IBKR Authentication Workflow

Interactive Brokers provides an extensive API that can be used for trading and account management.

It's also possible to authenticate for the API via OAuth.

ibauth is a Python client for handling the full Interactive Brokers (IBKR) Web API authentication flow. It wraps the OAuth2 + session lifecycle steps (access_token, bearer_token, ssodh_init, tickle, etc.) into a simple, reusable interface.

🔑 Features:

• Obtain and refresh IBKR OAuth2 tokens.
• Manage brokerage sessions (ssodh_init, validate_sso, tickle, logout).
• YAML-based configuration (easy to keep credentials outside of code).
• Logging of requests and responses for troubleshooting.

Documentation for the IBKR Web API can be found in the official reference.

Requirements

• Python 3.11+
• A valid IBKR account with Web API access enabled.
• An RSA private key (.pem) registered with IBKR.

Installation

You can install either from PyPI (preferred) or GitHub (which may give access to updates not yet published on PyPI).

# Install from PyPI.
uv add ibauth
pip install ibauth

# Install from GitHub.
uv add "git+https://github.com/datawookie/ibkr-oauth-flow"
pip install "git+https://github.com/datawookie/ibkr-oauth-flow"

Getting Started

The package implements authentication via the IBAuth class. There are two approaches to instantiating this class:

• directly via the constructor or
• using the auth_from_yaml() factory function.

Authenticator Objects

Instantiate a IBAuth object (illustrative values for constructor parameters):

from ibauth import IBAuth

auth = IBAuth(
  client_id = "Authenticator-Client",
  client_key_id = "main",
  credential = "DiV7hxH5yXAN5x",
  private_key_file = "/path/to/ibkr-private-key.pem",
)

where

• client_id — client ID;
• client_key_id — key identifier associated with your private key;
• credential — credential string; and
• private_key_file — path to your RSA private key (.pem).

There are optional arguments:

• timeout — timeout (seconds) applied to all network requests.

Configuration File

A more flexible approach is to create a YAML configuration file rather than baking those values into your code. You can copy config.example.yaml to config.yaml and fill in your credentials. The file might look something like this:

client_id: "Authenticator-Client"
client_key_id: "main"
credential: "DiV7hxH5yXAN5x"
private_key_file: "/path/to/ibkr-private-key.pem"

Then use the factory function:

from ibauth import auth_from_yaml

auth = auth_from_yaml("config.yaml")

Methods

Use the following public methods:

• connect() — run the authentication flow to connect to the API; and
• tickle() — keep the API connection alive.

Attributes

These are some useful attributes:

• bearer_token — the bearer token acquired during the authentication flow;
• header — the authentication header (as a dictionary);
• authenticated — are we authenticated?;
• connected — are we connected?; and
• competing — is there a competing connection?

The authenticated, connected and competing attributes are set and updated by running the tickle() method.

Development

Clone the repo and install dependencies into a virtual environment:

git clone https://github.com/datawookie/ibkr-oauth-flow.git
cd ibkr-oauth-flow
uv sync

You can test the authentication workflow:

# Use config.yaml in current directory.
uv run ibauth
# Use config.yaml in home directory and include debugging output.
uv run ibauth --config ~/config.yaml --debug

Test Suite

This project uses pytest. To run the test suite:

uv run pytest

To include coverage:

uv run pytest --cov=.

Deploy to PyPI

This requires UV_PUBLISH_TOKEN to be set to a PyPi token in environment.

make deploy
