hyperglyph-codec 0.7.0

Hyperdimensional symbolic residual compression for neural network weights

Hyper Glyph

Hyperdimensional symbolic residual compression for neural network weights.

Package name: hyperglyph-codec
Project name: Hyper Glyph
Install: pip install hyperglyph-codec
Import: from hyperglyph import HyperGlyphCodec

Hyper Glyph combines:

• Block-level tensor compression for NumPy arrays and neural network weights.
• Symbolic prototype assignment to represent repeated weight patterns compactly.
• Sparse residual repair to preserve reconstruction fidelity after prototype decoding.
• Int8 residual quantization to reduce sparse repair payload size.
• Per-block, per-tensor, and per-channel prototype scales for tuning reconstruction behavior.
• Configurable compression controls for block size, prototype count, residual size, and tensor filtering.
• State dict compression for model-like parameter dictionaries.
• Optional PyTorch support for loading, compressing, restoring, and benchmarking .pt state dicts.
• .hwz serialization for saving compressed models as portable archives.
• Compression reports with size ratio, tensor counts, and reconstruction error metrics.
• Markdown benchmark export with FP32, FP16, INT1 through INT8, and Hyper Glyph comparisons.
• Optional perplexity evaluation on WikiText-2 or C4-style subsets when torch, transformers, and datasets are installed.
• Layer-wise error and ablation helpers for residuals, codebook size, block size, scale modes, and decompressed inference comparisons.
• A small CLI for compressing, decompressing, inspecting, and benchmarking model archives.
• Typed Python API designed for research, experimentation, and extension.

---

Before / After

import numpy as np

from hyperglyph import HyperGlyphCodec, HyperGlyphConfig

state_dict = {
    "layer.weight": np.arange(1024, dtype=np.float32).reshape(32, 32),
}

config = HyperGlyphConfig(
    block_size=16,
    n_prototypes=32,
    residual_k=4,
)

codec = HyperGlyphCodec(config)
compressed = codec.compress_state_dict(state_dict)
restored = codec.decompress_state_dict(compressed)
report = codec.report(compressed, state_dict, restored)

print(report)

Example output:

CompressionReport(
    original_bytes=4096,
    compressed_bytes=...,
    compression_ratio=...,
    tensors_compressed=1,
    tensors_skipped=0,
    total_mse=...,
    total_mae=...,
    max_abs_error=...
)

That is the core job: encode large weight tensors as reusable symbolic prototypes plus a small residual correction, then report the size and reconstruction tradeoff.

Hyper Glyph v0.2.0 is an experimental research codec. It is intended for testing ideas around hyperdimensional and symbolic weight compression rather than guaranteed production compression.

Hyper Glyph v0.3.0 adds compact mode, a byte-packed archive path focused on actual stored bytes rather than theoretical payload estimates. Hyper Glyph v0.6.0 extends the benchmark harness across scalar quantization bit widths from 1 through 8 bits. Hyper Glyph v0.7.0 adds optional open-model evaluation hooks for perplexity, tensor-wise error analysis, ablations, and decompressed inference.

Sample v0.2.0 benchmark from examples/artifacts/sample-v0.2-benchmark.md:

Representation	Bytes	Ratio vs FP32	MSE	MAE	Max abs error
FP32	24576	1.00x	0	0	0
FP16 estimate	12288	2.00x	-	-	-
INT8 estimate	6144	4.00x	-	-	-
Hyper Glyph	22032	1.12x	0.00266153	0.0405458	0.197096

The matching compressed artifact is examples/artifacts/sample-v0.2.hwz and is 26,318 bytes on disk in the current zip-based archive format.

Hyper Glyph Compact Mode

Compact mode moves large payloads out of JSON and into binary streams inside the .hwz archive. v0.6.0 keeps compact_tensor_codec="auto" as the default, so each tensor can choose the best candidate for its byte/error tradeoff. It includes:

• Global codebook and packed assignment utilities for symbolic prototype experiments.
• Packed affine scalar quantization baselines for INT1 through INT8.
• Uint4 assignment packing when the prototype count is 16 or lower.
• Run-length encoding for repeated assignment patterns.
• Grouped/blockwise assignment sharing through assignment_group_size.
• Packed int4 tensor storage when it beats prototype mode on byte/error tradeoffs.
• Low-rank int8 and low-rank plus sparse residual candidates.
• Sparse tensor and raw int8 candidates for small or structured tensors.
• Block-codebook plus sparse residual candidates.
• Float16 or float32 scale metadata, with per-tensor and per-channel scale modes.
• Adaptive sparse residual budget helpers with delta-varint index encoding.
• Optional zstd compression for binary streams via hyperglyph-codec[compression].
• Payload breakdown reporting for metadata, assignments, scales, residuals, and archive size.

