kalbee

kalbee is a clean, modular Python toolkit for filtering and tracking. It gathers a dozen Kalman-filter variants (linear, nonlinear, robust, adaptive), RTS-family smoothers, and multi-object trackers (SORT-style, JPDA, PMBM) behind one consistent predict/update interface — so you can go from denoising a sensor stream to tracking vehicles or pedestrians in video without switching libraries.

Why kalbee?

All numbers are reproducible — see docs/benchmarks.md and scripts/compare_benchmarks.py for the honest version, including where FilterPy still wins (raw single-filter-loop overhead).

Features

• 18 Filters: KF, EKF, UKF, SigmaPointUKF, Particle Filter, Ensemble KF, Information Filter, Alpha-Beta-Gamma, Adaptive KF, Square-Root KF, Vectorized KF, Fading Memory KF, H-Infinity, Interacting Multiple Model (IMM), Invariant EKF (InEKF on SO(3)/SE(3)), Variational Bayes Adaptive KF (VBAKF), Cubature KF (CKF), and Rao-Blackwellized Particle Filter (RBPF)
• Advanced Tracking: SORT-style MultiObjectTracker, Joint Probabilistic Data Association (JPDAAssociation), and Poisson Multi-Bernoulli Mixture (PMBMTracker) for multi-target tracking in heavy clutter
• Real-Video Examples: bounding-box tracking of vehicles/people via YOLO (examples/yolo_*.py), plus a pedestrian-tracking demo on the real MOT16 dataset (examples/mot16_pedestrian_tracking.py, scripts/mot16_demo.py)
• Animated Demos: .gif galleries built from the public API — see the Examples & Gallery
• Non-Linear Smoothers: RTS Smoother, Extended RTS Smoother, Unscented RTS Smoother, and Fixed-Lag Smoother
• Asynchronous Sensor Fusion: AsyncSensorBuffer for out-of-sequence measurements (OOSM) and multi-rate sensors
• Learning & Neural Filters: Offline EM, Online EM, NIS Auto-Tuning, and PyTorch KalmanNet hybrid neural filter
• Factor Graph Export: Export filter trajectories to Factor Graph format (FactorGraphExporter) for global non-linear optimization
• Sigma Points: Pluggable strategies — SimplexSigmaPoints, MerweScaledSigmaPoints, JulierSigmaPoints
• Motion Models: Ready-made constant-velocity, constant-acceleration, and coordinated-turn (F, Q) builders plus position measurement models
• Innovation Gating: Chi-squared and Mahalanobis gating for outlier rejection
• Outlier Detection: Real-time Chi2OutlierDetector with adaptive thresholds
• Diagnostics: FilterDiagnostics for real-time monitoring, NIS/NEES consistency tests, innovation whiteness test
• Metrics: RMSE, NEES, NIS, Log-Likelihood for filter diagnostics
• Batch Processing: filter_sequence() with missing data handling
• State Persistence: save_state() / load_state() for JSON serialization
• Control Inputs: B matrix support in KF predict step
• Experiment Runner: Compare filters on synthetic signals with one line
• AutoFilter Factory: Switch between filters by name
• Numerical Stability: Joseph form covariance updates, Cholesky factor stabilization, and symmetry enforcement
• NumPy/SciPy & PyTorch Integration: Optimized for numerical computations and differentiable learning
• Sensor-Fusion Cookbook: Ready-made quaternion attitude EKF (gyro+accel) and GPS+IMU loosely-coupled fusion recipes
• Numerical Jacobians: numerical_jacobian() builds EKF Jacobians from plain Python functions — no hand-derivation needed
• scikit-learn Integration: KalmanEstimator — drop any filter into an sklearn.Pipeline via fit/transform/predict
• CLI: kalbee demo --live (animated terminal chart), kalbee bench, kalbee new (scaffold a starter script)
• Typed: Ships py.typed for IDE autocomplete and static type checking

Installation

pip install kalbee

Or from source:

git clone https://github.com/LakoreAI/kalbee.git
cd kalbee
pip install -e .

Optional extras: pip install "kalbee[yolo]" (object-tracking examples), "kalbee[viz]" (plotting), "kalbee[docs]" (documentation site), "kalbee[cli]" (animated kalbee demo --live), or "kalbee[sklearn]" (KalmanEstimator).

