langgraph-xai

Explainability for LangGraph applications: what ran, why it was decided, and what each audience may see.

langgraph-xai wraps a compiled LangGraph graph and records every run as structured, versioned records. Nodes, state changes, tools, retrievers, and human-in-the-loop interrupts are captured automatically. Your code records the evidence it relied on and the decisions it made. From those records it builds explanations for developers, auditors, business owners, or end users, filtered by a disclosure policy you control.

Features

• Drop-in instrumentation. xai.instrument(graph) records invoke, stream, batch, astream_events, and the other Runnable entry points, sync and async, without changing inputs, outputs, or exceptions. It works with StateGraph, the functional API, create_agent, deepagents, subgraphs, and MCP tools.
• Human-in-the-loop aware. Interrupts and resumes are recorded with the reviewer's answer. For a graph with a checkpointer, each run is linked to its checkpoints, and a resumed run points back to the run it continues, even across processes.
• Evidence, decisions, and provenance as data. Explanations are built from recorded facts, never from model reasoning.
• Audience-aware explanations. Attribution shows how much each factor and piece of evidence contributed. A per-audience policy decides what each reader sees, and withheld sections are announced.
• Safe by default. Credentials are redacted before anything is stored, explanations fail closed, LLM phrasing needs two explicit opt-ins, and instrumentation failures never break your graph unless you ask them to.
• Pluggable. Records are kept in memory by default. Subclass ProvenanceStore for your database; a complete PostgreSQL store is included as an example. Events can be forwarded to LangSmith, Langfuse, or any OpenTelemetry backend.

Install

pip install langgraph-xai

Requires Python 3.12+, LangGraph 1.x (1.2.12 or newer), and LangChain Core 1.x (1.6.6 or newer). Integrations are optional extras:

pip install "langgraph-xai[langsmith]"   # LangSmithObservability
pip install "langgraph-xai[langfuse]"    # LangfuseObservability
pip install "langgraph-xai[otel]"        # OpenTelemetryObservability
pip install "langgraph-xai[llm-openai]"  # LLM-phrased explanations with langchain-openai

Quickstart

import asyncio
from typing import TypedDict

from langgraph.graph import END, START, StateGraph

from langgraph_xai import Audience, DecisionType, EvidenceType, XAIRuntime

xai = XAIRuntime(application_id="payments", tenant_id="acme-bank", graph_id="fraud-review")


class Review(TypedDict, total=False):
    amount: float
    risk_score: float
    route: str


async def score_risk(state: Review) -> Review:
    risk_score = 0.91 if state["amount"] > 5000 else 0.12
    await xai.record_evidence(
        EvidenceType.TOOL_RESULT,
        summary=f"Fraud model scored the transaction {risk_score:.2f}.",
        confidence=0.97,
    )
    return {"risk_score": risk_score}


async def route(state: Review) -> Review:
    run = xai.current_run  # the run of the instrumented call executing this node
    assert run is not None
    selected = "HUMAN_REVIEW" if state["risk_score"] >= 0.8 else "AUTO_APPROVE"
    await xai.record_decision(
        selected,
        decision_type=DecisionType.ROUTING,
        candidate_actions=["AUTO_APPROVE", "HUMAN_REVIEW"],
        evidence_ids=[item.id for item in run.evidence],
        confidence=0.93,
    )
    return {"route": selected}


builder = StateGraph(Review)
builder.add_node("score_risk", score_risk)
builder.add_node("route", route)
builder.add_edge(START, "score_risk")
builder.add_edge("score_risk", "route")
builder.add_edge("route", END)
graph = xai.instrument(builder.compile())


async def main() -> None:
    with xai.collect_runs() as runs:
        result = await graph.ainvoke({"amount": 9200.0})
    (run,) = runs

    print(result)
    print([f"{node.node_id}: {node.status}" for node in run.execution.nodes])

    explanation = await xai.explain_decision(run.decisions[0], audience=Audience.AUDITOR, run=run)
    print(explanation.summary)
    print(explanation.reasons)


asyncio.run(main())

Output:

{'amount': 9200.0, 'risk_score': 0.91, 'route': 'HUMAN_REVIEW'}
['score_risk: completed', 'route: completed']
The routing decision selected 'HUMAN_REVIEW'.
['Selected action: HUMAN_REVIEW.', 'Alternatives considered: AUTO_APPROVE.', 'Decision confidence: 0.93.']

The fraud review example goes further: it explains one decision to an auditor, with attribution and evidence, and to a customer, with internal scores withheld and the withholding disclosed.

How it relates to tracing

LangSmith, Langfuse, and OpenTelemetry show what ran: run trees, spans, latency, tokens. langgraph-xai records why it was decided and who may see the explanation. The two work together, and the bundled adapters send langgraph-xai events to the tracing backend you already use.

Documentation

Full documentation: langgraph-xai.readthedocs.io

• Quickstart
• Concepts
• How-to guides
• Examples
• API reference

langgraph-xai 1.x follows semantic versioning: minor releases add features without breaking your code or your stored records. Changes are listed in the changelog.

An Agent Skill teaches coding agents such as Claude Code, Codex, Cursor, and GitHub Copilot to integrate langgraph-xai correctly.

Contributing

Contributions are welcome. See CONTRIBUTING.md for the development setup and checks, and SECURITY.md to report a vulnerability.

License

Apache License 2.0. See LICENSE.
