ion-nn 0.10.1

A simple neural network library for JAX.

Ion

A simple neural network library for JAX

---

Ion is a simple neural network library for JAX. The core is three concepts (Module, Param, Optimizer) in <1000 lines of code. Models are pytrees that always work directly with jax.grad, jax.jit, and jax.vmap. Ion also ships with standard neural network layers (linear, convolution, attention, normalization, recurrent, and more) built on the core.

pip install ion-nn

Core Concepts

Param

Param wraps an array and marks it as a model parameter, either trainable or frozen.

w = nn.Param(jax.random.normal(shape=(3, 16), key=key))      # trainable
b = nn.Param(jax.numpy.zeros(shape=(16,)), trainable=False)  # frozen

Params work directly in arithmetic (x @ w works without unwrapping). Frozen params produce zero gradients under jax.grad.

Module

Inherit from nn.Module to define a layer. Subclasses are registered as JAX pytrees and become immutable after __init__.

import ion.nn as nn

class Linear(nn.Module):
    w: nn.Param
    b: nn.Param

    def __init__(self, in_dim, out_dim, *, key):
        self.w = nn.Param(jax.random.normal(shape=(in_dim, out_dim), key=key))
        self.b = nn.Param(jax.numpy.zeros(shape=(out_dim,)))

    def __call__(self, x):
        return x @ self.w + self.b

Non-array fields (ints, strings, callables) are treated as static config. Store num_heads, use_bias, or activation functions directly on the module.

Optimizer

Wraps an optax optimizer with Param-aware updates. Frozen params are automatically partitioned out, so no manual filtering is needed.

optimizer = ion.Optimizer(optax.adam(3e-4), model)
model, optimizer = optimizer.update(model, grads)

That's the entire core. See Internals for design details and sharp edges.

Example

Putting it all together with a model built from Ion's standard layers:

import jax, optax, typing

import ion
import ion.nn as nn


class MLP(nn.Module):
    layer_1: nn.Linear
    layer_2: nn.Linear
    activation: typing.Callable

    def __init__(self, activation=jax.nn.relu, *, key):
        keys = jax.random.split(key, 2)
        self.layer_1 = nn.Linear(784, 128, key=keys[0])
        self.layer_2 = nn.Linear(128, 10, key=keys[1])
        self.activation = activation

    def __call__(self, x):
        return self.layer_2(self.activation(self.layer_1(x)))


def loss_fn(model, x, y):
    logits = model(x)
    return optax.softmax_cross_entropy_with_integer_labels(logits, y).mean()


@jax.jit
def train_step(model, optimizer, x, y):
    grads = jax.grad(loss_fn)(model, x, y)
    model, optimizer = optimizer.update(model, grads)
    return model, optimizer


model = MLP(key=jax.random.key(0))

optimizer = ion.Optimizer(optax.adam(3e-4), model)

for x, y in data:
    model, optimizer = train_step(model, optimizer, x, y)

Utilities

nn.Module provides convenience methods and properties for common operations. Methods return new instances, as modules are immutable.

model.at.activation.set(jax.nn.tanh)    # create a modified copy
model.freeze()                          # freeze all params
model.unfreeze()                        # unfreeze all params
model.at.base.set(model.base.freeze())  # freeze a sub-module
model.at.blocks[2].attn.w_q.set(new_w)  # set a leaf deep in the tree
model.at[nn.Dropout].p.set(0.5)         # set a field on every matching layer
model.astype(jax.numpy.bfloat16)        # cast params to a different dtype
model.params                            # pytree of Param leaves
model.num_params                        # total parameter count

Layers

Ion ships with standard neural network layers. Each is a Module with trainable Param leaves.

Category	Layers
Linear	Linear, Identity, LoRALinear
Convolution	Conv, ConvTranspose
Attention	SelfAttention, CrossAttention
Normalization	LayerNorm, RMSNorm, GroupNorm
Recurrent	RNNCell, LSTMCell, GRUCell, RNN, LSTM, GRU
SSM	LRUCell, S4DCell, S5Cell, LRU, S4D, S5
Pooling	MaxPool, AvgPool
Embedding	Embedding, LearnedPositionalEmbedding
Positional	RoPE, sinusoidal, alibi
Regularization	Dropout
Blocks	Sequential, MLP
GNN	GCNConv, GATConv, GATv2Conv, GINConv

See Layer Conventions for data format, weight init, spatial layer usage, and SSM conventions. See GNN Conventions for graph layer usage.

