image-bridge-toolkit

image-bridge-toolkit provides cache-backed perceptual image fingerprinting and cross-dataset bridge matching designed to handle large scale (50,000+ image) libraries. It finds identical or highly similar images across disparate folders while remaining resilient to scale shifts, aspect ratio changes, heavy compression, and intrusive watermarks.

---

Key Features

• Per-Directory JSON Caching: Generates and maintains lightweight image_cache.json files within each directory, keyed by filename and modification time (mtime).
• Scale-Invariant Waveform Approximations: Uses 16-float 1D Discrete Cosine Transform (DCT) grayscale histogram vectors to ignore local watermark text spikes and compression artifacts.
• 5-Tier Matching Funnel:
  1. Tier 1 (Bitwise pHash Luma + Color): Generous 64-bit Hamming filtering to eliminate obvious non-matches.
  2. Tier 2 (Histogram Waveform): Euclidean distance on 16 low-frequency DCT coefficients to filter lighting distribution changes.
  3. Tier 3 (LAB Perceptual Metrics): Vector distance across lab_value, lab_hue, lab_chroma, and lab_warmth.
  4. Tier 4 (Spatial Layout Tie-Breaker): 16-point color spatial coordinates down-weighting image outer margins where signatures and borders reside.
  5. Tier 5 (Optional SSIM Direct Comparison): Full structural similarity pixel comparison on top candidate matches.
• Resumable & High Performance: Output streams as .jsonl objects, allowing runs over huge original sets to resume instantly without re-processing.
• Zero-Dependency Fallback: Runs with OpenCV if available for acceleration, or falls back to pure NumPy + Pillow.

---

Installation

Install via PyPI:

# Minimal installation (NumPy + Pillow)
pip install image-bridge-toolkit

# Recommended installation (includes OpenCV acceleration & progress bars)
pip install "image-bridge-toolkit[all]"

For development:

git clone [https://github.com/akingdom/image_bridge_toolkit.git](https://github.com/akingdom/image_bridge_toolkit.git)
cd image_bridge_toolkit
pip install -e ".[all]"

---

Usage

1. Build or Update Metadata Caches (imgcache-build)

Walks a root directory, scanning all subdirectories (skipping any directory containing .ignore_subdir), and generates or updates image_cache.json.

# Build cache for a query dataset (e.g., 1,000 watermarked images)
imgcache-build /path/to/thumbnails_set

# Build cache for a target dataset (e.g., 50,000 original images)
imgcache-build /path/to/originals_set

2. Match Datasets (imgmatch-bridge)

Matches images from the query dataset against the target library, generating a bridge mapping file with confidence scores and top candidate lists.

imgmatch-bridge /path/to/thumbnails_set /path/to/originals_set \
    -o bridge_map.jsonl \
    --max-hamming 16 \
    --candidate-threshold 0.03 \
    --direct-compare

Command-Line Options

Flag	Default	Description
-o, --output	bridge_map.jsonl	File path for output streaming results.
--max-hamming	16	Maximum allowed Tier 1 pHash Hamming distance threshold.
--candidate-threshold	0.03	Percentage band (e.g., 3%) to include close secondary matches.
--direct-compare	False	Performs Tier 5 pixel-level SSIM re-ranking on candidates.

---

visual_sig Schema (v2.0+)

Each visual_sig entry is an array of signature points. Starting with this release, each point contains:

Field	Type	Range	Description
x, y	float	0–100	Normalised position (percentage)
size	float	0–100	Spatial weight (percentage)
hex	str	#rrggbb	Dominant colour
lab	[float, float, float]	L:0–100, a/b:‑128–127	CIELAB colour
grad_theta	float	0–2π	Gradient direction (radians)
grad_mag	float	≥0	Gradient magnitude
elongation	float	0–1	0=round, 1=line
axis_phi	float	0–π	Principal orientation (radians)
primitive	int	0 or 1	0=plane, 1=edge
density	float	0–1	Local point concentration
curvature	float	≥0	Isophote curvature (clamped)

All fields are computed from the image. Consumers that only read x, y, hex, size will continue to work unchanged; the extra fields are ignored.

