Hardcharger™ PDF Loader

Load PDF files into a Hardcharger™ server over Warp SQL / ADBC so SQL clients and Hardcharger MCP agents can search the text and download the original files.

Adapted from gizmosql-pdf-loader, with its complete test suite ported to the Hardcharger server and adbc-driver-hardcharger.

For every PDF the loader stores:

Works with plain DuckDB catalogs and with DuckLake catalogs (no primary-key / unique constraints are used; the loader de-duplicates on SHA-256 itself).

Install

python3 -m venv .venv && . .venv/bin/activate
pip install hardcharger-pdf-loader          # or: pip install dist/hardcharger_pdf_loader-*.whl

Python 3.11–3.15. Tested with Hardcharger server 2.0.0 and ADBC driver 2.0.2.

Dependencies: adbc-driver-hardcharger (>= 2.0.2), pyarrow, pymupdf, click, python-dotenv.

OCR of image-only pages needs no extra install: the Tesseract engine ships inside the PyMuPDF wheel, and the only external piece, the trained language data (eng.traineddata, about 4 MB), is downloaded on first use into ~/.cache/hardcharger-pdf-loader/tessdata from the tessdata_fast repository. An installed Tesseract's language folder (or --tessdata / TESSDATA_PREFIX) is used instead when present; --no-ocr-download forbids the download. Without language data, image-only pages are loaded with empty text and a warning.

Configure

Create a .env in the working directory (or export the variables):

HARDCHARGER_HOSTNAME=hardcharger.example.com
HARDCHARGER_PORT=443
HARDCHARGER_USERNAME=me@example.com
HARDCHARGER_PASSWORD=...
HARDCHARGER_CATALOG=my_lake          # target catalog (must already be attached on the server)
HARDCHARGER_SCHEMA=pdf_docs          # target schema (created if missing); default: pdf_docs
# optional
HARDCHARGER_USE_TLS=true             # false -> hardcharger://host:port?tls=false
HARDCHARGER_TLS_SKIP_VERIFY=false

Set the catalog explicitly. A session's default catalog is whatever database the server was started with, which on some deployments is the ephemeral in-memory memory catalog; the loader refuses to load into memory or temp so tables can't silently land somewhere that vanishes on restart.

Use

# Load every *.pdf in a directory (or pass explicit file paths)
hardcharger-pdf-loader load --source-dir source_pdf_files

# Inspect/extract without connecting to the server
hardcharger-pdf-loader load --dry-run --source-dir source_pdf_files

# What is loaded?
hardcharger-pdf-loader list

# Search page text: substring match, or BM25-ranked via the full-text index
hardcharger-pdf-loader search "hydraulic pump" --limit 5
hardcharger-pdf-loader search "hydraulic pump relief valves" --ranked --limit 5

# (Re)build the full-text index (also done automatically at the end of `load`)
hardcharger-pdf-loader index

Useful load options (see hardcharger-pdf-loader load --help for all):

Documents are identified by a UUID derived from the file's SHA-256, so the same bytes always map to the same document_id; re-running the loader is idempotent.

Use as a Python library

Everything the CLI does is a plain function call; the top-level package exports the pieces you need (HardchargerSettings, LoadOptions, OcrSettings, ensure_schema, load_pdf, plan_fts, build_fts_index, inspect_pdf, extract_pages, ...). examples/load_with_python.py is the runnable version of this:

import sys
from pathlib import Path

from dotenv import load_dotenv

from hardcharger_pdf_loader import (
    HardchargerSettings,
    LoadOptions,
    OcrSettings,
    build_fts_index,
    ensure_schema,
    load_pdf,
    plan_fts,
)

load_dotenv(dotenv_path=".env")

CATALOG = "my_lake"
SCHEMA = "pdf_docs"
source_dir = Path(sys.argv[1] if len(sys.argv) > 1 else "source_pdf_files")