Pretty Printing

In notebooks, Treescope provides interactive, color-coded visualization of Ion Modules and Params. Treescope is enabled by default on import, and can be configured:

ion.enable_treescope()                 # Ion Modules and Params only (default)
ion.enable_treescope(everything=True)  # all types
ion.disable_treescope()                # turn off

Modules also have built-in text formatting for terminal output.

>>> model = MLP(key=jax.random.key(0))
>>> model

MLP(
  layer_1=Linear(
    w=Param(f32[784, 128], trainable=True),
    b=Param(f32[128], trainable=True),
  ),
  layer_2=Linear(
    w=Param(f32[128, 10], trainable=True),
    b=Param(f32[10], trainable=True),
  ),
  activation=relu,
)

Serialization

Save and load any pytree as .ion files. Works with models, optimizers, or any other pytree. load requires a reference pytree as a template to reconstruct the tree structure.

ion.save("model.ion", model)
model = ion.load("model.ion", model)

ion.save("snapshot.ion", (model, optimizer))
model, optimizer = ion.load("snapshot.ion", (model, optimizer))

The .ion format is safetensors-style, with JAX dtypes like bfloat16, float8 and complex64 stored natively. Safetensors tools can read Ion checkpoints directly.

Examples

• Ion Tour: Hands-on walkthrough of the core API
• CNN Demo: Image classification with convolutional networks
• RNN Demo: Sequence classification with recurrent networks
• GPT Demo Notebook: Character-level GPT on TinyStories
• VAE Demo Notebook: Variational autoencoder for image generation
• GNN Node Classification: Node classification on Cora with graph neural networks
• GNN Molecular Property Prediction: Blood-brain barrier prediction with graph attention networks
• SSM Pathfinder: Exploring state space models on the Pathfinder task
• PPO Demo: Reinforcement learning with Gymnax
• PQN Demo: Parallelized Q-Networks with Gymnax
• DQN Atari: Deep Q-networks on Atari with replay buffers and target networks

FAQ

Why do I need a neural network library in JAX?

Building simple neural network models from scratch in JAX is straightforward. As they get more complex however, two things become painful: managing parameters (initializing them, tracking which are trainable, freezing some for fine-tuning) and composing modules (reusing layers, wiring them through JAX transforms, not reimplementing things like convolution padding from scratch for every project). A neural network library takes care of this so you can focus on model building and training.

Who is Ion for?

Ion is for JAX users who want a neural network library that is small, easy to learn, and easy to understand.

The core introduces three concepts, Module, Param, and Optimizer, and from there JAX does everything else. There are no custom transforms, no special contexts, no framework-specific calling conventions. If you already know JAX, you can learn Ion in an hour.

Because the core is <1000 lines with not much happening behind the scenes, it's straightforward to reason about what JAX is doing. This matters most in complex training setups like multi-stage fine-tuning or custom gradient flows.

How does Ion compare to Equinox and Flax?

Equinox is an excellent pytree-based library for scientific computing where neural networks are one of several possible use-cases. It provides filtered transforms, partition/combine utilities, and general pytree tools. Equinox treats all JAX arrays equally, so users must apply lax.stop_gradient or manually filter trainable parameters when computing gradients and applying optimizer updates. In Ion, Param tracks trainability so jax.grad returns zero gradients for frozen params automatically, and Optimizer handles the partition internally. Relative to Equinox, Ion trades off flexibility for simplicity and ease of use.

Flax NNX takes a different approach. NNX models are mutable graph objects with reference semantics, and custom transforms (nnx.jit, nnx.grad) bridge mutability with JAX's functional model. Ion leans into JAX's philosophy of functional programming and immutability, building on native JAX transforms rather than replacing them. The trade-off is transparent, simple machinery over powerful but opaque machinery.

Both Equinox and Flax are well battle-tested and have existing model hubs. If you need a broader pytree toolkit for scientific computing, Equinox is excellent. If you want PyTorch-like mutability, Flax NNX is a great choice.

License

Released under the Apache License 2.0.

Citation

To cite this repository:

@software{ion,
  title = {Ion: Simple Neural Networks in JAX},
  author = {Alex Goddard},
  url = {https://github.com/auxeno/ion},
  year = {2026}
}