Measured on the deterministic synthetic GPT-style benchmark in examples/artifacts/v0.6/benchmark_report.md:

Method	Bytes	Ratio	MSE	Cosine
FP32	918528	1.00x	0	1.00000004
FP16 quantization	459264	2.00x	2.9432538e-10	0.99999992
INT1 quantization	28872	31.81x	0.073967011	0.81135406
INT2 quantization	57576	15.95x	0.0044553082	0.84468936
INT3 quantization	86280	10.65x	0.00077001884	0.95792332
INT4 quantization	114984	7.99x	0.00016693089	0.99027589
INT5 quantization	143688	6.39x	3.9213638e-05	0.99768398
INT6 quantization	172392	5.33x	9.4796408e-06	0.99943803
INT7 quantization	201096	4.57x	2.3378236e-06	0.99986133
INT8 quantization	229800	4.00x	5.783329e-07	0.99996566
Hyper Glyph standard	759603	1.21x	0.00028803079	0.97888187
Hyper Glyph compact codebook	32226	28.50x	0.0052734507	0.47573550
Hyper Glyph compact auto	123776	7.42x	6.6366149e-05	0.99609527
Hyper Glyph compact packed-int4	123155	7.46x	6.6366149e-05	0.99517650

Payload breakdown for Hyper Glyph compact auto:

Payload	Bytes
metadata_bytes	6896
prototype_bytes	0
assignment_bytes	0
scale_bytes	18464
residual_index_bytes	0
residual_value_bytes	0
low_rank_bytes	0
raw_value_bytes	114944
sparse_index_bytes	0
sparse_value_bytes	0
archive_total_bytes	123776

On this benchmark, codebook mode massively reduces archive size but has poor error. Auto mode selects the quality-oriented packed-int4 candidate for these random GPT-style tensors, beats plain INT4 MSE, and reports packed value bytes separately from true codebook assignment bytes.

Beyond Scalar Quantization

Standard INT4 and INT8 quantization round weights independently. The stronger compression literature usually combines vector quantization, pruning, and lossless coding to push practical storage toward the 1- to 2-bit regime without accepting the error profile of naive rounding.

• Extreme vector quantization: learned dictionaries encode groups of weights as shared vectors or codewords instead of independent scalars. AQLM uses additive learned codebooks to keep language-model weight compression competitive below 3 bits per parameter. QuIP# uses randomized Hadamard mixing and high-dimensional lattice codebooks such as E8 for strong results at 4 bits per weight and below.
• Pruning and sparsity: pruning removes redundant weights rather than only lowering their precision. Semi-structured 2:4 sparsity stores two non-zero weights per group of four and maps to supported neural cores. SparseGPT uses second-order approximations to remove unstructured weights while compensating for the dropped connections.
• Entropy and lossless encoding: quantized weights and assignments are not uniformly distributed, so Huffman, ANS, range coding, or zstd-style compression can reduce archive bytes further. EntroLLM-style entropy coding targets frequent patterns with shorter codes. Delta methods such as BitDelta and SVD-based deltas store only fine-tuning differences from a base model, often in 1- or 2-bit form.

Hyper Glyph v0.6.0 does not claim full AQLM, QuIP#, SparseGPT, or EntroLLM implementations. It implements the practical building blocks needed to compare against them: learned block codebooks, sparse residual repair, low-rank plus residual candidates, grouped assignments, run-length and delta-varint streams, optional zstd archive compression, and benchmark rows across every scalar bit width from INT1 through INT8.

Evaluation Suite

v0.7.0 adds evaluation helpers for the heavier checks that should run outside normal CI:

• Perplexity: evaluate_perplexity(...) can evaluate FP32 and optionally decompressed weights on WikiText-2 by default, or on a C4 subset when you pass the dataset name/config. This requires torch, transformers, and datasets.
• Open models: the default model suite includes DistilGPT2, EleutherAI/gpt-neo-125m, facebook/opt-125m, EleutherAI/pythia-70m, and TinyLlama/TinyLlama-1.1B-Chat-v1.0.
• Stronger quantization libraries: available_strong_quantization_libraries() detects optional GPTQ, AWQ, SmoothQuant, bitsandbytes, TorchAO, and Optimum Quanto installs so reports can distinguish plain affine baselines from advanced quantization baselines.
• Layer-wise analysis: tensor_error_analysis(original, restored) reports per-tensor MSE, MAE, max error, cosine, and FP32 bytes.
• Ablations: run_ablation_study(...) compares residuals on/off, codebook size, block size, and scale modes.
• Inference after decompression: compare_inference_after_decompression(...) compares logits from the original model and a copy loaded with restored weights.

