iam-security-scanner 1.0.0

Comprehensive AWS IAM security scanner with multi-framework compliance mapping

A comprehensive AWS IAM security scanner with 44 security checks across 7 categories and compliance mapping for 10 frameworks (128 controls). Includes privilege-escalation and confused-deputy detection, multi-threaded scanning, credential report analysis, and interactive HTML dashboards.

Key Features

Comprehensive Security Analysis

• User Security: Root access keys, MFA enforcement (hardware vs virtual), key rotation, unused credentials, console access without MFA
• Password Policy: Minimum length, complexity requirements, reuse prevention, max age validation
• Policy Security: Admin privilege detection, wildcard service permissions, PassRole on *, NotAction abuse, unused policies
• Role Security: Wildcard trust principals, overprivileged roles, unused roles, service-linked role exclusion
• Privilege Escalation & Trust: 22 documented privesc paths (managed + inline), permissive sts:AssumeRole *, confused-deputy / cross-account trust (Org-aware)
• Group Security: Admin groups, empty groups, users not assigned to groups
• Account Settings: IAM Access Analyzer (external + unused-access + findings), support role, expired certificates, CloudShell access, IAM server certificates

Compliance Frameworks

• AWS Foundational Security Best Practices (FSBP): 22 IAM-specific controls
• CIS AWS Foundations Benchmark v5.0.0: 13 controls
• PCI DSS v4.0.1: 12 controls
• HIPAA Security Rule: 11 controls
• SOC 2: 14 controls
• ISO 27001:2022: 13 controls
• ISO 27017:2015: 8 cloud security controls
• ISO 27018:2019: 6 PII protection controls
• GDPR (EU) 2016/679: 8 controls
• NIST SP 800-53 Rev5: 21 controls

Performance & Usability

• Multi-threaded Scanning: Parallel category analysis with ThreadPoolExecutor (6 workers)
• Rich Console Output: Progress bars, colored output, and formatted tables
• Multiple Report Formats: JSON, CSV, HTML, and compliance-specific reports
• Beautiful HTML Reports: Interactive dashboard with Chart.js visualizations
• Exponential Backoff: Automatic retry with jitter for API throttling

Production Ready

• Modular Architecture: Facade pattern with 8 dedicated checker modules
• Thread-safe Sessions: Session factory per-thread boto3 session management
• Graceful Degradation: AccessDenied errors don't crash scans
• Non-stacking Scoring: Overlapping MFA penalties (A.4/A.10) use highest only
• Fail-safe Isolation: One category failure doesn't crash other checks

Quick Start

Installation

# Install from source
git clone https://github.com/TocConsulting/iam-security-scanner.git
cd iam-security-scanner
pip install .

Docker Installation

# Build from source
docker build -t iam-security-scanner .

Basic Usage

# Scan IAM configuration
iam-security-scanner security

# Scan with specific AWS profile
iam-security-scanner security --profile production

# Scan a specific region
iam-security-scanner security -r eu-west-1

# Compliance report only
iam-security-scanner security --compliance-only

# JSON report only, quiet mode (for CI/CD)
iam-security-scanner security -f json -q

Commands

Security Command

Scan IAM configuration for security vulnerabilities and compliance issues.

iam-security-scanner security [OPTIONS]

Options:
  -r, --region TEXT              AWS region (default: us-east-1)
  -p, --profile TEXT             AWS profile name
  -o, --output-dir TEXT          Output directory (default: ./output)
  -f, --output-format TEXT       Report format: json, csv, html, all (default: all)
  -w, --max-workers INTEGER      Worker threads 1-10 (default: 6)
  --compliance-only              Generate compliance report only
  -q, --quiet                    Suppress console output except errors
  -d, --debug                    Enable debug logging
  -h, --help                     Show help

# Top-level options (before the 'security' command):
#   iam-security-scanner --version
#   iam-security-scanner --help

Examples:

# Scan with all report formats
iam-security-scanner security -f all

# Fast compliance-only scan with HTML output
iam-security-scanner security --compliance-only -f html -p production

# Scan with more threads
iam-security-scanner security -w 10 -r eu-west-1

# JSON report only, quiet mode (for CI/CD)
iam-security-scanner security -f json -q

Docker Usage

Basic Docker Commands

# Show help
docker run --rm iam-security-scanner --help

# Show security command help
docker run --rm iam-security-scanner security --help

Security Scanning with Docker

# Scan using mounted AWS credentials
docker run --rm \
  -v ~/.aws:/root/.aws:ro \
  -v $(pwd)/output:/app/output \
  iam-security-scanner security

# Scan with specific AWS profile
docker run --rm \
  -v ~/.aws:/root/.aws:ro \
  -v $(pwd)/output:/app/output \
  iam-security-scanner security --profile production

Using Environment Variables for AWS Credentials

docker run --rm \
  -e AWS_ACCESS_KEY_ID \
  -e AWS_SECRET_ACCESS_KEY \
  -e AWS_DEFAULT_REGION=us-east-1 \
  -v $(pwd)/output:/app/output \
  iam-security-scanner security

