Kopi-Docka

Cold Backup Tool for Docker Environments using Kopia

Kopi-Docka is a Python-based backup wrapper for Docker containers and volumes. It uses Kopia for encryption and deduplication, with specific focus on Docker Compose stack awareness.

---

What is Kopi-Docka?

Kopi-Docka = Kopia + Docker + Backup

A wrapper around Kopia, designed for Docker environments:

• 📦 Stack-Aware - Recognizes Docker Compose stacks and backs them up as logical units
• 🔐 Encrypted - End-to-end encryption via Kopia (AES-256-GCM)
• 🌐 Multiple Storage Options - Local, S3, B2, Azure, GCS, SFTP, Tailscale, Rclone
• 💾 Disaster Recovery - Encrypted bundles with auto-reconnect scripts
• 🔧 Pre/Post Hooks - Custom scripts (maintenance mode, notifications, etc.)
• 📊 Systemd Integration - Daemon with sd_notify and watchdog support
• 🚀 Restore on New Hardware - Recovery without original system
• 🛡️ Graceful Shutdown - SafeExitManager ensures containers restart after Ctrl+C
• 🔔 Notifications - Telegram, Discord, Email alerts via Apprise

See detailed features →

---

What it looks like

Seven short scenes playing back-to-back — doctor → dry-run → backup → history → snapshot list → restore wizard → disaster recovery. About 110 seconds end-to-end; the animation loops, so you can pause on any segment by scrolling away and back.

Individual scenes (click to expand)

#	Scene	SVG
1	Doctor — system health check (dependencies, repo, backend sanity, DR readiness)	demo-doctor.svg
2	Dry-run — plan the backup, no changes	demo-dry-run.svg
3	Backup — real cold backup over SFTP, two stacks in ~7s	demo-backup.svg
4	History — past backup runs with status, scope, snapshot IDs	demo-history.svg
5	Snapshot list — Kopia snapshots grouped by backup_id / type / unit tags	demo-snapshot-list.svg
6	Restore wizard — interactive recovery with safety-backup before overwrite	demo-restore.svg
7	Disaster recovery bundle — encrypted ZIP + deprecation guidance	demo-dr-export.svg

---

Quick Start

Prerequisites

Kopi-Docka expects a prepared system. You need to install dependencies before installing Kopi-Docka:

Required:

• Docker (20.10+)
• Kopia (0.13+)

Quick check:

docker --version
kopia --version

Need automated setup? Use Server-Baukasten for automated system preparation.

Installation

# Recommended: pipx (isolated environment)
pipx install kopi-docka

# Make available for sudo (pipx installs to ~/.local/bin)
sudo ln -s ~/.local/bin/kopi-docka /usr/local/bin/kopi-docka

# Or: pip (system-wide)
pip install kopi-docka

# Verify all dependencies
kopi-docka doctor

Full installation guide →

Setup

# Interactive setup wizard
sudo kopi-docka setup

The wizard guides you through:

1. ✅ Dependency verification (Docker, Kopia)
2. ✅ Repository storage selection (Local, S3, B2, Azure, GCS, SFTP, Tailscale, Rclone)
3. ✅ Repository initialization
4. ✅ Connection test

Configuration guide →

First Backup

# System health check
sudo kopi-docka doctor

# List backup units (containers/stacks)
sudo kopi-docka advanced snapshot list

# Test run (no changes)
sudo kopi-docka dry-run

# Full backup
sudo kopi-docka backup

# Create disaster recovery bundle (encrypted ZIP)
sudo kopi-docka disaster-recovery export ~/recovery.zip
# → Store bundle + passphrase off-site: USB/cloud/safe

Usage guide →

Automatic Backups

# Generate systemd units
sudo kopi-docka advanced service write-units

# Enable daily backups (02:00 default)
sudo systemctl enable --now kopi-docka.timer

# Check status
sudo systemctl status kopi-docka.timer

# Or use the interactive management wizard
sudo kopi-docka advanced service manage

Systemd integration →

---

Key Features

1. Compose-Stack-Awareness

Recognizes Docker Compose stacks and backs them up as atomic units with docker-compose.yml included.