Try it with zero code

pip install "kalbee[cli]"
kalbee demo --live --filter kf --signal sine   # animated terminal chart
kalbee bench                                    # speed/accuracy across all filters
kalbee new my_tracker.py                        # scaffold a starter script

See it before you read it

Animated, runnable demos — filtering, IMM on maneuvering targets, and multi-object tracking of real pedestrians (MOT16) — live in the Examples & Gallery, with vehicles/people bounding-box tracking examples in examples/yolo_mot.py, examples/yolo_vehicles.py, and examples/yolo_people.py.

Quick Start

1. Standard Kalman Filter

import numpy as np
from kalbee import KalmanFilter

state = np.zeros((2, 1))  # [position, velocity]
cov = np.eye(2)
F = np.array([[1, 1], [0, 1]])  # Constant velocity model
Q = np.eye(2) * 0.01
H = np.array([[1, 0]])
R = np.array([[0.1]])

kf = KalmanFilter(state, cov, F, Q, H, R)
kf.predict()
kf.update(np.array([[1.2]]))
print(f"Estimated State:\n{kf.x}")

2. Interacting Multiple Model (IMM) Filter

import numpy as np
from kalbee import KalmanFilter, InteractingMultipleModel

kf_cv = KalmanFilter(state_init, cov_init, F_cv, Q_cv, H, R)
kf_ca = KalmanFilter(state_init, cov_init, F_ca, Q_ca, H, R)

model_transition = np.array([[0.95, 0.05], [0.05, 0.95]])
model_probabilities = np.array([0.8, 0.2])

imm = InteractingMultipleModel([kf_cv, kf_ca], model_transition, model_probabilities)
imm.predict()
imm.update(measurement)

3. SigmaPointUKF with Pluggable Sigma Points

import numpy as np
from kalbee import SigmaPointUKF, MerweScaledSigmaPoints

state = np.zeros((2, 1))
cov = np.eye(2) * 10.0
Q = np.eye(2) * 0.01
R = np.array([[0.5]])

def f(x, dt):
    return np.array([[x[0, 0] + x[1, 0] * dt], [x[1, 0]]])

def h(x):
    return np.array([[x[0, 0]]])

sigma_pts = MerweScaledSigmaPoints(n=2, alpha=0.1, beta=2.0, kappa=0.0)
ukf = SigmaPointUKF(state, cov, Q, R, f, h, sigma_points=sigma_pts)

ukf.predict(dt=1.0)
ukf.update(np.array([[1.2]]))

4. Compare Filters with Experiments

from kalbee import run_experiment

report = run_experiment(
    signal="sine",
    filters=["kf", "ekf", "ukf", "pf"],
    noise_std=0.5,
)
print(report.summary())

5. AutoFilter Factory

from kalbee import AutoFilter

kf = AutoFilter.from_filter(state, cov, F, Q, H, R, mode="kf")
# Available modes: kf, ekf, ukf, abg, pf, enkf, if, akf, srkf, vkf, imms

6. Multi-Object Tracking

import numpy as np
from kalbee import KalmanFilter, MultiObjectTracker
from kalbee.models import constant_velocity, position_measurement_model

F, Q = constant_velocity(dt=1.0, process_var=0.1, n_dims=2)
H, R = position_measurement_model(order=1, n_dims=2, measurement_var=0.25)

def new_track(z):
    x0 = np.array([[z[0]], [0.0], [z[1]], [0.0]])
    return KalmanFilter(x0, np.eye(4) * 10.0, F, Q, H, R)

tracker = MultiObjectTracker(new_track, n_init=3, max_age=5)

for detections in detection_stream:
    confirmed = tracker.update(detections)
    for t in confirmed:
        print(t.id, t.state[0, 0], t.state[2, 0])

See examples/multi_object_tracking.py for a full runnable demo.

