langgraph-declarative 0.2.0

Declarative YAML workflow definitions for LangGraph — topology as config, logic in Python

Topology in YAML. Logic in Python. One line to compile.

Quickstart · Features · YAML reference · Examples · Roadmap

---

Describe a LangGraph workflow's structure in YAML, keep the behaviour in Python, and compile the two into a standard CompiledStateGraph. Nothing about how you run, stream, or deploy the graph changes.

[!TIP] Topology changes become config edits, not code rewrites. Workflow structure can be diffed in review, validated in your IDE, rendered as a diagram, stored and versioned in a database, and read by people who don't write Python.

Install

pip install langgraph-declarative                 # uv add langgraph-declarative
pip install "langgraph-declarative[anthropic]"    # optional: llm: support ([openai] too)

Quickstart

1. Register your functions.

from langgraph_declarative import Registry, build_graph

registry = Registry()

@registry.node("greet")
def greet(state):
    return {"messages": [{"role": "assistant", "content": "Hello! How can I help?"}]}

@registry.node("respond")
def respond(state):
    return {"messages": [{"role": "assistant", "content": "Goodbye!"}]}

2. Declare the graph.

# workflow.yaml
nodes:
  - name: "greeter"
    function: "greet"
  - name: "responder"
    function: "respond"

edges:
  - source: "START"
    target: "greeter"
  - source: "greeter"
    target: "responder"
  - source: "responder"
    target: "END"

3. Build and run.

graph = build_graph("workflow.yaml", registry)
result = graph.invoke({"messages": [{"role": "user", "content": "Hi there"}]})

That's the whole surface area. build_graph() validates the YAML with Pydantic, cross-checks every function: and path: against the registry, and hands you a compiled LangGraph.

[!TIP] Every feature below has a commented, runnable example — see examples/.

How it fits together

flowchart LR
    Y["workflow.yaml<br/><i>or a DB row</i>"] --> V["Schema validation<br/><i>Pydantic</i>"]
    R["@registry.node<br/>@registry.router<br/>@registry.tool"] --> V
    V --> B["GraphBuilder"]
    B --> G["CompiledStateGraph<br/><i>.invoke() · .stream() · langgraph dev</i>"]

Three pieces: a registry of Python functions, a definition of the topology, and a builder that joins them. Validation happens before compilation, so a typo in the YAML gives you Unknown node function 'classfy'. Did you mean 'classify'? — not a stack trace at runtime.

Features

Feature	YAML	Since	Example
Simple & parallel edges	target: "node" / target: [a, b]	v1	quickstart, fan_out
Conditional routing	path: + targets:	v1	conditional_routing
Dynamic fan-out (Send)	path: without targets	v1	dynamic_routing
Custom Python state class	build_graph(..., state_class=...)	v1	custom_state
State declared in YAML	state: with types & reducers	v1.1	declared_state
Match routing (no router fn)	match: + targets:	v1.1	match_routing
Mermaid diagrams	draw_mermaid()	v1.1	visualization
IDE autocomplete & validation	workflow.schema.json	v1.1	visualization
Subgraph composition	subgraph: "child.yaml"	v2	subgraph
Cross-file node imports	imports:	v2	cross_file_imports
LLM config & tool binding	llm: + tools:	v2	llm_and_tools
Database-stored workflows	SQLiteLoader, build_graph_from_db()	v2	db_workflow
LangGraph project template	—	v2	template/

[!NOTE] v1 / v1.1 / v2 are milestone labels, not package versions. All three have shipped — see CHANGELOG.md for releases.

YAML reference

Only nodes is required. The simplest workflow is a list of nodes and edges.

Full schema — state, llm, imports, nodes, edges

state:                              # declare the state schema (default: MessagesState)
  - name: "category"
    type: "str"                     # str | int | float | bool | list | dict | list[str] | list[dict]
  - name: "notes"
    type: "list[str]"
    reducer: "append"               # append | add_messages | replace (default)

llm:                                # graph-level LLM default for opt-in nodes
  provider: "anthropic"             # anthropic | openai
  model: "claude-opus-4-8"

imports:                            # merge node declarations from other files
  - file: "shared_nodes.yaml"
    nodes: ["error_handler"]        # omit to import all nodes

nodes:
  - name: "classifier"
    function: "classify"            # registered via @registry.node()
  - name: "research"
    subgraph: "child.yaml"          # embed another workflow (function XOR subgraph)
  - name: "agent"
    function: "agent_fn"            # function must accept an `llm` parameter to opt in
    llm: { model: "claude-haiku-4-5" }  # node-level override, merged over graph llm
    tools: ["get_weather"]          # @registry.tool() names or "module.path:attr"

edges:
  - source: "START"                 # START, END, or a node name
    target: "classifier"            # simple edge
  - source: "loader"
    target: ["a", "b"]              # parallel fan-out
  - source: "classifier"
    path: "router_name"             # @registry.router(); omit targets for Send routing
    targets: { key: "node" }
  - source: "classifier"
    match: "category"               # route on a state field's value — no Python router
    targets:
      billing: "billing_agent"
      default: "fallback"           # reserved fallback key

[!TIP] Add this as the first line of any workflow file for autocomplete and inline validation in VS Code, JetBrains, and Neovim:

# yaml-language-server: $schema=path/to/workflow.schema.json

The schema ships at schema/workflow.schema.json, or regenerate it with export_json_schema().

API

Function / Class	Description
Registry()	Holds node, router, and tool functions in separate namespaces
@registry.node("name")	Register a node function (transforms state)
@registry.router("name")	Register a router (returns a routing key or a list of Send)
@registry.tool("name")	Register a tool for tools: binding
build_graph(path, registry, state_class=None)	YAML file → compiled CompiledStateGraph
build_graph_from_db(source, registry, db_path)	DB-stored definition → compiled graph ("flow" or "flow@2")
draw_mermaid(path, registry, output_path=None)	Compile and render a Mermaid diagram (.md → fenced block)
export_json_schema(output_path=None)	Emit the JSON Schema for workflow YAML files
GraphBuilder(registry, state_class=None)	Power-user class behind build_graph()
SQLiteLoader(db_path)	Save/load versioned definitions; implements the pluggable Loader protocol

Documentation

Document	Contents
examples/	12 runnable examples, one per feature, organized by milestone
template/	Starter project for langgraph dev using the declarative pattern
ROADMAP.md	What shipped per milestone, and unvalidated future ideas
CHANGELOG.md	Release history
DECISIONS.md	Why the API and the scope look the way they do
docs/02-requirements/REQUIREMENTS.md	Problem, users, success criteria
docs/03-design/DESIGN.md	Architecture, module responsibilities, trade-offs

Project layout

src/langgraph_declarative/   # library (registry, schema, builder, state/llm factories, loaders)
schema/                      # generated JSON Schema for workflow YAML
examples/                    # runnable examples — one folder per feature
template/                    # LangGraph starter template
tests/                       # pytest suite + YAML fixtures
docs/                        # requirements, design, roadmap, reviews

Requirements

• Python 3.10+
• LangGraph ≥ 0.2 · PyYAML ≥ 6.0 · Pydantic ≥ 2.0
• Optional: [anthropic] / [openai] extras for llm: support

Contributing

Issues and pull requests welcome. Run the suite with uv run pytest before opening a PR.

License

MIT. Community project — not affiliated with or endorsed by LangChain. Built on top of LangGraph.