Traditional vs. Kopi-Docka:

Traditional:                    Kopi-Docka:
├── wordpress_web_1            Stack: wordpress
├── wordpress_db_1             ├── Containers: web, db, redis
└── wordpress_redis_1          ├── Volumes: wordpress_data, mysql_data
                               ├── docker-compose.yml
❌ Context lost                └── Common backup_id
                               ✅ Complete stack restorable

2. Disaster Recovery Bundles

Single encrypted ZIP files containing repository connection data, configuration, and auto-reconnect scripts:

# Create encrypted ZIP bundle (recommended, v6.2.0+)
sudo kopi-docka disaster-recovery export ~/recovery.zip

# Or stream via SSH (zero disk footprint on server — Linux/macOS clients)
ssh user@server "sudo kopi-docka disaster-recovery export --stream --passphrase 'xxx'" > recovery.zip
# Windows users: use cmd.exe or scp — PowerShell's `>` corrupts the binary stream
# (see Disaster Recovery guide for details)

# In emergency (on new server):
1. Extract ZIP (7-Zip on Windows — built-in Explorer does NOT support AES-256)
2. Run sudo ./recover.sh
3. kopi-docka restore
4. docker compose up -d

Disaster Recovery guide →

3. Tailscale Integration

Automatic peer discovery for P2P backups over WireGuard mesh network:

sudo kopi-docka advanced config new
# → Select Tailscale
# → Shows all devices in your Tailnet
# → Auto-configures SSH keys
# → Direct encrypted connection (no cloud costs)

4. Systemd Integration

Daemon implementation with:

• sd_notify status reporting
• Watchdog monitoring
• Security hardening (ProtectSystem, NoNewPrivileges, etc.)
• PID locking (prevents parallel runs)
• Structured logging to systemd journal

See detailed features →

---

Backup Scopes

Kopi-Docka supports three backup scopes to balance speed, size, and restore capabilities:

Scope Comparison

Scope	What's Backed Up	Restore Capability	Use Case
minimal	✅ Volumes only	⚠️ Data only - containers must be manually recreated	Fastest backups when you always have docker-compose files available
standard	✅ Volumes ✅ Recipes (docker-compose.yml) ✅ Networks (IPAM config)	✅ Full container restore	Recommended - Complete restore capability
full	✅ Volumes ✅ Recipes ✅ Networks ✅ Docker daemon config	✅ Full restore + manual daemon config	Disaster recovery with Docker daemon settings

Detailed Restore Matrix

Scope	Volumes	Container Configs	Networks	Docker Daemon Config
minimal	✅ Restored	❌ Not backed up*	❌ Not backed up	❌ Not backed up
standard	✅ Restored	✅ Restored	✅ Restored	❌ Not backed up
full	✅ Restored	✅ Restored	✅ Restored	⚠️ Manual restore**

Notes:

• * Minimal scope limitation: Only volume data is backed up. After restore, you must manually recreate containers using your original docker-compose.yml files or docker run commands. Networks must also be manually recreated.
• ** Docker config safety: Docker daemon configuration (/etc/docker/daemon.json, systemd overrides) is backed up but not automatically restored. This prevents accidental production breakage. Review and manually apply configuration changes.

Usage Examples

Set default scope in config wizard:

sudo kopi-docka advanced config new
# → Interactive menu will prompt for scope selection
# → Default: standard (recommended)

Set scope in config file:

{
  "backup": {
    "backup_scope": "standard"
  }
}

Override scope via CLI flag:

# Minimal - Fastest, smallest backups (volumes only)
sudo kopi-docka backup --scope minimal

# Standard - Recommended (volumes + recipes + networks)
sudo kopi-docka backup --scope standard

# Full - Complete DR including Docker daemon config
sudo kopi-docka backup --scope full

⚠️ Minimal Scope Warning

If you restore from a minimal scope backup, Kopi-Docka will show a prominent warning:

⚠️  MINIMAL Scope Backup Detected

This backup contains ONLY volume data.
Container recipes (docker-compose files) are NOT included.

After restore:
• Volumes will be restored
• Containers must be recreated manually
• Networks must be recreated manually

Consider using --scope standard or --scope full for complete backups.

Recovery steps for minimal scope backups:

1. sudo kopi-docka restore → Restores volume data
2. Manually recreate containers: docker compose up -d (using your original docker-compose.yml)
3. Manually recreate networks if needed: docker network create ...

🔧 Docker Config Manual Restore

For FULL scope backups, Docker daemon configuration is backed up but requires manual restoration:

Extract docker_config snapshot:

# List docker_config snapshots
sudo kopi-docka list --snapshots | grep docker_config

# Extract configuration to temp directory
sudo kopi-docka show-docker-config <snapshot-id>

What this command does:

• Extracts docker_config snapshot to /tmp/kopia-docker-config-XXXXX/
• Displays safety warnings about manual restore
• Shows extracted files (daemon.json, systemd overrides)
• Displays daemon.json contents inline (if <10KB)
• Provides 6-step manual restore instructions

Why manual restore?

