hypershap 0.0.6

HyperSHAP is a post-hoc explanation method for hyperparameter optimization.

HyperSHAP

HyperSHAP – a game‑theoretic Python library for explaining Hyperparameter Optimization (HPO). It uses Shapley values and interaction indices to provide both local and global insights into how individual hyper‑parameters (and their interactions) affect a model’s performance.

• Github repository: https://github.com/automl/HyperSHAP/
• Documentation https://automl.github.io/HyperSHAP/

Table of Contents

• Features
• Installation
• Getting Started
• API Overview
• Example Notebook
• Citation
• Contributing
• License

---

Features

• Additive Shapley decomposition of any performance metric across hyper‑parameters.
• Interaction analysis via the Faithful Shapley Interaction Index (FSII).
• Ready‑made explanation tasks for Ablation, Tunability, and Optimizer Bias studies.
• Integrated visualisation (SI‑graph) for interaction effects.
• Works with any surrogate model that follows the ExplanationTask interface.

---

Installation

First, create a virtual environment, e.g., via conda:

$ conda create -n hypershap python=3.10
$ conda activate hypershap

Now, you can just pip install HyperSHAP as follows:

$ pip install hypershap

Or, clone the git repository and install hypershap via the Makefile:

$ git clone https://github.com/automl/hypershap
$ cd hypershap
$ make install

Getting Started

Given an existing setup with a ConfigurationSpace from the ConfigSpace package and black-box function as follows:

from ConfigSpace import ConfigurationSpace, Configuration

# ConfigurationSpace describing the hyperparameter space
cs = ConfigurationSpace()
  ...

# A black-box function, evaluating ConfigSpace.Configuration objects
def blackbox_function(cfg: Configuration) -> float:
  ...

You can use HyperSHAP as follows:

from hypershap import ExplanationTask, HyperSHAP

# Instantiate HyperSHAP
hypershap = HyperSHAP(ExplanationTask.from_function(config_space=cs,function=blackbox_function))
# Conduct tunability analysis
hypershap.tunability(baseline_config=cs.get_default_configuration())
# Plot results as a Shapley Interaction graph
hypershap.plot_si_graph()

The example demonstrates how to:

1. Wrap a black-box function in an explanation task.
2. Use HyperSHAP to obtain interaction values for the tunability game.
3. Plot the corresponding SI-graph.

---

API Overview

Method	Purpose
HyperSHAP(explanation_task, n_workers, max_hyperparameters_exact, approximation_budget)	Initialize the explainer with a generic ExplanationTask. Optionally, you may activate parallelization by setting n_workers to the number of CPU cores you would like to use for parallelization. max_hyperparameters_exact determines until which number of hyperparameters exact Shapley values will be computed and beyond which a budget of approximation_budget will be used to approximate them.
ablation(config_of_interest, baseline_config, index="FSII", order=2)	Explain the contribution of each hyperparameter value (and interactions) when moving from a baseline to a specific configuration.
ablation_multibaseline(config_of_interest, baseline_config, aggregation, index="FSII", order=2)	Explain the contribution of each hyperparameter value (and interactions) when moving from different baselines to a specific configuration. Values are aggregated via a given aggregation operator.
tunability(baseline_config=None, index="FSII", order=2, n_samples=10_000)	Quantify how much performance can be gained by tuning subsets of hyperparameters.
sensitivity(baseline_config=None, index="FSII", order=2, n_samples=10_000)	Quantify how much performance variance can be gained by varying subsets of hyperparameters.
mistunability(baseline_config=None, index="FSII", order=2, n_samples=10_000)	Quantify how much performance can be lost due to mistuning a (subsets of) hyperparameter(s).
optimizer_bias(optimizer_of_interest, optimizer_ensemble, index="FSII", order=2)	Attribute performance differences to a particular optimizer vs. an ensemble of optimizers.
plot_si_graph(interaction_values=None, save_path=None)	Plot the Shapley Interaction (SI) graph; uses the most recent interaction values if none are supplied.
plot_upset(interaction_values=None, save_path=None)	Plot interaction values in the form of an upset plot; uses the most recent interaction values if none are supplied.
plot_force(interaction_values=None, save_path=None)	Plot interaction values in the form of a force plot; uses the most recent interaction values if none are supplied.
plot_waterfall(interaction_values=None, save_path=None)	Plot interaction values in the form of a waterfall plot; uses the most recent interaction values if none are supplied.
plot_stacked_bar(interaction_values=None, save_path=None)	Plot summaries of interaction values as stacked bar charts with a bar per interaction order; uses the most recent interaction values if none are supplied.
get_interaction_values_with_names(interaction_values=None)	Get interaction values dictionary with names of the hyperparameters instead of IDs.
ExplanationTask.get_hyperparameter_names()	Helper to retrieve ordered hyper‑parameter names (used for visualisation).

All methods return an InteractionValues object (from shapiq) that can be inspected, saved, or passed to the visualisation routine.

---

Example Notebooks

Full Jupyter notebooks illustrating all three explanation tasks (ablation, tunability, optimizer bias) are included in the repository under examples/. The notebookts walk through:

• Building a mockup environment
• Creating the corresponding explanation task
• Loading explanation tasks from different setups: data, black-box function, and existing surrogate model.
• Computing interaction values with HyperSHAP
• Visualizing results with plot_si_graph

---

Citation

If you use HyperSHAP in your research, please cite the original paper:

@article{wever-arxiv25,
  author       = {Marcel Wever and
                  Maximilian Muschalik and
                  Fabian Fumagalli and
                  Marius Lindauer},
  title        = {HyperSHAP: Shapley Values and Interactions for Hyperparameter Importance},
  journal      = {CoRR},
  volume       = {abs/2502.01276},
  year         = {2025},
  doi          = {10.48550/ARXIV.2502.01276},
}

The paper introduces the underlying game-theoretic framework and demonstrates its usefulness for HPO explainability.

Contributing

Contributions are welcome! Please follow these steps:

1. Fork the repo and create a feature branch (git checkout -b feat/your-feature).
2. Write tests (the project uses pytest).
3. Ensure all tests pass (pytest).
4. Update documentation if you add new functionality.
5. Submit a Pull Request with a clear description of the changes.

See CONTRIBUTING.md for detailed guidelines.

---

License

HyperSHAP is released under the BSD 3-Clause License. See the LICENSE file for full terms.

---

Enjoy exploring your HPO pipelines with HyperSHAP! 🎉

---

Repository initiated with fpgmaas/cookiecutter-uv.
