 ignored it and hardcoded axis=1).
• simulate.random_mutation_set no longer mutates the module-level amino-acid list.
• simulate.MultiPeakMountFujiSimulation peak search has a retry cap; it raises instead of spinning forever on infeasible constraints.

See CHANGELOG.md for the full list.

Releases

Releases are driven by python-semantic-release on merge to main. Commit messages follow Conventional Commits:

• fix: ... -> patch
• feat: ... -> minor
• feat!: ... or BREAKING CHANGE: footer -> major

CHANGELOG.md, version bumps, Git tags, GitHub Releases, wheel builds, and PyPI uploads all happen automatically.

License

MIT. See LICENSE.