• Docker daemon configuration is extremely sensitive
• Incorrect config can break Docker entirely
• Must be reviewed before applying to production
• Prevents accidental system breakage

Example output:

✓ Extracted files:
   • daemon.json (2.3 KB)
   • docker.service.d/override.conf (0.5 KB)

📄 daemon.json contents:
{
  "log-driver": "json-file",
  "log-opts": {
    "max-size": "10m",
    "max-file": "3"
  }
}

🔧 Manual Restore Instructions
Step 1: Review extracted files
Step 2: Backup current config
Step 3: Apply configuration (CAREFULLY!)
Step 4: Systemd overrides (if present)
Step 5: Restart Docker daemon
Step 6: Verify Docker is working

Scope Selection Guidance

Choose minimal when:

• You need fastest possible backups
• You always have access to original docker-compose files
• You're comfortable manually recreating containers after restore
• Storage space is extremely limited

Choose standard when (RECOMMENDED):

• You want complete restore capability
• You prefer automated container recreation
• You want network configurations preserved
• You need reliable disaster recovery

Choose full when:

• You need complete disaster recovery capability
• You have custom Docker daemon configuration
• You use systemd service overrides for Docker
• You want to preserve all Docker settings

Default: standard (best balance for most users)

---

Documentation

📚 Guides:

• Installation - System requirements, installation options
• Configuration - Wizards, config files, storage backends
• Usage - CLI commands, workflows, how it works
• Features - Detailed feature documentation
• Disaster Recovery - DR bundles, recovery workflow, SSH streaming
• Hooks - Pre/post backup hooks, examples
• Troubleshooting - Common issues, FAQ
• Development - Project structure, contributing
• Architecture - Code-driven architecture overview (authoritative)

📁 Examples:

• examples/config.json - Sample configuration
• examples/docker-compose.yml - Example stack
• examples/hooks/ - Hook script examples
• examples/systemd/ - Systemd setup guide

---

CLI Commands

Kopi-Docka features a simplified CLI with top-level commands and an admin subcommand for advanced operations.

Top-Level Commands

sudo kopi-docka setup              # Complete setup wizard
sudo kopi-docka backup             # Full backup (standard scope)
sudo kopi-docka restore            # Interactive restore wizard
sudo kopi-docka restore --yes      # Non-interactive restore (CI/CD)
sudo kopi-docka show-docker-config <snapshot-id>  # Extract docker_config for manual restore
sudo kopi-docka disaster-recovery export ~/recovery.zip  # Create DR bundle (ZIP)
sudo kopi-docka dry-run            # Simulate backup (preview)
sudo kopi-docka doctor             # System health check
kopi-docka version                 # Show version

Admin Commands

# Configuration
sudo kopi-docka advanced config show      # Show config
sudo kopi-docka advanced config new       # Create new config
sudo kopi-docka advanced config edit      # Edit config

# Repository
sudo kopi-docka advanced repo init        # Initialize repository
sudo kopi-docka advanced repo status      # Repository info

# Snapshots & Units
sudo kopi-docka advanced snapshot list              # List backup units
sudo kopi-docka advanced snapshot list --snapshots  # List all snapshots
sudo kopi-docka advanced snapshot estimate-size     # Estimate backup size
sudo kopi-docka advanced snapshot manage            # Interactive management wizard
sudo kopi-docka advanced snapshot delete <id>       # Delete a snapshot
sudo kopi-docka advanced snapshot pin <id>          # Pin snapshot (protect from cleanup)
sudo kopi-docka advanced snapshot unpin <id>        # Unpin snapshot
sudo kopi-docka advanced snapshot maintenance       # Run maintenance
sudo kopi-docka advanced snapshot prune-empty       # Expire snapshots (apply retention)
sudo kopi-docka advanced snapshot retention show    # Show retention policy
sudo kopi-docka advanced snapshot retention set \
  --latest 10 --daily 7 --weekly 4 --monthly 12    # Update retention policy

# System & Service
sudo kopi-docka advanced system install-deps    # Install dependencies
sudo kopi-docka advanced service write-units    # Generate systemd units
sudo kopi-docka advanced service daemon         # Run as daemon

Complete CLI reference →

---

Storage Backend Options

Kopi-Docka supports 8 different storage backends:

1. Local Filesystem - Local disk or NAS mount
2. AWS S3 - Amazon S3 or S3-compatible (Wasabi, MinIO)
3. Backblaze B2 - ~$6/TB/month (includes egress)
4. Azure Blob - Microsoft Azure storage
5. Google Cloud Storage - GCS
6. SFTP - Remote server via SSH
7. Tailscale - P2P over WireGuard mesh network
8. Rclone - Universal adapter (OneDrive, Dropbox, Google Drive, 70+ services) — ⚠️ slow on Google Drive, see issue #111

Tested Backends

End-to-end backup + restore tested by the author against real storage. Other backends are wired up and unit-tested, but I haven't run a full backup cycle against them myself — community reports welcome.

