iflow-mcp_geo-joy_mcp-elicitation-example 0.1.0

MCP elicitation demo - interactive table booking system

MCP Elicitation Demo: Interactive

A demonstration of the Model Context Protocol (MCP) with intelligent elicitation capabilities for interactive data gathering. This project showcases how an MCP server can dynamically request information from clients when needed.

Demo Video

Overview

This demo implements a restaurant table booking system that demonstrates MCP's elicitation feature. The server can intelligently request missing or invalid data from the client through interactive prompts.

Features

• Intelligent Elicitation: Server requests missing parameters dynamically
• Input Validation: Validates dates, party sizes, and other booking details
• Error Handling: Graceful handling of user cancellations and errors
• Multiple Scenarios: Supports various booking scenarios for testing
• Type Safety: Full type hints and Pydantic schema validation

Project Structure

mcp-elicitation-example/
├── .gitignore              # Git ignore patterns
├── .python-version         # Python version specification
├── elicitation-server.py   # MCP server with booking tool
├── elicitation-client.py   # Interactive client for testing
├── pyproject.toml          # Project dependencies and configuration
├── README.md              # This file
└── uv.lock                # Dependency lock file

Installation

1. Clone the repository (if not already done):

   git clone <repository-url>
   cd mcp-elicitation-example


2. Install dependencies using uv:

   uv sync


   This will automatically:

   • Create a virtual environment with Python 3.11+
   • Install all dependencies from pyproject.toml
   • Lock dependencies in uv.lock for reproducible builds

   Note: No need to manually create or activate a virtual environment - uv handles this automatically!

   Alternative (using pip):

   python -m venv venv
   source venv/bin/activate  # On Windows: venv\Scripts\activate
   pip install -e .


Usage

Running the Server

Start the MCP server in one terminal:

uv run python elicitation-server.py

The server will start on http://localhost:8000/mcp by default.

Running the Client

In another terminal, run the interactive client:

uv run python elicitation-client.py

Tip: Use uv run to automatically use the project's virtual environment without manual activation!

Demo Scenarios

The client demonstrates three scenarios:

1. Full Elicitation: No initial parameters - server requests all data
2. Partial Data: Only date provided - server requests party size
3. Invalid Data: Past date provided - server validates and requests correction

How It Works

Server Implementation (elicitation-server.py)

• FastMCP Server: Uses the FastMCP framework for easy setup
• Pydantic Schemas: Defines validation schemas for different input types
• Elicitation Handler: Generic function for requesting data with validation
• Book Table Tool: Main tool that orchestrates the booking process

Client Implementation (elicitation-client.py)

• Smart Callback: Interprets server requests and prompts user appropriately
• Input Validation: Client-side validation with retry logic
• Multiple Scenarios: Tests different combinations of initial data
• Error Handling: Graceful handling of user cancellations

Key Components

Elicitation Schemas

class GetDate(BaseModel):
    date: str = Field(
        description="Enter the date for your booking (YYYY-MM-DD)",
        pattern=r"^\d{4}-\d{2}-\d{2}$"
    )

Server Tool

@mcp.tool()
async def book_table(ctx: Context, date: str = "", party_size: int = 0) -> str:
    """Book a table with intelligent elicitation for missing or invalid data."""

Client Callback

async def smart_elicitation_callback(
    context: RequestContext["ClientSession", Any],
    params: types.ElicitRequestParams,
) -> types.ElicitResult | types.ErrorData:

Technical Details

Dependencies

• mcp[cli]: Model Context Protocol SDK
• pydantic: Data validation and settings management
• anyio: Async I/O library
• asyncio: Python's built-in async framework

Validation Rules

• Date Format: Must be YYYY-MM-DD and not in the past
• Party Size: Must be between 1 and 20 people
• Confirmation: Boolean with optional notes field

Error Handling

• Client disconnection during elicitation
• Invalid input formats
• User cancellations at any step
• Network timeouts and connection errors

Example Interaction

🍽️  Starting table booking process...

--- Testing: No arguments (full elicitation) ---

--- Server Request ---
Message: Please enter the date for your booking:
Enter the date for your booking (YYYY-MM-DD): 2025-07-15

--- Server Request ---
Message: Please enter the party size for your booking:
Enter the number of people (1-20): 4

--- Server Request ---
Message: Please confirm your booking for 4 people on 2025-07-15.
Do you want to confirm this booking? (y/n): y
Any special requests or notes? (optional): Window table please

✅ Result: ✅ Your table for 4 people on 2025-07-15 has been booked. Notes: Window table please

Development

Code Style

The project follows PEP 8 standards with:

• Maximum line length: 79 characters
• Type hints for all functions
• Docstrings for classes and functions
• Consistent naming conventions

Testing

Run the client to test different scenarios:

python elicitation-client.py

The client will automatically test three scenarios and prompt for continuation between each.

Extending the Demo

To add new elicitation types:

1. Define a schema in ElicitationSchema class
2. Add handling logic in the server tool
3. Update client callback to handle new request types
4. Test the new functionality with the client

Troubleshooting

Common Issues

1. Connection Refused: Ensure the server is running before starting the client
2. Port Already in Use: Check if another process is using port 8000
3. Import Errors: Ensure all dependencies are installed with uv sync

Debug Mode

Enable debug logging by modifying the logging level in elicitation-server.py:

logging.getLogger("mcp").setLevel(logging.DEBUG)

Contributing

1. Fork the repository
2. Create a feature branch
3. Make your changes with proper tests
4. Ensure code follows the style guidelines
5. Submit a pull request

License

This project is provided as a demonstration of MCP capabilities. Please refer to the MCP SDK license for usage terms.

Additional Resources

• Model Context Protocol Documentation
• FastMCP Documentation
• Pydantic Documentation

---

This demo showcases the power of MCP's elicitation feature for building interactive, intelligent tools that can gather information dynamically from users.
