gsplot logo

Documentation PyPI Python License: MIT

gsplot

gsplot creates publication-quality scientific figures with a concise API on top of Matplotlib. It adds paper-aware layouts, deterministic plotting and styling helpers, validated JSON defaults, and lightweight build metadata while returning ordinary Matplotlib Figure, Axes, and Artist objects.

The package is still evolving. Check the documentation and the issue tracker before depending on behavior that is not covered by the public API.

Install

gsplot supports Python 3.10 and newer:

python -m pip install gsplot

Quick example

import gsplot as gs

fig, axes = gs.subplots("AB")
gs.line(axes["A"], [0, 1, 2], [0, 1, 4], label="quadratic")
gs.scatter(axes["B"], [0, 1, 2], [0, 1, 4], label="samples", s=15)
gs.label(axes, "x", "value", square=True, index="in")
gs.legend(axes)
gs.save(fig, "quickstart", show=False)

This creates a two-panel Matplotlib figure, saves quickstart.png and quickstart.pdf, and remains compatible with regular Matplotlib operations.

The canonical helpers always receive their Figure or Axes target explicitly. save writes PNG and PDF transactionally at 600 DPI with a tight crop and displays the Figure after successful writes by default; pass show=False for batch or headless output. Use crop=False when output dimensions must match the Figure design canvas exactly. The advanced savefig helper retains its conservative output controls.

For a complete scientific example, see the publication example.

Configuration

Configuration is optional and explicit. Load a schema-2 JSON file and pass the immutable value to supported functions:

import gsplot as gs

config = gs.load_config("path/to/gsplot.json")
fig, axes = gs.subplots(config=config)

When a value is specified more than once, the precedence is:

  1. an argument passed directly to the function;
  2. the supplied immutable Config value;
  3. the function's default value.

Canonical code never searches the working directory or home directory for a configuration file. See the configuration guide for the supported schema, precedence, and backend notes.

Development

The repository uses Poetry and targets Python 3.10 or newer. With a compatible Python interpreter:

python -m pip install "poetry==2.4.1"
poetry install
MPLBACKEND=Agg poetry run pytest -q
MPLBACKEND=Agg poetry run sphinx-build -W -b html docs docs/_build/html

The scripts under examples/ are executable documentation. Run one from its own directory, for example:

cd examples/layouts && python mosaic.py

examples/compatibility/legacy_v0.py intentionally demonstrates the deprecated 0.x surface. All other plotting examples use the canonical explicit-target API.

See the developer setup guide for formatting, type checking, packaging, and Docker instructions.

For private vulnerability reports and the supported-version policy, see SECURITY.md.

Authors and maintenance

This repository builds on the original code developed by Giordano Mattoni.

  • Original author: Giordano Mattoni
  • Maintainer: Soichiro Yamane

License

This project is distributed under the MIT License.
