jaxon-nerve 1.0.1

A differentiable, GPU-native simulator for peripheral-nerve fiber models.

---

jaxon is a fully differentiable, GPU-native reimplementation of the canonical peripheral-nerve fiber models in JAX / Jaxley. It reproduces NEURON's extracellular mechanism to sub-0.5 % threshold error and machine-precision conduction velocity, runs whole fiber populations in parallel on one GPU, and exposes gradients through the cable equation — so extracellular stimulation parameters (per-contact amplitudes, waveform shape, electrode position) can be optimized directly rather than grid-searched. It slots into existing pipelines as a gradient-enabled, vectorized replacement for the NEURON forward solver.

The cohort-scale selectivity experiments run on FEM-derived per-contact lead fields and histology-segmented vagus-nerve geometries produced by the golgi platform [1, 2] (29 nerves: 18 pig, 11 human), applied to a 12-contact ring cuff.

✨ Highlights

• Differentiable through the cable equation. Reverse-mode autodiff and packed finite-difference gradients drive Adam optimization of per-contact amplitudes, arbitrary K×T waveforms, and joint amplitude + electrode-position search — no surrogate model, gradients of the true biophysics.
• GPU-native population scale. vmap-batched forward passes simulate 100,000 fibers on a single GPU, reaching a geometric-mean ~820× speedup over single-thread NEURON at that scale (~200–300× at the ~1000-fiber operating point used in the paper).
• Validated against NEURON / PyFibers. 99.6 % of 943 threshold configurations agree within 1 %; conduction velocity matches to machine precision. jaxon is checked against the reference solver, not a fit to it.
• Principled coupled solver. A custom backward-Euler integrator for the two-state (V_i, V_pax) double-cable equation — the equivalent of NEURON's extracellular mechanism, not the single-cable activating-function shortcut — solved by a 2×2 block-Thomas sweep verified to 5.6×10⁻¹¹ mV against dense LU.
• Five model/parameterization variants. Myelinated MRG (McIntyre–Richardson–Grill, original + interpolated tables) and Sweeney; unmyelinated Sundt and Rattay C-fibers, each hand-translated from NMODL and rate-checked to machine precision.
• Realistic cohort fields. Drives golgi-derived FEM lead fields over histology-segmented swine and human vagus nerves, so selectivity is scored on anatomically realistic populations, not synthetic cross-sections.

Models

Model	Type	Compartments	Validation status
MRG	Myelinated A-fiber (2002)	21 nodes (double-cable)	✓ <0.5 % thresholds, 1e-12 CV
MRG_Interp	MRG, polynomial geometry	same	scaling-only
Sweeney	Myelinated A-fiber (1987)	21 nodes	✓ <0.1 % thresholds, 1e-12 CV
Sundt	Unmyelinated C-fiber (2015)	51 uniform	✓ <0.5 % thresholds, CV fixed
Rattay	Unmyelinated HH C-fiber	51 uniform	✓ <0.5 % thresholds, CV fixed
Schild94	Unmyelinated C-fiber (full Ca dynamics)	51 uniform	code complete; validation pending
Schild97	Unmyelinated C-fiber (mean)	51 uniform	code complete; validation pending

Installation

jaxon installs with conda (for the pinned scientific + NEURON stack) and runs on CPU by default; a single edit switches it to CUDA.

# 1. enter the project directory
cd jaxon

# 2. create the env (CPU by default; uncomment jax[cuda12] in environment.yml for GPU)
conda env create -f environment.yml

# 3. activate and compile the NEURON .mod files used by the PyFibers reference
conda activate jaxon
pyfibers_compile

For CUDA hosts, edit environment.yml per its header comments before step 2, then verify:

python -c "import jax; print(jax.devices())"   # should list CudaDevice

Quick start

Run the validation suite (CPU, minutes):

conda activate jaxon

python experiments_v2/mrg_validation.py        # thresholds, CV, traces (MRG)
python experiments_v2/sundt_validation.py      # ditto, Sundt
python experiments_v2/rattay_validation.py     # ditto, Rattay
python experiments_v2/sweeney_validation.py    # ditto, Sweeney
python experiments_v2/scaling.py               # scaling benchmark, all models

Optimize stimulation for selectivity:

python experiments_v2/selectivity_demo.py      # local single-nerve selectivity demo
python experiments_v2/selectivity_sweep.py     # full population sweep
python experiments_v2/selectivity_joint_opt.py # joint amplitudes + electrode positions

Outputs land in outputs/<experiment>/. Heavier sweeps are wired for SLURM under slurm/ — see slurm/submit_all.sh. To reproduce every figure and number in the paper from processed data, see REPRODUCE.md.