Run the optional model-suite example:

python examples/evaluate_model_suite.py --max-samples 16
python examples/evaluate_model_suite.py --dataset c4 --dataset-config en --decompressed

These evaluations can be slow and may download model/data artifacts. Archive size and reconstruction quality are expected to vary by architecture and tensor type. Plain affine INT1-INT8 remains the built-in scalar baseline; GPTQ/AWQ/SmoothQuant comparisons are detected and should be run through their respective libraries when installed.

---

Why Hyperdimensional Weight Compression?

Neural network weights often contain repeated local structure, approximate patterns, and redundancy that can be represented more compactly than raw floating-point tensors:

Weight tensors
  -> Split into fixed-size blocks
  -> Learn reusable prototype blocks
  -> Assign each block to a prototype
  -> Store per-block scales
  -> Store sparse top-k residual corrections as int8 or float32

  -> Save compressed archive
  -> Restore approximate tensors
  -> Report compression and reconstruction metrics

Hyper Glyph is designed for experiments where you want to inspect that tradeoff directly:

• Large weight matrices that can be split into repeated local blocks.
• Prototype-based compression where blocks share learned representatives.
• Sparse residual repair where only the largest reconstruction corrections are stored.
• Scale modes for per-block, per-tensor, or per-channel prototype scaling.
• Approximate reconstruction with measurable MSE, MAE, and max absolute error.
• State dict workflows that match common PyTorch model storage patterns.
• Portable archive output for saving and inspecting compressed runs.

---

Why Not Just Quantization?

Quantization changes the numeric precision of individual weights. Hyper Glyph uses a different representation: each tensor block is mapped to a learned prototype, scaled, and repaired with a sparse residual.

That makes Hyper Glyph useful for experimenting with symbolic and hyperdimensional compression ideas, not as a drop-in replacement for mature quantization, pruning, or production model compression toolchains.

---

Architecture

Input weights
  - NumPy arrays
  - PyTorch state_dict values
    |
    v
Compression
  - tensor filtering
  - block splitting
  - prototype learning
  - prototype assignment
  - scale calculation
  - int8 or float32 sparse residual encoding
    |
    v
CompressedModel
  - compressed tensors
  - shapes
  - prototype ids
  - scales
  - residuals
  - prototype matrices
  - codec metadata
    |
    v
Decompression and report
  - reconstructed tensors
  - original/compressed byte estimates
  - compression ratio
  - MSE / MAE / max error

---

Install

pip install hyperglyph-codec

For PyTorch state dict support:

pip install "hyperglyph-codec[torch]"

For compact archives with optional zstd compression:

pip install "hyperglyph-codec[torch,compression]"

For documentation dependencies:

pip install "hyperglyph-codec[docs]"

For development:

pip install -e ".[dev,torch,docs]"
pytest
python -m build

---

Quick Start

Compress a NumPy State Dict

import numpy as np

from hyperglyph import HyperGlyphCodec, HyperGlyphConfig

state_dict = {
    "weight": np.arange(256, dtype=np.float32).reshape(16, 16),
}

config = HyperGlyphConfig(
    block_size=8,
    n_prototypes=8,
    residual_k=2,
)

codec = HyperGlyphCodec(config)
compressed = codec.compress_state_dict(state_dict)
restored = codec.decompress_state_dict(compressed)

print(restored["weight"].shape)

Compress a PyTorch Model

import torch

from hyperglyph import HyperGlyphCodec, HyperGlyphConfig

model = torch.nn.Sequential(
    torch.nn.Linear(32, 32),
    torch.nn.ReLU(),
    torch.nn.Linear(32, 8),
)

config = HyperGlyphConfig(
    block_size=16,
    n_prototypes=16,
    residual_k=4,
    residual_dtype="int8",
    scale_mode="block",
)

codec = HyperGlyphCodec(config)
compressed = codec.compress_state_dict(model.state_dict())
restored = codec.decompress_state_dict(compressed)

print(f"Compressed tensors: {len(compressed.tensors)}")
print(f"Restored keys: {sorted(restored)}")

