graflow 0.1.9

The orchestration engine for production-grade agentic workflows

Graflow

Stop wrestling graph composition. Start writing Pythonic agent pipelines. Compose tasks with >> and |.

Graflow is a Python-based agent orchestration framework with a workflow-first, defined-by-run approach focused on simplicity and developer experience. Compose tasks — from ETL jobs to multi-agent LLM pipelines — using plain Python functions and two intuitive operators.

---

Why Graflow?

Most agent frameworks make you think in framework concepts — state machines, conditional edges, graph builders, node factories. Graflow lets you think in Python. Define tasks, connect them with >> and |, and run.

uv add graflow   # or: pip install graflow

from graflow import task, workflow

@task
def fetch():
    return {"users": 1200}

@task
def validate(users: int):        # auto-resolved from upstream channel
    assert users > 0
    return users

@task
def notify(users: int):
    print(f"Pipeline done: {users} users processed")

with workflow("my_pipeline") as ctx:
    fetch >> validate >> notify   # that's it
    ctx.execute("fetch")

3 decorators, 1 operator, zero boilerplate.

Try hands-on in the browser — no install required:

Before / After

Tired of writing add_conditional_edges, builder patterns, and explicit state objects? Here's the same agent loop in LangGraph vs. Graflow.

Define-and-compile vs. define-by-run. LangGraph makes you declare every edge and conditional transition before execution — the graph is frozen at compile() time, and all possible routes must be known upfront. Graflow is define-by-run (the same paradigm PyTorch uses vs. TensorFlow 1.x): the graph shape is whatever the Python code does at runtime. Control flow is just if/return/context.next_task() — no separate routing DSL, no END sentinels, no conditional-edge registry. You debug workflows with pdb, not with a graph inspector.

LangGraph (conditional routing)	Graflow
from langgraph.graph import StateGraph, END builder = StateGraph(State) builder.add_node("agent", agent_node) builder.add_node("tool", tool_node) builder.add_conditional_edges( "agent", should_continue, {"continue": "tool", "end": END}, ) builder.add_edge("tool", "agent") builder.set_entry_point("agent") graph = builder.compile() result = graph.invoke({"input": "hello"})	from graflow import task, workflow with workflow("agent_loop") as ctx: @task(inject_context=True) def agent(context): out = call_llm(context.get_channel().get("input")) if not should_continue(out): context.terminate_workflow("done") return out @task def tool(out: str): return run_tool(out) agent >> tool >> agent # loop ctx.execute("agent")

Key Features

Feature	What it does
>> and | operators	Chain tasks sequentially or run them in parallel — no graph builder API
Auto data flow	Task parameters are automatically resolved from upstream channels
Fan-out / Fan-in	fetch >> (transform_a | transform_b) >> store — diamond patterns in one line
Dynamic tasks	Add tasks at runtime via ctx.next_task() / ctx.next_iteration() — true defined-by-run
Distributed execution	Swap to Redis-backed queues with one config change; add workers with python -m graflow.worker.main
Checkpoint & resume	Pause long-running workflows, resume from exact state
Human-in-the-loop	Approvals, text input, selections mid-workflow — with Slack/webhook notifications
LLM agents	Plug in LiteLLM, Pydantic AI, or Google ADK agents and inject them into tasks
Tracing	Langfuse integration for observability across distributed workflows

Workflow Patterns

Linear pipeline:   a >> b >> c >> d
Fan-out:           source >> (proc_a | proc_b | proc_c)
Fan-in:            (input_a | input_b) >> aggregate
Diamond:           fetch >> (transform_a | transform_b) >> store
Multi-stage:       (load_a | load_b) >> validate >> (proc_a | proc_b) >> store

A diamond workflow visualized:

graph LR
    fetch --> transform_a
    fetch --> transform_b
    transform_a --> store
    transform_b --> store

Real-World Snippets

ETL Pipeline

with workflow("etl") as ctx:
    @task
    def extract():
        return db.query("SELECT * FROM raw_events")

    @task
    def validate(events: list):
        return [e for e in events if e["timestamp"]]

    @task
    def load(events: list):
        warehouse.bulk_insert(events)

    extract >> validate >> load
    ctx.execute("extract")

Parallel Enrichment

with workflow("enrich") as ctx:
    fetch_data >> (enrich_demographics | enrich_geo | enrich_behavioral) >> merge_and_store
    ctx.execute("fetch_data")

Multi-Agent LLM Workflow

Register LLM agents once, then inject them directly into tasks with inject_llm_agent="<name>" — no manual lookup, no boilerplate.

from graflow import task, workflow
from graflow.llm.agents.base import LLMAgent

with workflow("research") as ctx:
    # Register agents once; factories receive the ExecutionContext
    ctx.register_llm_agent("researcher", lambda _: build_researcher_agent())
    ctx.register_llm_agent("analyst",    lambda _: build_analyst_agent())

    @task(inject_llm_agent="researcher")
    def research(agent: LLMAgent):
        return agent.run("Summarize recent ML papers")["output"]

    @task(inject_llm_agent="analyst")
    def analyze(agent: LLMAgent, research: str):   # `research` auto-resolved from channel
        return agent.run(f"Analyze: {research}")["output"]

    @task
    def publish(analyze: str):
        send_report(analyze)

    research >> analyze >> publish
    ctx.execute("research")

