AutoCAD MCP 服务器 / AutoCAD MCP Server

⚠️ 本项目目前维护精力有限，欢迎有兴趣的开发者参与协作！
⚠️ Currently this project is not actively maintained due to time constraints. I would be very happy to collaborate with anyone interested in co-maintaining or extending it.

基于 Model Context Protocol (MCP) 的 AutoCAD 集成服务器，允许通过 Claude 等大型语言模型 (LLM) 与 AutoCAD 进行自然语言交互。
An AutoCAD integration server based on Model Context Protocol (MCP), enabling natural language interaction with AutoCAD via large language models like Claude.

🔗 项目在 MseeP.ai 展示 / Referenced on MseeP.ai:
https://mseep.ai/app/zh19980811-easy-mcp-autocad

🎬 演示视频 / Demo Video:

---

✨ 功能特点 / Features

• 🗣️ 自然语言控制 AutoCAD 图纸 / Natural language control of AutoCAD drawings
• ✏️ 基础绘图功能（线条、圆）/ Basic drawing tools (line, circle)
• 📚 图层管理 / Layer management
• 🧠 自动生成 PMC 控制图 / Auto-generate PMC control diagrams
• 🔍 图纸元素分析 / Drawing element analysis
• 🔦 文本高亮匹配 / Highlight specific text patterns
• 💾 内嵌 SQLite 数据库存储 CAD 元素 / Integrated SQLite storage for CAD elements

---

🖥️ 系统要求 / System Requirements

• Python 3.10+
• AutoCAD 2018+ (需支持 COM 接口 / with COM interface support)
• Windows 操作系统 / Windows OS

---

⚙️ 安装步骤 / Installation

1. 克隆仓库 / Clone the repository

git clone https://github.com/yourusername/autocad-mcp-server.git
cd autocad-mcp-server

| `export_to_database` | 将 CAD 元素信息存入 SQLite |

## 2. 创建虚拟环境 / Create virtual environment

**Windows:**

```bash
python -m venv .venv
.venv\Scripts\activate

macOS / Linux:

python -m venv .venv
source .venv/bin/activate

---

3. 安装依赖 / Install dependencies

pip install -r requirements.txt

---

4. （可选）构建可执行文件 / (Optional) Build as executable

pyinstaller --onefile server.py

---

🚀 使用方法 / How to Use

独立运行服务器 / Run server independently

python server.py

---

集成 Claude Desktop / Integrate with Claude Desktop

编辑配置文件：

Windows 路径 / Config path on Windows:

%APPDATA%\Claude\claude_desktop_config.json

示例配置 / Example config:

{
  "mcpServers": {
    "autocad-mcp-server": {
      "command": "path/to/autocad_mcp_server.exe",
      "args": []
    }
  }
}

---

🧰 工具 API / Available API Tools

功能 / Function	描述 / Description
create_new_drawing	创建新的图纸 / Create a new drawing
draw_line	画直线 / Draw a line
draw_circle	画圆 / Draw a circle
set_layer	设置当前图层 / Set current drawing layer
highlight_text	高亮显示匹配文本 / Highlight matching text
scan_elements	扫描并解析图纸元素 / Scan and parse drawing elements
export_to_database	导出 CAD 元素到数据库 / Export CAD data to SQLite

---

🙋‍♂️ 维护状态 / Maintenance Notice

⚠️ 当前我正忙于其他项目，维护精力有限。欢迎 Fork 项目或提交 PR，一起完善 AutoCAD 智能交互生态！
⚠️ I'm currently busy and not able to actively maintain this repo. PRs and collaborators are welcome!

📬 联系我 / Contact: [e-mail]

---

Made with ❤️ for open-source learning.