Save and Load .hwz Archives

from hyperglyph import load_compressed, save_compressed

save_compressed(compressed, "model.hwz")
loaded = load_compressed("model.hwz")
restored = codec.decompress_state_dict(loaded)

Generate a Report

report = codec.report(
    compressed_model=compressed,
    original_state_dict=state_dict,
    restored_state_dict=restored,
)

print(report.compression_ratio)
print(report.total_mse)
print(report.max_abs_error)

---

CLI

Compress a PyTorch state dict into a .hwz archive:

hyperglyph compress model.pt model.hwz

Use compact mode and a target ratio:

hyperglyph compress gpt2.pt gpt2.hwz --mode compact --target-ratio 8
hyperglyph inspect gpt2.hwz

Tune compression settings:

hyperglyph compress model.pt model.hwz \
  --block-size 16 \
  --hdc-dim 4096 \
  --n-buckets 16 \
  --n-prototypes 128 \
  --residual-k 8 \
  --residual-dtype int8 \
  --scale-mode per_channel \
  --min-tensor-size 256

Restore a compressed archive back to a PyTorch state dict:

hyperglyph decompress model.hwz restored.pt

Inspect archive metadata:

hyperglyph inspect model.hwz

Benchmark compression and reconstruction:

hyperglyph benchmark model.pt

Benchmark compact mode:

hyperglyph benchmark model.pt --mode compact

Export the benchmark as markdown:

hyperglyph benchmark model.pt --markdown-output benchmark.md

---

Benchmark Example

A small practical benchmark is enough to see the current codec behavior:

hyperglyph benchmark model.pt

Example markdown output:

| Representation | Bytes | Ratio vs FP32 | MSE | MAE | Max abs error |
| FP32 | 24576 | 1.00x | 0 | 0 | 0 |
| FP16 estimate | 12288 | 2.00x | - | - | - |
| INT8 estimate | 6144 | 4.00x | - | - | - |
| Hyper Glyph | 22032 | 1.12x | 0.00266153 | 0.0405458 | 0.197096 |

The current package focuses on transparent compression experiments rather than claiming universal size reductions. Compare the restored model against your own accuracy, latency, and reconstruction thresholds.

---

Main Features

1. Configurable Codec

Tune the compression shape with one dataclass:

from hyperglyph import HyperGlyphConfig

config = HyperGlyphConfig(
    hdc_dim=4096,
    block_size=16,
    n_buckets=16,
    n_prototypes=128,
    residual_k=8,
    residual_dtype="int8",
    scale_mode="channel",
    seed=42,
    min_tensor_size=256,
    compress_bias=False,
)

2. Array Compression

Compress and reconstruct a single NumPy array:

import numpy as np

from hyperglyph import HyperGlyphCodec

codec = HyperGlyphCodec()
array = np.random.randn(64, 64).astype("float32")

compressed = codec.compress_array("layer.weight", array)
restored = codec.decompress_array(compressed)

3. State Dict Compression

Compress dictionary-style model weights:

compressed = codec.compress_state_dict(state_dict)
restored = codec.decompress_state_dict(compressed)

By default, small tensors and bias tensors are skipped. Set min_tensor_size and compress_bias in HyperGlyphConfig to change that behavior.

4. Sparse Residual Repair

Each block is reconstructed from a prototype and scale, then corrected with a top-k sparse residual:

block ~= prototype[prototype_id] * scale + sparse_residual

Increase residual_k for better reconstruction fidelity, or reduce it for a smaller compressed representation.

Set residual_dtype="int8" to quantize sparse residual values. Use residual_dtype="float32" when you want unquantized residual repairs.

5. Serialization

Save compressed models as .hwz zip archives:

from hyperglyph import load_compressed, save_compressed

save_compressed(compressed, "model.hwz")
loaded = load_compressed("model.hwz")

6. PyTorch Adapter

Install the torch extra to convert PyTorch tensors into compressed Hyper Glyph models:

from hyperglyph import compress_state_dict, decompress_state_dict

compressed = compress_state_dict(model.state_dict())
restored = decompress_state_dict(compressed, reference_state_dict=model.state_dict())

7. Compression Metrics

Measure the compression and reconstruction tradeoff:

report = codec.report(compressed, state_dict, restored)

print(report.original_bytes)
print(report.compressed_bytes)
print(report.compression_ratio)
print(report.total_mse)
print(report.total_mae)
print(report.max_abs_error)