Example access:

cache = json.load(open("image_cache.json"))
points = cache["image.jpg"]["visual_sig"]
for p in points:
    print(f"{p['hex']} at ({p['x']:.1f}, {p['y']:.1f}) curvature={p['curvature']:.2f}")

visual_sig — Neighbour‑Based Topology (v2.0+)

Each visual_sig node now carries a flattened set of topology fields computed from the spatial neighbourhood of the point within a dense scaffold (16×16 grid). This enables categorical recognition of shapes (e.g., apple, person, car) and handles non‑rigid curves.

Field	Description
x, y	Position (0‑100)
size	Saliency (Voronoi assignment over scaffold)
hex, lab	Dominant colour (hex + CIELAB)
grad_theta, grad_mag	Gradient direction (radians) and magnitude
elongation, axis_phi	Shape anisotropy (0=round, 1=line) and principal axis
primitive	0=plane, 1=edge (quadrant variance)
density	Local point concentration (fraction of scaffold within radius)
curvature	Local bend κ (clamped to 2.5)

Selection algorithm:

• Greedy phase: picks colour‑diverse, spatially spread points.
• Structural phase: scores remaining points by elongation, curvature, gradient; applies NMS for spacing.
• Budget: dynamic between 10 and 20 points.

Experimental matcher: compute_topological_similarity uses these fields for more discriminating matching.

How Topology Fields Are Computed

For each visual_sig point, topology fields are sampled from the image at that location:

1. Gradient (grad_theta, grad_mag): First derivatives (Ix, Iy) from the grayscale image.
2. Shape (elongation, axis_phi): Hessian eigenvalues and eigenvectors (Ixx, Iyy, Ixy).
   • elongation = 1 - |λ_min / λ_max| (0 = round, 1 = line)
   • axis_phi = angle of the dominant eigenvector.
3. Primitive (primitive): 1 if edge‑like (elongation > 0.5 and grad_mag > 5.0), else 0.
4. Curvature (curvature): Isophote curvature formula:

   κ = |Ixx·Iy² - 2·Ixy·Ix·Iy + Iyy·Ix²| / (Ix² + Iy²)^(3/2)


5. Density (density): Fraction of other points within 0.1 normalized distance.
6. Colour (lab): Converted from hex using sRGB → XYZ → CIELAB.

All derivatives are computed on a 64×64 resized grayscale image and sampled at each point's location.

---

Cache Integrity & Updating

• mtime Matching: A cached entry is preserved as long as the file's modification time matches the record in image_cache.json.
• Partial Recomputation: If an existing cache entry is missing a newly added metric type (e.g., hist_waveform), only the missing calculation is executed; existing valid metrics are preserved.
• Corrupt Cache Handling: Invalid or unparseable JSON files are automatically caught and rebuilt without interrupting directory traversal.
• Subdirectory Exclusion: Placing a .ignore_subdir marker inside any directory causes the builder and matcher to ignore that folder and all nested subdirectories.

---

Programming Usage

Includes

from pathlib import Path
from image_bridge_toolkit.cache_builder import ImageCacheBuilder
from image_bridge_toolkit.matcher import run_match

--- Tool A: build/refresh caches ---

builder = ImageCacheBuilder("/data/deviantart", workers=8)
stats = builder.run()          # returns dict: dirs, files_seen, files_updated, files_reused
print(stats)

builder = ImageCacheBuilder("/data/originals", workers=16)
builder.run()

--- Tool B: match ---

run_match(
    da_root="/data/deviantart",
    orig_root="/data/originals",
    output_path="bridge_map.jsonl",
    max_hamming=16,
    candidate_threshold=0.03,
    do_direct_compare=True,
    workers=8,
    resume=True,
)

read results back in

import json
with open("bridge_map.jsonl") as f:
    for line in f:
        result = json.loads(line)
        print(result["query_path"], "->", len(result["top_matches"]), "candidates")

---
