lcgp 1.1.1

Test suite

A list of basic tests is provided for user to verify that LCGP is installed correctly. Execute the follow code within the root directory:

$ python
>>> import lcgp
>>> lcgp.__version__
<version string>
>>> lcgp.test()

What most of us need:

import numpy as np
from lcgp import LCGP
from lcgp import evaluation  # optional evaluation module

# Generate fifty 2-dimensional input and 4-dimensional output
x = np.random.randn(50, 2)
y = np.random.randn(4, 50)

# Define LCGP model
model = LCGP(y=y, x=x)

# Estimate error covariance and hyperparameters
model.fit()

# Prediction
p = model.predict(x0=x)  # mean and variance
rmse = evaluation.rmse(y, p[0].numpy())
dss = evaluation.dss(y, p[0].numpy(), p[1].numpy(), use_diag=True)
print('Root mean squared error: {:.3E}'.format(rmse))
print('Dawid-Sebastiani score: {:.3f}'.format(dss))

# Access parameters
print(model)

Specifying number of latent components

There are two ways to specify the number of latent components by passing one of the following arguments in initializing an LCGP instance:

• q = 5: Five latent components will be used. q must be less than or equal to the output dimension.

• var_threshold = 0.99: Include \(q\) latent components such that 99% of the output variance are explained, using a singular value decomposition.

Note: Only one of the options should be provided at a time.

model_q = LCGP(y=y, x=x, q=5)
model_var = LCGP(y=y, x=x, var_threshold=0.99)

Specifying diagonal error groupings

If errors of multiple output dimensions are expected to be similar, the error variances can be grouped in estimation.

For example, the 6-dimensional output is split into two groups: the first two have low errors and the remaining four have high errors.

import numpy as np

x = np.linspace(0, 1, 100)
y = np.row_stack((
    np.sin(x), np.cos(x), np.tan(x),
    np.sin(x/2), np.cos(x/2), np.tan(x/2)
))

y[:2] += np.random.normal(2, 1e-3, size=(2, 100))
y[2:] += np.random.normal(-2, 1e-1, size=(4, 100))

Then, LCGP can be defined with the argument diag_error_structure as a list of output dimensions to group. The following code groups the first 2 and the remaining 4 output dimensions.

model_diag = LCGP(y=y, x=x, diag_error_structure=[2, 4])

By default, LCGP assigns a separate error variance to each dimension, equivalent to

model_diag = LCGP(y=y, x=x, diag_error_structure=[1]*6)

Define LCGP using different submethod

The main and recommended method under LCGP is the Full posterior (full) method. The method takes into account the uncertainty propagated to the latent components and integrates out the latent components.

Under circumstances where the simulation outputs are stochastic, the full posterior approach or the replication method (rep) should perform most effectively. The replication method is recommended when the simulation outputs contain replicated inputs.

LCGP_models = []
submethods = ['full', 'rep']
for submethod in submethods:
    model = LCGP(y=y, x=x, submethod=submethod)
    LCGP_models.append(model)

Standardization choices

LCGP standardizes the simulation output by each dimension to facilitate hyperparameter training. The two choices are implemented through robust_mean = True or robust_mean = False.

• robust_mean = False: The empirical mean and standard deviation are used.

• robust_mean = True: The empirical median and median absolute error are used.

model = LCGP(y=y, x=x, robust_mean=False)