Backend	Status	Notes
Rclone	✅ tested	Live test lab. Google-Drive remote has known upstream perf limits — #111
Tailscale	✅ tested	NAS-over-tailnet; v7.4.0 + v7.6.1 regressions verified
SFTP	✅ tested	v7.6.1 E2E: wizard → kopia repository create → full kopi-docka backup → snapshot persistence
Local Filesystem	❓ untested	Should work — same code path as the others, no external auth
AWS S3	❓ untested	—
Backblaze B2	❓ untested	—
Azure Blob	❓ untested	—
Google Cloud Storage	❓ untested	—

⚠️ Performance note for rclone + Google Drive users: a known upstream limitation makes individual snapshot operations take 60-300 seconds each (Kopia marks the rclone backend as [Not maintained], Google Drive has high small-file write overhead). If you're seeing 30+ minute backups for a small amount of data, see pinned issue #111 for measurements and recommended alternatives (any of the other 7 backends will be an order of magnitude faster).

Storage configuration →

---

System Requirements

• OS: Linux (Debian, Ubuntu, Arch, Fedora, RHEL/CentOS)
• Python: 3.10 or newer
• Docker: Docker Engine 20.10+
• Kopia: >= 0.13 (recommended; required for sparse-file support) (automatically checked)

Detailed requirements →

---

Feature Comparison

Feature	Kopi-Docka	docker-volume-backup	Duplicati	Restic
Docker-native	✅	✅	❌	❌
Cold Backups	✅	✅	❌	❌
Compose-Stack-Aware	✅	❌	❌	❌
Network Backup*	✅	❌	❌	❌
DR Bundles	✅	❌	❌	❌
Tailscale Integration	✅	❌	❌	❌
Rclone Support	✅	❌	❌	❌
systemd Integration	✅	❌	❌	❌
Pre/Post Hooks	✅	⚠️	❌	❌
Storage Options	8 backends	Basic	Many	Many
Deduplication	✅ (Kopia)	❌	✅	✅

*Network Backup = Automatic backup of custom Docker networks with IPAM configuration (subnets, gateways)

Kopi-Docka's focus: Stack-awareness, disaster recovery bundles, Tailscale P2P, and systemd hardening

Full comparison →

---

Project Status

Status: Feature-Complete, Stabilization Phase
Latest Release: See badges above ↑

The current release includes all planned core features:

• ✅ Backup scope selection (minimal/standard/full)
• ✅ Docker network backup with IPAM
• ✅ Pre/Post backup hooks
• ✅ Disaster recovery bundles
• ✅ Systemd integration with hardening

Current Focus:

• Bug fixing and edge-case handling
• Test coverage expansion
• Documentation improvements

Known Limitations:

• Single repository only (no parallel multi-cloud backup)
• Hooks require careful configuration (Safety Guide)
• Restore edge-cases still being hardened

New major features: Only after stable foundation

View Changelog | Development Roadmap

---

Thanks & Acknowledgments

Kopi-Docka = Kopia + Dockar – the name reflects what this project is: a bridge between two excellent tools.

Kopi-Docka would not exist without these excellent tools:

• Kopia – the rock-solid backup engine providing encryption, deduplication and snapshot management
  https://kopia.io

• Docker – container runtime and ecosystem that makes reproducible environments possible
  https://www.docker.com

• Tailscale – secure WireGuard-based networking that enables simple peer-to-peer offsite backups
  https://tailscale.com

• rclone – universal storage adapter enabling access to many affordable cloud and remote storage providers
  https://rclone.org

• Typer – clean and readable CLI framework for Python https://typer.tiangolo.com

• Pydantic – data validation and settings management using Python type annotations https://docs.pydantic.dev

• Apprise – universal notification library supporting 100+ services https://github.com/caronc/apprise

All of these tools remain under their respective licenses and are not bundled with Kopi-Docka.

This project is built with deep respect for the open-source ecosystem.

Author: Markus F. (TZERO78)
Links: PyPI | GitHub

---

License

MIT License - see LICENSE for details.

Copyright (c) 2025 Markus F. (TZERO78)

---

Feedback & Support

If you find Kopi-Docka useful, feel free to leave a ⭐ on GitHub.

I cannot test all storage backends and edge cases on my own, so feedback from real-world setups is highly appreciated.

If something doesn't work as expected, please open an Issue and include your environment details.

• 📦 PyPI: pypi.org/project/kopi-docka
• 📚 Documentation: Complete docs
• 🐛 Bug Reports: GitHub Issues
• 💬 Discussions: GitHub Discussions
• 🧑‍🤝‍🧑 Code of Conduct: CODE_OF_CONDUCT.md