7. Learn Noise Covariances from Data (EM)

from kalbee import em_kalman
from kalbee.models import constant_velocity, position_measurement_model

F, _ = constant_velocity(dt=1.0, n_dims=1)
H, _ = position_measurement_model(order=1, n_dims=1)

result = em_kalman(measurements, F, H, n_iter=50)
print("Learned Q:\n", result.Q)
print("Learned R:\n", result.R)

8. Auto-Tuning

from kalbee import tune_kalman_filter, quick_tune

# Iterative NIS-based tuning
result = tune_kalman_filter(measurements, F, H, n_iter=50)
print(f"Q:\n{result.Q}\nR:\n{result.R}")

# Quick single-pass tuning
Q, R = quick_tune(measurements, F, H)

9. Real-Time Diagnostics

from kalbee import KalmanFilter, FilterDiagnostics

kf = KalmanFilter(state, cov, F, Q, H, R)
diag = FilterDiagnostics(m=1, n=2)

for z in measurements:
    kf.predict()
    kf.update(z)
    snapshot = diag.collect(kf, ground_truth=true_state)

print(diag.summary())

10. GPS + IMU Sensor Fusion

from kalbee import KalmanFilter
from kalbee.models import constant_velocity, imu_velocity_control, position_measurement_model

n_dims = 2
dt_imu = 0.02  # 50 Hz IMU
F, Q = constant_velocity(dt=dt_imu, process_var=0.02, n_dims=n_dims)
B = imu_velocity_control(dt=dt_imu, n_dims=n_dims)  # maps accel -> [pos, vel] control input
H, R = position_measurement_model(order=1, n_dims=n_dims, measurement_var=1.5**2)

kf = KalmanFilter(x0, P0, F, Q, H, R, control_matrix=B)

for tick, accel in enumerate(imu_stream):
    kf.predict(u=accel)          # every IMU tick
    if tick % 25 == 0:
        kf.update(next(gps_stream))  # every GPS fix

See examples/gps_imu_fusion.py and the Sensor-Fusion Cookbook.

11. Quaternion Attitude EKF (gyro + accelerometer)

from kalbee import ExtendedKalmanFilter
from kalbee.models import (
    quaternion_normalize, attitude_transition, attitude_transition_jacobian,
    gravity_measurement, gravity_measurement_jacobian,
)

ekf = ExtendedKalmanFilter(state=q0, covariance=P0, transition_covariance=Q, measurement_covariance=R)

ekf.predict(dt=dt, f=lambda x, dt: attitude_transition(x, dt, gyro),
            F=lambda x, dt: attitude_transition_jacobian(x, dt, gyro))
ekf.state = quaternion_normalize(ekf.state)

ekf.update(accel_reading, h=gravity_measurement, H=gravity_measurement_jacobian)
ekf.state = quaternion_normalize(ekf.state)

See examples/quaternion_attitude_ekf.py for the full runnable version and tuning notes.

12. scikit-learn Integration

from kalbee.modules.integration.sklearn_api import KalmanEstimator

smoothed = KalmanEstimator(dt=0.1, process_var=1.0, measurement_var=0.3).fit_transform(noisy_measurements)
# or inside a Pipeline / GridSearchCV — see docs/features/scikit_learn_integration.md

Documentation

Full documentation with theory, code examples, and experiments for each filter:

pip install mkdocs-material
mkdocs serve

• Getting Started
• Learn — intuition-first Kalman filtering tutorial
• Examples & Gallery — animated demos + how-to recipes
• Filters: KF · EKF · UKF · SigmaPointUKF · PF · EnKF · IF · ABG · AKF · Fading Memory KF · H-Infinity · SRKF · Vectorized KF · IMM
• Features: Sensor-Fusion Cookbook · scikit-learn Integration · Gating · Outlier Detection · Auto-Tuning · Diagnostics · Consistency Tests · RTS Smoother · Metrics · Experiments · Maneuvering Target Tracking · YOLO Object Tracking
• CLI · Benchmarks · Architecture

Project status

kalbee is stable (v1.0.0). See CHANGELOG.md for release history and RELEASING.md for the release process.

Testing

Tests mirror the package layout under tests/ (filters, smoothers, models, tracking, fusion, learning, integration, utils, experiments, cli):

uv run pytest tests/                                  # run the suite
uv run pytest tests/ --cov=kalbee --cov-report=term   # with coverage

Lint and format with ruff (as CI does):

uv run ruff check .
uv run ruff format --check .

License

This project is licensed under the Apache License 2.0.