Reproducing the paper

The processed data (golgi lead fields + all sweep / validation / phenomena outputs) is archived on Zenodo; REPRODUCE.md documents two paths — regenerating every figure from that processed data (fast, CPU-only), or re-running the full simulation pipeline from scratch (slow, GPU).

The Zenodo archive's top-level directories (outputs/, duke_Ves/) match the repository layout, so it unpacks directly at the repo root — no mapping or symlinks needed. From the repository root:

# unpack the Zenodo data archive -> populates outputs/ and duke_Ves/
tar -xzf jaxon_data_archive_v1.tar.gz

# regenerate all main + named-supplementary figures from processed data
bash reproduce_figures.sh

outputs/ supplies the processed sweep / validation / phenomena data; duke_Ves/ supplies the raw per-nerve lead-field bundles the gradient-check figure and the from-scratch cohort sweep read. See REPRODUCE.md for the from-scratch (GPU) path.

The raw golgi FEM meshes are not bundled — they are golgi outputs, available via the golgi platform and the underlying SPARC datasets (swine doi:10.26275/MAQ2-EII4, human doi:10.26275/OFJA-GHOZ).

Core design

• Channels. Each NMODL mechanism is hand-translated into a pure-JAX Channel class with solve_gate_exponential updates; rate constants are checked against the published .mod formulas to machine precision.
• Fibers. Each builder returns a jaxley.Cell plus a geometry dataclass fully describing the per-compartment static parameters.
• Coupled solver (stim/extracellular_coupled.py). Backward-Euler integrator for the two-state (V_i, V_pax) double-cable equation, solved by a 2×2 block-Thomas sweep (verified to 5.6e-11 mV vs dense LU); back-substitution via jax.lax.associative_scan for O(log n) depth.
• Batching. stack_fiber_statics packs N fibers into vmapped arrays; batch_integrate_m_max runs them in parallel on the GPU for the optimization loops.
• Optimization (optim/optimizer.py), three modes: rectangular per-contact amplitudes via a packed finite-difference gradient (K+1 configs per forward pass); arbitrary K×T waveforms via autodiff through the ODE scan (with gradient checkpointing); joint amplitudes + electrode positions via FD over both, with the field recomputed differentiably each step.

Repository layout

jaxon/
├── README.md               this file
├── REPRODUCE.md            step-by-step paper reproduction
├── reproduce_figures.sh    one-command figure driver (processed data)
├── environment.yml         pinned conda env
├── jaxon/              core package
│   ├── channels/           Jaxley Channel translations (MRG, Sundt, Rattay,
│   │                       Sweeney, Schild94, Schild97)
│   ├── fibers/             morphology builders, one per model
│   ├── stim/
│   │   ├── intracellular.py        rectangular intracellular pulse helper
│   │   ├── extracellular.py        point-source Ve profile (demo option)
│   │   ├── extracellular_coupled.py  coupled (V_i, V_pax) backward-Euler solver
│   │   ├── batch_solve.py          vmapped multi-fiber forward pass
│   │   └── multichannel_field.py   multi-contact ring-cuff field
│   ├── optim/
│   │   ├── losses.py       activation proxy, WQ loss, WBCE, selectivity index
│   │   └── optimizer.py    rect / waveform / joint Adam loops
│   ├── nerve/geometry.py   synthetic nerve cross-section (demos/tests)
│   └── nrn_baseline.py     thin PyFibers / NEURON wrappers
├── experiments_v2/         paper-relevant runs (see EXPERIMENTS.md, FIGURE_DATA_MAP.md)
│   ├── <model>_validation.py       thresholds + CV + traces, one per fiber model
│   ├── scaling.py                  PyFibers vs Jaxley CPU vs Jaxley GPU
│   ├── selectivity_sweep_duke.py   cohort selectivity sweep on golgi fields
│   ├── figures_*_main.py           paper figure generators
│   └── analyze_*.py                statistics + tables
├── duke_Ves/               per-nerve golgi FEM lead fields + geometry (gitignored)
├── outputs/                validation JSONs + figures + sweep data (gitignored)
├── slurm/                  SLURM sbatch drivers for the cluster
└── reference_code/pyfibers/  upstream PyFibers, cloned for reference