# HardchargerSettings(hostname=..., port=..., username=..., password=...) also works without env vars.
settings = HardchargerSettings.from_env()

with settings.connect(catalog=CATALOG) as conn:
    ensure_schema(conn, catalog=CATALOG, schema=SCHEMA)  # idempotent: tables, views, macros, migrations

    options = LoadOptions(
        catalog=CATALOG,
        schema=SCHEMA,
        chunk_size=8 * 1024 * 1024,
        replace=False,  # True reloads files whose SHA-256 is already present
        ocr=OcrSettings(enabled=True, language="eng"),
    )
    for pdf_path in sorted(source_dir.glob("*.pdf")):
        result = load_pdf(conn, path=pdf_path, options=options)
        r = result
        print(f"{r.status:8} {r.file_name}: {r.page_count} pages, {r.total_text_chars:,} chars")

    # Full-text index: built in place on a DuckDB-file catalog, skipped on DuckLake unless a
    # DuckDB catalog is named to hold a copy of the page text.
    plan = plan_fts(conn, catalog=CATALOG, schema=SCHEMA, fts_catalog="memory")
    print(f"fts: {plan.mode} ({plan.reason})")
    pages_indexed = build_fts_index(conn, plan)

    with conn.cursor() as cur:
        if pages_indexed:
            cur.execute(
                f"SELECT file_name, page_number, score "
                f"FROM {CATALOG}.{SCHEMA}.search_pages_ranked(?, top_k := 3)",
                parameters=["relief valve"],
            )
        else:
            cur.execute(
                f"SELECT file_name, page_number, snippet FROM {CATALOG}.{SCHEMA}.search_pages(?) LIMIT 3",
                parameters=["relief valve"],
            )
        for row in cur.fetchall():
            print(row)

load_pdf returns a LoadResult (status is "loaded" or "skipped", plus chunk/page/text counts and the document_id). inspect_pdf(path) and extract_pages(path, ocr=...) work without any server connection if you only want the metadata or the text.

Query from SQL

-- Ranked full-text search (BM25, English stemming) via the fts index
SELECT file_name, page_number, score, snippet
  FROM my_lake.pdf_docs.search_pages_ranked('hydraulic pump relief valves', top_k := 10);

-- Ranked search by hand: call the index's match_bm25 macro directly. The index schema is
-- fts_<schema>_document_pages in the catalog that holds the indexed table: the target catalog
-- for a DuckDB-file target (below), or the --fts-catalog for a DuckLake target, e.g.
-- memory.fts_pdf_fts_document_pages over memory.pdf_fts.document_pages.
-- conjunctive := 1 requires every term on the page (default: any term, ranked).
SELECT d.file_name, p.page_number, round(p.score, 2) AS score
  FROM (SELECT document_id, page_number,
               my_db.fts_pdf_docs_document_pages.match_bm25(page_id, 'hydraulic relief valve', conjunctive := 1) AS score
          FROM my_db.pdf_docs.document_pages) p
  JOIN my_db.pdf_docs.documents d USING (document_id)
 WHERE p.score IS NOT NULL
 ORDER BY p.score DESC
 LIMIT 10;

-- Substring search with a snippet (case-insensitive, no index needed)
SELECT file_name, page_number, snippet
  FROM my_lake.pdf_docs.search_pages('relief valve')
 LIMIT 10;

-- Same thing by hand
SELECT d.file_name, p.page_number, p.page_text
  FROM my_lake.pdf_docs.document_pages p
  JOIN my_lake.pdf_docs.documents d USING (document_id)
 WHERE p.page_text ILIKE '%relief valve%';

-- Metadata
SELECT file_name, mime_type, file_size_bytes, page_count, pages_with_text, title, producer, pdf_created_at
  FROM my_lake.pdf_docs.documents;

