lambda-microvm-cdk 0.1.0

Reusable AWS CDK (Python) construct for provisioning AWS Lambda MicroVM images and launchers.

AWS Lambda MicroVM CDK Construct (Python)

A reusable AWS CDK v2 construct (pure Python, 3.11+) for provisioning AWS Lambda MicroVMs — Firecracker-based, VM-isolated, snapshot-fast serverless compute for AI sandboxes, interactive dev environments, and multi-tenant CI. Secure defaults, every AWS knob overridable, plus an escape hatch.

📜 Documentation | Blogs website

Contact details | mailto:[e-mail]

Status: early development (targets a preview AWS API). Repo: lambda-microvm-cdk-python · PyPI: lambda-microvm-cdk.

What it does

LambdaMicroVM is a typed wrapper around the L1 AWS::Lambda::MicrovmImage resource. In one construct it zips your Dockerfile+app, uploads it to S3, creates least-privilege build and VM-execution roles, resolves the managed base-image version, and emits a snapshotted MicroVM image — with secure defaults and an overrides escape hatch for anything not yet modeled.

Running a MicroVM (run / suspend / resume / terminate) is a runtime API call, not CloudFormation — so it's driven with boto3 from your app or the E2E fixture, using the construct's typed properties (image ARN, execution role, connector ARNs, log group). There is no launcher Lambda / API Gateway / WAF — you call the runtime API directly.

Two planes

flowchart LR
    subgraph CFN["Declarative — CloudFormation (this construct)"]
        IMG["AWS::Lambda::MicrovmImage<br/>(LambdaMicroVM)"]
        NC["AWS::Lambda::NetworkConnector<br/>(VPC egress — MicrovmNetworkConnector)"]
    end
    subgraph RT["Runtime API — boto3 (your app / E2E fixture)"]
        RUN["RunMicrovm · Suspend · Resume · Terminate<br/>CreateMicrovmAuthToken"]
    end
    IMG -- "image ARN + exec role<br/>+ connector ARNs (props)" --> RUN

Images and connectors are declarative CDK; the running instance is runtime-only, wired from the construct's outputs.

Quickstart

Install

Add the package to your CDK app (Python 3.11+). aws-cdk-lib, constructs, and the aws-cdk-aws-ec2-alpha module (used by the VPC-egress construct) are pulled in as dependencies.

pip install lambda-microvm-cdk
# or
uv add lambda-microvm-cdk
# or
poetry add lambda-microvm-cdk

Use

from aws_cdk import Stack
from lambda_microvm_cdk import LambdaMicroVM

class MyStack(Stack):
    def __init__(self, scope, id, **kw):
        super().__init__(scope, id, **kw)

        vm = LambdaMicroVM(self, "Agent",
            source="microvm_app",                 # dir with a Dockerfile (also: .zip path or s3_assets.Asset)
            description="headless agent VM",
            memory_mib=2048,                       # tier: 512|1024|2048|4096|8192
            environment={"LOG_LEVEL": "info"},     # NEVER secrets — baked into the snapshot
            # architecture defaults to ARM_64 (only value the service accepts today)
            # enable_logging=True, os_capabilities=[], overrides={} ...
        )

        vm.image_arn          # Fn::GetAtt ImageArn (token)
        vm.execution_role     # least-priv VM execution role (add workload perms on top)
        vm.grant_run(caller)  # attach least-priv RunMicrovm* to a runtime-caller principal

Custom VPC egress (optional)

Route the VM's outbound traffic through your VPC with MicrovmNetworkConnector. It's BYO-VPC — you own the VPC (and whether it has internet egress). Pass the connector straight to egress_connectors=[...]; the security group's rules are the egress policy (deny-all by default).

flowchart LR
    vm["MicroVM<br/>image build + runtime"]

    subgraph vpc["Your VPC — BYO · REJECT flow logs"]
        direction TB
        subgraph priv["Private subnets · PRIVATE_WITH_EGRESS"]
            eni["Connector ENIs<br/>SG = egress policy:<br/>deny-all + allow tcp/443"]
        end
        subgraph pub["Public subnets"]
            nat["NAT Gateway + EIP"]
        end
        igw["Internet Gateway"]
    end

    net(("Internet<br/>public.ecr.aws · PyPI · Bedrock"))

    vm -->|"outbound via connector"| eni
    eni -->|"0.0.0.0/0 → NAT"| nat
    nat -->|"0.0.0.0/0 → IGW"| igw
    igw <--> net

The security group is the only egress gate (deny-all + explicit allows, stateful); the NAT gateway has no rules — it just gives the private subnets a path to the internet. Full architecture + fully-private (no-NAT) option: Custom Egress docs.