---

Configuration

from hyperglyph import HyperGlyphConfig

config = HyperGlyphConfig(
    hdc_dim=4096,
    block_size=16,
    n_buckets=16,
    n_prototypes=128,
    residual_k=8,
    residual_dtype="int8",
    scale_mode="block",
    seed=42,
    min_tensor_size=256,
    compress_bias=False,
    dtype="float32",
    device="cpu",
)

Key settings:

• block_size controls how many flattened weights are grouped together.
• n_prototypes controls how many reusable block representatives are learned.
• residual_k controls how many residual correction values are stored per block.
• residual_dtype controls whether sparse residual values are stored as int8 or float32.
• scale_mode controls whether prototype scales are calculated per block, per tensor, or per channel.
• min_tensor_size skips tensors too small to benefit from compression.
• compress_bias enables compression for bias tensors, which are skipped by default.
• seed makes prototype selection deterministic.

---

Examples

import numpy as np

from hyperglyph import HyperGlyphCodec, HyperGlyphConfig

state_dict = {
    "encoder.weight": np.random.randn(128, 128).astype("float32"),
    "decoder.weight": np.random.randn(128, 64).astype("float32"),
}

codec = HyperGlyphCodec(
    HyperGlyphConfig(
        block_size=16,
        n_prototypes=64,
        residual_k=8,
        residual_dtype="int8",
        scale_mode="channel",
    )
)

compressed = codec.compress_state_dict(state_dict)
restored = codec.decompress_state_dict(compressed)
report = codec.report(compressed, state_dict, restored)

print(report)

hyperglyph compress model.pt model.hwz
hyperglyph inspect model.hwz
hyperglyph benchmark model.pt

---

Project Structure

src/hyperglyph/
  __init__.py             # Public API
  archive.py              # Compact .hwz binary stream archive helpers
  benchmark.py            # Benchmark report helpers
  blocks.py               # Tensor flattening, block splitting, shape restore
  cli.py                  # Command-line interface
  codec.py                # HyperGlyphCodec and compressed dataclasses
  compact_codec.py        # CompactHyperGlyphCodec
  config.py               # HyperGlyphConfig
  exceptions.py           # Package exceptions
  global_codebook.py      # Global prototype collection and assignment helpers
  hdc.py                  # Hyperdimensional vector helpers
  metrics.py              # Size and reconstruction metrics
  packing.py              # uint4/int4/varint/delta packing helpers
  prototypes.py           # Prototype learning and assignment
  evaluation.py           # Perplexity, ablation, tensor-error, and inference helpers
  quantization.py         # int1-int8 affine quantization helpers
  residual.py             # Sparse residual encoding and repair
  residual_budget.py      # Adaptive residual budget helpers
  serialization.py        # .hwz save/load helpers
  torch_adapter.py        # Optional PyTorch integration
  py.typed                # Typing marker
tests/
  test_*.py               # Unit tests
docs/
  algorithm.md            # Algorithm overview
  api.md                  # API notes
  cli.md                  # CLI examples
  index.md                # Documentation home
  roadmap.md              # Planned work
examples/
  compress_mlp.py         # PyTorch MLP compression example
  compress_state_dict.py  # NumPy state dict compression example
  mnist_demo.py           # MNIST-oriented demo
  benchmark_hyperglyph_vs_quant.py # FP32/FP16/INT1-INT8/Hyper Glyph benchmark
  evaluate_model_suite.py          # Optional open-model perplexity evaluation
  artifacts/
    sample-v0.2.hwz       # Example compressed archive
    sample-v0.2-benchmark.md # Markdown benchmark report
hyperglyph.png            # Project logo
pyproject.toml            # Package metadata and dependencies
CHANGELOG.md              # Release history
CONTRIBUTING.md           # Contribution guide
LICENSE                   # MIT license

---

Development

# Install with dev, PyTorch, and docs extras
pip install -e ".[dev,torch,docs]"

# Run tests
pytest

# Run linting
ruff check .

# Type-check package code
mypy

# Build package
python -m build

---

License

MIT

---

Contributing

Contributions are welcome. Open an issue or pull request with the model shape, codec configuration, expected compression behavior, reconstruction metrics, and any accuracy checks you used.

---

Citation

If you use Hyper Glyph in research, please cite:

@software{HyperGlyph2026,
  title={Hyper Glyph: Hyperdimensional Symbolic Residual Compression for Neural Network Weights},
  author={Robert McMenemy},
  year={2026},
  version={0.7.0},
}