-- Fetch a file's chunks in order (each row is one chunk, so any client message limit works)
SELECT chunk_index, content
  FROM my_lake.pdf_docs.document_chunks
 WHERE document_id = (SELECT document_id FROM my_lake.pdf_docs.documents
                       WHERE file_name = 'parts-manual-2.pdf')
 ORDER BY chunk_index;

Full-text index

search_pages_ranked is backed by DuckDB's fts extension (BM25 scoring, English stemmer). The loader looks up the target catalog's type in duckdb_databases() and logs what it decides:

Loading the fts extension needs the Hardcharger admin role; querying an existing index does not. The index is a snapshot: load refreshes it after loading new documents, and hardcharger-pdf-loader index rebuilds it on demand. If the copy catalog is the server's in-memory memory catalog (as in the example below), the copy and index vanish on a server restart, so run index again afterwards (or point --fts-catalog at an attached DuckDB file).

# DuckLake target: opt in to a copy-based index in the shared in-memory catalog
hardcharger-pdf-loader index --fts-catalog memory

Download a file from Python

examples/download_document.py streams the chunks in order and verifies the SHA-256 without buffering the whole PDF:

python examples/download_document.py "parts-manual-2.pdf" /tmp/parts-manual-2.pdf

The core of it:

cur.execute(
    f"SELECT content FROM {qs}.document_chunks WHERE document_id = ? AND chunk_index = ?",
    parameters=[document_id, chunk_index],
)
(content,) = cur.fetchone()
out.write(content)

Hidden layers ("secure" PDFs)

Some vendor products (e.g. HyperGEAR PDFLib "secure documents") do not encrypt a PDF; they put the real content on an optional-content layer whose default view state is OFF and rely on viewer JavaScript to switch it on after checking a license window. Outside that viewer every page looks blank, and OCR finds nothing.

The loader records such layers in documents.hidden_layer_names and, by default, leaves them alone. With --reveal-hidden-layers it writes a temporary copy with those layers switched ON, extracts text from the copy, deletes it, and sets documents.hidden_layers_revealed = true. The stored file bytes are always the original. Use this only for documents you are entitled to read outside the vendor's viewer.

Streaming file bytes

Uploads use cursor.adbc_ingest with a RecordBatchReader, one record batch per chunk (8 MiB by default), over Warp SQL's Arrow IPC transport. Page text is sent in batches of 200 pages. Downloads read the chunks in chunk_index order and verify the SHA-256.

There is no server-side view that concatenates a whole file: large BLOB concatenations can use much more memory than the original PDF. Reassemble on the client with examples/download_document.py.

Development

pip install -e ".[dev]"
ruff check src tests examples
pytest -q -ra                 # every test, including OCR + live DuckDB and DuckLake integration
python -m build                # wheel + sdist in dist/

The suite starts an isolated Hardcharger 2.0.0 subprocess automatically using the hardcharger==2.0.1 development dependency. The server binary is downloaded and verified on first use. Each run uses a temporary DuckDB file, a temporary home and random credentials. OCR language data and the DuckDB fts / ducklake extensions are downloaded when needed; missing prerequisites fail tests instead of skipping them. To use your own server instead, set HARDCHARGER_HOSTNAME and the connection variables above (administrator access and a persistent catalog are required; attach a DuckDB catalog named memory for the copy-index test). pytest -m "not integration" runs only the tests that do not need a server.

CI runs the full suite on Python 3.11, 3.12, 3.13, 3.14 and 3.15, then builds and checks both the wheel and source distribution.

Releases: bump version in pyproject.toml, move the [Unreleased] notes in CHANGELOG.md into a version section, commit, then git push origin main vX.Y.Z. CI runs the tests on Python 3.11 through 3.15, builds the wheel and sdist, creates a GitHub Release with that CHANGELOG section as the notes and the artifacts attached, and publishes the package to PyPI via trusted publishing (the pypi GitHub environment; no token secrets).

Exact PyPI publisher values and first-release steps are in docs/publishing.md.