Build-time vs run-time egress. egress_connectors is the image build's egress — the build runs your Dockerfile in a MicroVM, so the VPC must reach your base image + package repos (a NAT gateway, or private mirrors). A locked-down VPC with no route to those fails the build. For VPC egress only at runtime, leave egress_connectors empty and pass the connector to run_microvm instead.

import aws_cdk.aws_ec2 as ec2
from lambda_microvm_cdk import LambdaMicroVM, MicrovmNetworkConnector

# BYO VPC with a NAT gateway so the image build can reach public.ecr.aws + PyPI.
vpc = ec2.Vpc(self, "Vpc", max_azs=2, nat_gateways=1)  # or an aws_ec2_alpha.VpcV2 — see sample/

connector = MicrovmNetworkConnector(
    self,
    "Egress",
    vpc=vpc,  # deny-all egress SG by default
)
connector.security_group.add_egress_rule(
    ec2.Peer.any_ipv4(),
    ec2.Port.tcp(443),
    "HTTPS egress",
)
vm = LambdaMicroVM(
    self,
    "Agent",
    source="microvm_app",
    egress_connectors=[connector],  # accepts the connector object or a raw ARN string
)

See sample/sample_stack.py for a full VpcV2 + NAT-gateway example.

Build & run flow

sequenceDiagram
    participant Dev
    participant CDK as CDK / CloudFormation
    participant Svc as Lambda MicroVM service
    participant App as your app / E2E fixture (boto3)
    Dev->>CDK: cdk deploy (LambdaMicroVM)
    CDK->>Svc: create MicrovmImage (S3 artifact + base image)
    Svc-->>CDK: image CREATING -> CREATED (snapshot)
    App->>Svc: RunMicrovm(imageArn, executionRoleArn, connectors, maxDuration)
    Svc-->>App: microvmId, endpoint (PENDING -> RUNNING)
    App->>Svc: CreateMicrovmAuthToken(allowedPorts=[{port:8080}])
    App->>App: HTTPS request (X-aws-proxy-auth) -> assert
    App->>Svc: TerminateMicrovm (guaranteed in teardown)

Sample app

sample/ is a deployable CDK app whose MicroVM runs a model worker on Amazon Bedrock (us-east-1) — Amazon Nova 2 Lite by default (boto3 Converse), with Claude Opus 4.8 opt-in (MODEL_PROVIDER=anthropic). The worker is tiered so the deterministic gate never depends on the model. The E2E suite runs two tests against one VM:

1. echo — deterministic, no model. The E2E gate.
2. bedrock — one model call (Nova default / Opus opt-in); the E2E test asks the model to sum two random numbers and asserts the reply contains the sum.
3. agent — Claude Code headless (opt-in enhancement, not exercised by the E2E tests).

Local development

For working on the construct itself (not just consuming it). Uses uv, ruff, and the AWS CDK CLI via npx (see the Makefile).

make dev        # uv sync (venv + dev deps)
make lint       # ruff format --check + ruff check + mypy
make unit       # unit tests (no AWS; boto3 mocked)
make synth      # npx aws-cdk synth the sample app (runs cdk-nag)

CI/CD and the docs pipeline are described in docs/pipeline.md.

Code contributions

Contributions are welcome — please open an issue or PR. PR titles follow the feature | fix | docs | chore convention (validated in CI).

Connect

• Website: www.ranthebuilder.cloud
• Blog: ranthebuilder.cloud/blog
• X (Twitter): @RanBuilder
• Email: [e-mail]

License

This library is licensed under the MIT-0 License. See the LICENSE file.
