gymnasium-retinatask 0.1.0

A Gymnasium-compatible implementation of the Left & Right Retina Problem

Gymnasium Retina Task

A Gymnasium-compatible implementation of the Left & Right Retina Problem, a benchmark task for testing the evolution of modular neural networks.

Overview

The Retina Task is based on the work by Risi & Stanley (Artificial Life 2012) on evolving modular neural networks using ES-HyperNEAT. The task tests an agent's ability to independently classify patterns on the left and right sides of a 4x2 artificial retina.

This implementation is:

• ML-agnostic: Clean separation from evolutionary algorithms
• Gymnasium-compatible: Follows Farama Foundation standards
• Well-tested: Comprehensive test suite included
• Easy to use: Simple API with multiple evaluation modes

Installation

Using uv (recommended):

uv pip install -e .

Using pip:

pip install -e .

Quick Start

import gymnasium as gym
import gymnasium_retinatask

# Create environment
env = gym.make("RetinaTask-v0")

# Reset environment
obs, info = env.reset()

# Take a step
action = env.action_space.sample()  # Random classification
obs, reward, terminated, truncated, info = env.step(action)

env.close()

The Task

The artificial retina consists of 8 pixels arranged in a 4x2 grid:

Left side (4 pixels) | Right side (4 pixels)

Objective

The agent must independently classify whether patterns on each side are "valid":

• Left output: 1.0 if left pattern is valid, 0.0 if invalid
• Right output: 1.0 if right pattern is valid, 0.0 if invalid

Pattern Distribution

Out of 256 possible patterns (2^8):

• 64 patterns have both sides valid (25%)
• 64 patterns have only left valid (25%)
• 64 patterns have only right valid (25%)
• 64 patterns have neither side valid (25%)

Why This Task?

This task is designed to test modularity in neural networks. The left and right classification problems should ideally be solved by separate, independent modules in the network. This makes it an excellent benchmark for:

• Modular neural network evolution
• Structure learning algorithms
• Neuroevolution techniques (NEAT, HyperNEAT, ES-HyperNEAT)

Environment Details

Observation Space

Box(0, 1, (8,), float32) - 8 retina pixels, each either 0 (off) or 1 (on)

Action Space

Box(0, 1, (2,), float32) - Classification outputs:

• action[0]: Left side classification
• action[1]: Right side classification

Rewards

By default, uses the fitness function from the original paper:

reward = 1000.0 / (1.0 + error�)

where error is the sum of absolute differences between outputs and correct labels.

Episode Modes

The environment supports three modes:

1. Single Pattern (default): One random pattern per episode

   env = gym.make("RetinaTask-v0", mode="single_pattern")


2. Batch: Fixed number of random patterns per episode

   env = gym.make("RetinaTask-v0", mode="batch", batch_size=100)


3. Full Evaluation: All 256 patterns in sequence

   env = gym.make("RetinaTask-v0", mode="full_evaluation")


Reward Types

• paper (default): Uses 1000.0 / (1.0 + error) fitness function
• simple: Returns negative error directly

env = gym.make("RetinaTask-v0", reward_type="simple")

Examples

Random Agent

import gymnasium as gym
import gymnasium_retinatask

env = gym.make("RetinaTask-v0", mode="batch", batch_size=100)
obs, info = env.reset()

episode_reward = 0
while True:
    action = env.action_space.sample()
    obs, reward, terminated, truncated, info = env.step(action)
    episode_reward += reward
    if terminated:
        break

print(f"Total reward: {episode_reward:.2f}")
env.close()

Perfect Agent (Baseline)

import gymnasium as gym
import numpy as np
from gymnasium_retinatask import RetinaPatterns

env = gym.make("RetinaTask-v0", mode="full_evaluation")
obs, info = env.reset()

episode_reward = 0
while True:
    # Get perfect classification
    pattern = info["pattern"]
    left, right = RetinaPatterns.get_labels(pattern)
    action = np.array([left, right], dtype=np.float32)

    obs, reward, terminated, truncated, info = env.step(action)
    episode_reward += reward
    if terminated:
        break

print(f"Accuracy: 100%")
print(f"Reward: {episode_reward:.2f}")  # Should be 1000.0
env.close()

Running Examples

The package includes several example scripts:

# Analyze pattern distribution
uv run python src/gymnasium_retinatask/examples/pattern_analysis.py

# Test with perfect agent (baseline)
uv run python src/gymnasium_retinatask/examples/perfect_agent.py

# Test with random agent
uv run python src/gymnasium_retinatask/examples/random_agent.py

Advanced Examples

The examples/ directory contains complete, working implementations using different ML frameworks:

NEAT Evolution

Evolve neural networks using NEAT (NeuroEvolution of Augmenting Topologies):

# Install NEAT dependencies
uv sync --group examples-neat

# Run NEAT evolution (50 generations)
uv run python examples/neat_evolution.py

This example demonstrates:

• Configuring NEAT for the Retina Task
• Evaluating genomes on all 256 patterns
• Tracking evolution statistics across generations
• Testing the best evolved network

Expected results: ~75-90% accuracy after 50 generations.

HyperNEAT Evolution

Evolve networks using HyperNEAT, which exploits the geometric structure of the retina:

# Install NEAT dependencies (same as above)
uv sync --group examples-neat

# Run HyperNEAT evolution (30 generations)
uv run python examples/hyperneat_evolution.py

HyperNEAT features:

• CPPN (Compositional Pattern Producing Network) generates substrate weights
• Substrate network matches the 2D retina geometry
• Encourages modular solutions for left/right independence
• Analyzes evolved network structure

The geometric substrate layout helps HyperNEAT discover modular solutions more efficiently than standard NEAT.

Development

Running Tests

uv run pytest src/gymnasium_retinatask/tests/ -v

Code Formatting

uv run black src/
uv run isort src/

Reference

This implementation is based on:

Risi, S., & Stanley, K. O. (2012). An enhanced hypercube-based encoding for evolving the placement, density, and connectivity of neurons. Artificial Life, 18(4), 331-363. doi: 10.1162/ARTL_a_00071

License

MIT

Contributing

Contributions are welcome! Please feel free to submit a Pull Request.