# With session token (for temporary credentials/assumed roles)
docker run --rm \
  -e AWS_ACCESS_KEY_ID \
  -e AWS_SECRET_ACCESS_KEY \
  -e AWS_SESSION_TOKEN \
  -e AWS_DEFAULT_REGION=us-east-1 \
  -v $(pwd)/output:/app/output \
  iam-security-scanner security

Docker Volume Mounts

Mount	Purpose
-v ~/.aws:/root/.aws:ro	Mount AWS credentials (read-only)
-v $(pwd)/output:/app/output	Save reports to local directory

Prerequisites

Python Requirements

• Python 3.10 or higher
• Required packages (installed automatically):
  • boto3>=1.28.0
  • botocore>=1.31.0
  • rich>=13.0.0
  • click>=8.1.0
  • jinja2>=3.1.0

AWS Requirements

• AWS credentials configured (via AWS CLI, environment variables, or IAM roles)
• Required permissions:

{
    "Version": "2012-10-17",
    "Statement": [
        {
            "Effect": "Allow",
            "Action": [
                "iam:GenerateCredentialReport",
                "iam:GetCredentialReport",
                "iam:GetAccountPasswordPolicy",
                "iam:ListUsers",
                "iam:ListRoles",
                "iam:ListGroups",
                "iam:ListPolicies",
                "iam:GetPolicyVersion",
                "iam:ListAttachedUserPolicies",
                "iam:ListUserPolicies",
                "iam:ListAttachedRolePolicies",
                "iam:ListRolePolicies",
                "iam:ListAttachedGroupPolicies",
                "iam:ListGroupPolicies",
                "iam:GetGroup",
                "iam:ListGroupsForUser",
                "iam:ListVirtualMFADevices",
                "iam:ListServerCertificates",
                "iam:ListEntitiesForPolicy",
                "iam:GetRolePolicy",
                "iam:GetGroupPolicy",
                "access-analyzer:ListAnalyzers",
                "access-analyzer:ListFindings",
                "sts:GetCallerIdentity"
            ],
            "Resource": "*"
        }
    ]
}

Security Checks

44 Checks Across 7 Categories

#	Category	Checks	Focus
A	User & Credential Security	12	Root access keys, MFA (hardware/virtual), key rotation, unused credentials, console MFA, direct policies, direct admin
B	Password Policy	8	No policy, min length, uppercase, lowercase, numbers, symbols, reuse prevention, max age
C	Managed Policy Security	5	Admin privileges, wildcard service access, PassRole on *, NotAction abuse, unused policies
D	Role Security	4	Admin roles, wildcard trust principals, overprivileged roles, unused roles
E	Group Security	3	Admin groups, empty groups, users not in groups
F	Account Settings	7	Access Analyzer (external + unused-access + findings), support role, expired certs, CloudShell, IAM certificates
G	Privilege Escalation & Trust	5	Privesc (managed + inline), permissive AssumeRole, confused-deputy, cross-account trust

See security-checks.md for every check and compliance.md for framework mappings.

Modular Architecture

iam_security_scanner/
├── scanner.py                  # Main scanner orchestration (facade pattern)
├── cli.py                      # Click CLI interface
├── compliance.py               # 128 controls across 10 frameworks
├── html_reporter.py            # Jinja2 HTML report generation
├── utils.py                    # Logging, scoring, formatting
├── checks/                     # Security check modules
│   ├── base.py                 # BaseChecker (session factory, backoff)
│   ├── user_security.py        # A.1-A.12: Root, MFA, keys, credentials, direct admin
│   ├── password_policy.py      # B.1-B.8: Password policy validation
│   ├── policy_security.py      # C.1-C.5: Managed policy analysis
│   ├── role_security.py        # D.1-D.5: Role trust and privilege
│   ├── group_security.py       # E.1-E.3: Group membership
│   ├── account_settings.py     # F.1-F.7: Access Analyzer, certs, CloudShell
│   ├── privilege_escalation.py # G.1-G.3: Privesc paths, permissive AssumeRole
│   └── trust_analysis.py       # G.4-G.5: Confused-deputy, cross-account trust
└── templates/
    └── report.html             # Interactive HTML dashboard

Security Scoring

Each account receives a security score (0-100) starting at 100 points:

