hand-tracking-sdk 1.1.0

Python SDK for Hand Tracking Streamer telemetry

Python SDK for consuming telemetry from Hand Tracking Streamer (HTS)

Hand Tracking SDK is a Python package for consuming HTS hand-tracking telemetry (UDP/TCP), parsing wrist/landmark data into typed frames, and providing conversion, visualization, and integration-ready APIs.

This SDK is hosted on PyPI, with API documentation Here

Installation

pip install hand-tracking-sdk

Optional visualization support with Rerun:

pip install "hand-tracking-sdk[visualization]"

Quickstart

from hand_tracking_sdk import HTSClient, HTSClientConfig, StreamOutput

client = HTSClient(
    HTSClientConfig(
        output=StreamOutput.BOTH,  # packets + assembled frames
    )
)

for event in client.iter_events():
    print(event)

What HTS Sends

HTS emits UTF-8 CSV lines:

• wrist packet: 7 floats (x, y, z, qx, qy, qz, qw)
• landmarks packet: 63 floats (21 x [x, y, z])

The SDK validates packet labels, hand side, and exact value counts.

Streaming Client

HTSClient provides a high-level sync stream with filtering and error policy controls.

• Transport: UDP, TCP server, TCP client
• Output: raw packets, assembled frames, or both
• Hand filter: left, right, or both
• Error policy: strict (raise) or tolerant (skip malformed)
• Observability: get_stats() counters, log_hook for structured events

Frame Assembly

HandFrameAssembler correlates wrist + landmark packets into per-hand HandFrame objects. Head pose packets produce HeadFrame events. Stale out-of-order updates are discarded.

A HandFrame includes:

• side: Left or Right
• wrist: WristPose(x, y, z, qx, qy, qz, qw)
• landmarks.points: 21 MediaPipe-style (x, y, z) joints
• Per-joint access: frame.get_joint(JointName.INDEX_TIP)
• Per-finger access: frame.get_finger("index")
• Timing metadata: recv_ts_ns, source_ts_ns, sequence_id

Coordinate Conversion

Explicit Unity left-handed to right-handed converters:

from hand_tracking_sdk.convert import (
    convert_hand_frame_unity_left_to_right,
    unity_left_to_rfu_position,          # right-forward-up
    unity_left_to_rfu_rotation_matrix,
)

Joint & Finger Access

To get telemetry for a specific joint from a frame, use get_joint(...). Joint names and order follow the HTS streamed contract (wrist is JointName.WRIST).

from hand_tracking_sdk import HTSClient, HTSClientConfig, JointName, StreamOutput

client = HTSClient(HTSClientConfig(output=StreamOutput.FRAMES))

for frame in client.iter_events():
    x, y, z = frame.get_joint(JointName.INDEX_TIP)
    print(
        f"side={frame.side.value} joint={JointName.INDEX_TIP.value} "
        f"xyz=({x:.5f}, {y:.5f}, {z:.5f}) recv_ts_ns={frame.recv_ts_ns}"
    )

You can also query by finger group:

index_points = frame.get_finger("index")
# returns dict[JointName, tuple[float, float, float]]
# keys include JointName.INDEX_PROXIMAL, JointName.INDEX_TIP, ...

Examples

Telemetry

Script	Description
examples/visualize_rerun.py	Rerun 3D visualization with coordinate frames and jitter metrics
examples/stream_frames.py	Print assembled frames to console
examples/log_to_jsonl.py	JSONL capture for replay and analysis
examples/jitter_report.py	Timing jitter report

uv run python examples/visualize_rerun.py --transport tcp_server --host 0.0.0.0 --port 8000

Video Host (WebRTC)

Host-side scripts that stream video back to the Quest headset over WebRTC. See examples/video/README.md for details.

Script	Source	Description
test_pattern_video_host.py	Test pattern	Colour bars — no hardware needed
webcam_video_host.py	USB webcam	Streams a local camera feed
inspire_hand_video_host.py	MuJoCo	Bimanual Inspire Hand with vector retargeting
shadow_hand_video_host.py	MuJoCo	Bimanual Shadow Hand E3M5 with vector retargeting
aloha_video_host.py	MuJoCo	ALOHA 2 bimanual arms with IK

# Test pattern — no extra dependencies:
uv run examples/video/test_pattern_video_host.py

# Shadow Hand bimanual retargeting:
uv run examples/video/shadow_hand_video_host.py --mocap-tcp-port 5555

Simulation Teleop

The MuJoCo video hosts close a full teleoperation loop: Quest sends hand + head mocap over TCP, Python drives a MuJoCo simulation, and the rendered camera view streams back to the headset over WebRTC.

Quest 3/3S ──TCP──► HTSClient ──► MuJoCo pre_step + mj_step + render
                                                     │
Quest 3/3S ◄────────────── WebRTC H.264 ◄────────────┘

Protocol and Docs

• HTS protocol: hand-tracking-streamer README
• SDK API docs: hand-tracking-sdk.readthedocs.io

License

Apache-2.0