Dynamic Workflows: next_task and next_iteration

Graflow is defined-by-run — tasks can spawn new tasks or loop themselves based on runtime data.

next_task — conditionally add a downstream task at runtime:

from graflow import task, workflow
from graflow.core.task import TaskWrapper

with workflow("router") as ctx:
    @task(id="classify", inject_context=True)
    def classify(context, value: int = 150):
        if value > 100:
            context.next_task(TaskWrapper("high", lambda: print(f"high-value: {value * 2}")))
        else:
            context.next_task(TaskWrapper("low",  lambda: print(f"low-value: {value + 10}")))

    ctx.execute("classify")

next_task(..., goto=True) — branch to a task and skip the statically-declared successors:

with workflow("pipeline") as ctx:
    @task(id="validate", inject_context=True)
    def validate(context, record: dict):
        if not record.get("ok"):
            # Jump to error handler and SKIP process/publish below
            context.next_task(error_handler, goto=True)
            return
        # Fall through: process >> publish will run normally

    @task
    def process(): ...

    @task
    def publish(): ...

    @task
    def error_handler():
        print("recovery path")

    validate >> process >> publish
    ctx.execute("validate", value={"ok": False})

Semantics at a glance:

Call	New task?	Runs static successors?
next_task(new_task)	creates	✅ yes (normal fan-out)
next_task(existing_task)	—	❌ no (auto-goto)
next_task(task, goto=True)	either	❌ no (explicit goto)

Use goto=True for error recovery, early exits, or replacing the rest of the pipeline with a different branch — it's the Graflow equivalent of a conditional edge pointing at END and then jumping elsewhere, in one line.

next_iteration — loop the current task with new data until a convergence condition:

with workflow("optimize") as ctx:
    @task(id="optimizer", inject_context=True, max_cycles=20)
    def optimize(context, data=None):
        params = data or {"iteration": 0, "accuracy": 0.5}
        params = {"iteration": params["iteration"] + 1,
                  "accuracy": min(params["accuracy"] + 0.15, 0.95)}
        print(f"Iter {params['iteration']}: accuracy={params['accuracy']:.2f}")

        if params["accuracy"] >= 0.9:
            return params            # converged → workflow ends
        context.next_iteration(params)  # loop with new data

    ctx.execute("optimizer")

Use next_task for branching, next_iteration for cycles — both respect checkpointing, retries, and tracing.

Run Tasks in Docker

Need environment isolation, pinned Python versions, or GPU runtimes? Tag a task with handler="<name>" and register a DockerTaskHandler bound to that name — the same workflow code now runs each task inside a container.

Each handler is bound to one image, so pick a container per task by registering multiple handlers under distinct names:

from graflow import task, workflow
from graflow.core.context import ExecutionContext
from graflow.core.engine import WorkflowEngine
from graflow.core.handlers.docker import DockerTaskHandler

with workflow("docker_pipeline") as wf:
    @task
    def local_step():
        return "ran on host"

    @task(handler="py311")                 # -> python:3.11-slim
    def etl_step():
        import sys
        return f"etl on python {sys.version_info[:2]}"

    @task(handler="pytorch_gpu")           # -> pytorch/pytorch:latest
    def train_step():
        import torch
        return f"cuda available: {torch.cuda.is_available()}"

    local_step >> etl_step >> train_step

    engine = WorkflowEngine()
    # Register one handler per image; task's `handler=` picks which one
    engine.register_handler("py311",       DockerTaskHandler(image="python:3.11-slim"))
    engine.register_handler("pytorch_gpu", DockerTaskHandler(image="pytorch/pytorch:latest"))
    engine.execute(ExecutionContext.create(wf.graph))

Mix and match freely: CPU vs. GPU, Python 3.10 vs. 3.12, custom-built images with pre-installed dependencies — it's all just "register a handler, tag the task."

💡 Custom handlers. docker is just one built-in handler. You can implement your own TaskHandler for Kubernetes Jobs, AWS Lambda, Modal, Ray, SSH-to-remote-host, or any other execution backend — same workflow code, custom runtime. See the Task Handlers guide for the handler interface and full examples.

Scale to Distributed

The same workflow code runs locally or across a Redis-backed worker pool — just change the backend.

from graflow.core.context import create_execution_context
from graflow.queue.factory import QueueBackend

context = create_execution_context(
    queue_backend=QueueBackend.REDIS,
    channel_backend="redis",
)

# Start workers in separate terminals
python -m graflow.worker.main --worker-id worker-1
python -m graflow.worker.main --worker-id worker-2

Documentation

• Product Documentation — Guides, API reference, architecture
• Examples — Production-ready examples organized by complexity
• CHANGELOG

Contributing

Contributions are welcome — see CONTRIBUTING.md for setup, development workflow, and PR guidelines.

Ways to contribute:

• 🐛 Report bugs or request features via GitHub Issues
• 🔌 Add a new backend (queue / channel / handler) — follow the factory pattern in graflow/queue/ and graflow/channels/
• 📚 Contribute an example to examples/ — especially real-world agent/LLM workflows
• 📖 Improve the docs at graflow.ai
• 💬 Discuss on r/GraflowAI

License

This project is licensed under the Apache License 2.0 — see the LICENSE file for details.