Headline numbers

• MRG threshold error vs NEURON: median +0.04 %, max 0.39 % across 432 cases (9 diameters × 8 pulse shapes × 6 pulse widths). Sweeney: max 0.09 % across 240 cases. Overall, 99.6 % of 943 configurations within 1 %.
• MRG / Sweeney conduction velocity: machine precision (1e-12 %) across all diameters.
• Scaling vs single-thread NEURON: ~200–300× at N = 1000 fibers, geometric-mean ~820× at N = 100,000 on one A100. The value here is accuracy and differentiability, not raw forward speed against fitted surrogates.

Caveats

1. Extracellular field. The cohort selectivity experiments use FEM-derived per-contact lead fields (the pre-baked Ve_VperA tensor) computed by golgi [1, 2] for a multi-contact ring cuff on histology-segmented vagus nerves — not a point source. The analytic point-source potential in a homogeneous medium (σ = 0.3 S/m, stim/extracellular.py) is retained as a lightweight option for local single-nerve demos.
2. Nerve geometry. The cohort experiments use histology-derived vagus-nerve morphology segmented and meshed by golgi [1, 2] from the Pelot 2020 pig / 2021 human SPARC datasets (29 nerves: 18 pig, 11 human). The synthetic circular cross-section (nerve/geometry.py) is retained for local demos and unit tests.
3. Schild94 / Schild97 are not yet validated. Channel and fiber code exist and are wired into the scaling benchmark, but the dedicated validation runs have not been executed.
4. Sundt at D = 1.2 µm gives a non-physiological CV (~19 m/s) in the current validation script because the bisection lands on a suprathreshold pulse that fires multi-site. Reported identically by JAX and PyFibers — a measurement artifact, not a model error.

Reproducibility

Versions pinned in environment.yml / requirements.txt:

python       3.11        jaxley       0.13.0      optax        0.2.8
jax          0.6.2       neuron       9.0.1       numpy        2.2.6
                         pyfibers     0.8.5       matplotlib   3.10.9

Cluster validation hardware: MedUni Vienna HPC, NVIDIA A16 (16 GB VRAM), SLURM. NEURON .mod artifacts are platform-specific and gitignored — re-run pyfibers_compile after creating the conda env on a new host.

License

jaxon is released under the MIT License — see LICENSE. The golgi FEM datasets and the manuscript reproduction archive are released separately on Zenodo under CC-BY-4.0.

Citation

If you use jaxon, please cite the accompanying manuscript (Lung & Haberbusch, Medical University of Vienna; citation to be updated on publication) and the golgi platform that supplies the cohort fields:

1. Lung D, Jia Y, Moro A, Fachino M, Haberbusch M. golgi: open-source software for automated nerve model generation and recruitment simulation. bioRxiv 2026.07.10.737846. https://doi.org/10.64898/2026.07.10.737846
2. Lung D, Jia Y, Blumer R, Reissig L, Zopf LM, Heimel P, Kraus C, Moro A, Fachino M, Haberbusch M. golgi: an open-source graphical platform for image-to-recruitment modeling of peripheral nerve stimulation. bioRxiv 2026.07.10.737529. https://doi.org/10.64898/2026.07.10.737529

Built with

Role	Built on
Differentiable cable simulation	JAX · Jaxley
Optimization	Optax
Reference solver	NEURON via PyFibers
Cohort FEM fields & anatomy	golgi
