hpckit 0.2.1

hpckit is a small Python CLI for orchestrating Slurm cluster workflows from a local project checkout. It manages remote tool checkouts, immutable per-SHA virtualenvs, run packets, Slurm submission and polling, receipts, artifact sync, and local run ledgers.

The tools it runs are declared in your own .hpckit.yaml — hpckit ships none of them, and depends on nothing but a YAML parser itself.

Its companion renderer is quadros, which turns simulation field snapshots into frames and video. Add it with the renderer extra if you want to render as well as submit:

pip install hpckit              # submit jobs only
pip install 'hpckit[renderer]'  # ...and render locally

It stays optional on purpose: quadros brings VTK, roughly 700 MB, and a machine that only submits jobs should not pay that.

Configuration lives in the project you run it from, not in this repository, so one installation drives any number of projects.

Install

For local development:

uv pip install -e .

For command-line use from another checkout:

pipx install git+https://github.com/openfluids/hpckit.git

Quickstart

cd /path/to/your/project
hpckit init --project myproject
hpckit doctor

Configure

Create .hpckit.yaml in the project where you run hpckit (see .hpckit.example.yaml for a full template). Tools, job types, and the sparse batch script name are all config-driven:

project: myproject
remote: mycluster
work_root: /path/to/work
scratch_root: /path/to/scratch
remote_repos_root: /path/to/work/repos
remote_state_root: /path/to/work/.hpckit
ledger: HPCKIT_RUN_LOG.md
job_script: job.batch
restart_helper: check_restart.py
prologue: |                      # optional — site environment setup
  module load myenv
  export OMP_NUM_THREADS=1
slurm:
  account: myproj@cpu   # required — no default
  partition: prepost
  ntasks: 1
  cpus_per_task: 4
tools:
  sigtool:
    repo_url: git@github.com:myorg/sigtool.git
job_types:
  process:
    tool: sigtool
    command: "{venv}/bin/python -m sigtool.cli process --registry {run_dir}/registry.toml --output-root {output_dir}"
artifact_sync:
  processed: data/hpckit_processed
  renders: plots/hpckit_renders
  paper_figs: paper/figs
  receipts: hpckit/receipts

Commands

hpckit doctor
hpckit status
hpckit update-repo <tool> --ref <sha-or-branch>
hpckit submit <job_type> <case> --ref <sha>
hpckit submit sparse <case> --to <target_end_time>
hpckit poll [run_id]
hpckit sync-artifacts <run_id>
hpckit receipt <run_id>
python -m hpckit doctor

Job type subcommands (e.g. process, render, plot) come from job_types: in the config. Sparse is built-in and uses job_script / restart_helper.

Site environment setup

sbatch starts a non-login shell, so anything your login profile would normally provide — module load, an MPI or compiler environment — is absent inside the job unless you set it up there. That failure is a quiet one: the command still runs, it just cannot find the tools it expected, and you get a result that looks like a real one.

prologue: is shell run inside the generated job.sbatch, after set -euo pipefail and before the job type's command. It goes there rather than inside each command: because command templates are expanded with str.format_map, so a shell ${VAR} would raise unknown placeholder '{VAR}'; because every job type would otherwise repeat it; and because it varies with the machine, not with the job. Omit it and the generated script is what it was before.

Some environment scripts reference unbound variables and trip set -u. Fence those rather than dropping the option for the whole job:

prologue: |
  set +u
  . /opt/intel/oneapi/setvars.sh --force >/dev/null 2>&1
  set -u
  export OMP_NUM_THREADS=1

Development

uv sync --group dev
uv run pytest
uv run python -m build

The repository uses the PyPA-recommended src/ layout, standard pyproject.toml metadata, a public [project.scripts] entry point, and dependency groups for maintainer tooling.

Destructive remote cleanup is intentionally not implemented. Sparse continuation edits only the case-local restart helper knobs and records the backup name in the receipt.