Security Issue	Points Deducted	Severity
Root access keys exist	-25	CRITICAL
Root MFA not enabled	-25	CRITICAL
Root virtual MFA (not hardware)	-5	CRITICAL
Wildcard trust principal roles	-20	CRITICAL
Privilege escalation paths (managed/inline, non-stacking)	-20	CRITICAL
Admin policies (Action:* Resource:*)	-15	HIGH
Users with AdministratorAccess attached directly	-15	HIGH
Admin roles	-15	HIGH
PassRole on *	-10	HIGH
Access Analyzer disabled	-10	HIGH
Admin groups	-10	HIGH
Overprivileged roles	-10	HIGH
Access Analyzer findings	-10	HIGH
Permissive sts:AssumeRole on *	-10	HIGH
Cross-account trust missing guard (confused-deputy)	-10	HIGH
Users without MFA (non-stacking)	-10	MEDIUM
Console users without MFA (non-stacking)	-15	MEDIUM
Old access keys (>90 days)	-10	MEDIUM
Unused credentials (>45 days)	-8	MEDIUM
Users not in groups	-5	MEDIUM
Cross-account roles	-5	MEDIUM
Expired certificates	-5	MEDIUM
CloudShell full access	-5	MEDIUM
No unused-access Access Analyzer	-3	MEDIUM
Password policy: weak length	-5	MEDIUM
Password policy: no uppercase	-3	MEDIUM
Password policy: no lowercase	-3	MEDIUM
Password policy: no numbers	-3	MEDIUM
Password policy: no symbols	-3	MEDIUM
Wildcard service policies	-3	MEDIUM
NotAction policies	-3	MEDIUM
Direct attached user policies	-5	LOW
Password policy: no reuse prevention	-2	LOW
Password policy: no max age	-2	LOW
Inline user policies	-2	LOW
Multiple access keys	-2	LOW
No support role	-2	LOW
Empty groups	-2	LOW
Unused policies	-2	LOW
Unused roles	-2	LOW
Root used recently	-2	LOW
IAM server certificates	-1	LOW

Non-stacking MFA Penalties

Overlapping MFA checks (A.4 users_without_mfa and A.10 console_no_mfa) use the highest penalty only to avoid double-counting:

• Users without MFA = -10, Console without MFA = -15 -> only -15 applied

No Password Policy

If no password policy exists, all B.1-B.7 penalties apply simultaneously (-21 total).

Formula: Score = max(0, 100 - total_deductions)

Score Interpretation

Score Range	Level	Action
90-100	Excellent	Maintain current posture
70-89	Good	Address minor gaps
50-69	Needs Improvement	Fix medium-priority issues
0-49	Critical	Immediate action required

Output Files

The scanner generates reports in the specified output directory:

JSON Report (iam_scan_timestamp.json)

{
  "summary": {
    "scan_time": "2026-03-11T10:30:45",
    "region": "us-east-1",
    "account_id": "123456789012",
    "security_score": 78.5
  },
  "checks": {...},
  "issues": [...],
  "compliance": {...}
}

CSV Report (iam_scan_timestamp.csv)

Spreadsheet-friendly format with all findings, severity levels, and compliance status.

HTML Report (iam_scan_timestamp.html)

Interactive dashboard with:

• Executive Summary: Key metrics and risk indicators
• Security Score: Visual score card with color coding
• Findings Table: All issues sorted by severity
• Compliance Grid: Pass/fail status across all 10 frameworks
• Score Breakdown: Bar chart of deductions by category

Development

Setting Up Development Environment

git clone https://github.com/TocConsulting/iam-security-scanner.git
cd iam-security-scanner

python -m venv venv
source venv/bin/activate

pip install -e ".[dev]"

Testing

# Install development dependencies
pip install -e ".[dev]"

# Run all tests
python -m pytest tests/ -v

# Run specific test file
python -m pytest tests/test_compliance.py -v

# Run with coverage
python -m pytest tests/ --cov=iam_security_scanner --cov-report=html

Test Structure

tests/
├── test_cli.py                 # CLI option and command tests
├── test_compliance.py          # 128 controls, 10 frameworks validation
├── test_scoring.py             # Non-stacking scoring logic
├── test_user_security.py       # A.1-A.11 checks (root, MFA, keys)
├── test_password_policy.py     # B.1-B.7 checks (policy validation)
├── test_policy_security.py     # C.1-C.5 checks (admin, wildcard)
├── test_role_security.py       # D.1-D.5 checks (trust, cross-account)
├── test_group_security.py      # E.1-E.3 checks (membership)
├── test_account_settings.py    # F.1-F.6 checks (analyzer, certs)
└── test_scanner.py             # Scanner orchestration tests

Tests use unittest.mock for AWS service mocking, allowing comprehensive testing without AWS resources.

Support & Contributing

Getting Help

• Documentation: Check this README and inline help (--help)
• Issues: Report bugs via GitHub Issues

Contributing

We welcome contributions! Please:

1. Fork the repository
2. Create a feature branch
3. Add tests for new functionality
4. Submit a pull request

License

This project is licensed under the MIT License - see the LICENSE file for details.

Acknowledgments

• AWS Security Best Practices: Based on official AWS security recommendations
• CIS Benchmarks: Implements CIS AWS Foundations Benchmark v5.0.0 controls
• ec2-security-scanner: Architecture and design patterns
• s3-security-scanner: Original scanner framework

---

Security Notice: This tool is designed for defensive security purposes only. Always ensure you have proper authorization before scanning AWS resources. The tool requires read-only permissions and does not modify any AWS resources.

Performance Note: The scanner uses account-level scanning with parallel category execution (6 threads). Credential report generation is async with polling. Exponential backoff handles API throttling automatically. Use -w to adjust parallelism.
