json2capella 0.3.1

Importing JSON into Capella Data package

JSON2Capella

Command-line tool for importing package definitions from JSON files into a Capella model's data package.

Documentation

Read the full documentation on Github pages.

Examples

Apply package definition from .json file to Capella model layer's root data package:

python -m json2capella \
-i tests/data/example_jsons/package1.json \
-m tests/data/empty_project_60 \
-l la \

Import package definitions from folder with .json files to Capella model layer's root data package:

python -m json2capella \
-i tests/data/example_jsons \
-m tests/data/empty_project_60 \
-l la

Installation

You can install the latest released version directly from PyPI.

pip install json2capella

To set up a development environment, clone the project and install it into a virtual environment.

git clone https://github.com/DSD-DBS/json2capella
cd json2capella
python -m venv .venv

source .venv/bin/activate.sh  # for Linux / Mac
.venv\Scripts\activate  # for Windows

pip install -U pip pre-commit
pip install -e '.[docs,test]'
pre-commit install

Contributing

We'd love to see your bug reports and improvement suggestions! Please take a look at our guidelines for contributors for details.

Licenses

This project is compliant with the REUSE Specification Version 3.0.

Copyright DB InfraGO AG, licensed under Apache 2.0 (see full text in LICENSES/Apache-2.0.txt)

Dot-files are licensed under CC0-1.0 (see full text in LICENSES/CC0-1.0.txt)
