lexograph

Spatialize linear text into pictures you can read — in pure Python, rendered with matplotlib.

lexograph is the visualization member of the corpus-lx family (alongside chronowords, kenon, and keyflux). It turns a text into a picture through one four-step spine — segment → layout → encode → render — and ships several presets that are each just a point on that spine:

• Punctuation spiral — every non-alphanumeric mark, in order, along an Archimedean spiral, coloured by symbol class.
• Text walk (2-D / 3-D) — each sentence steps forward and turns 90°, space-filling; size, colour, and glyph encode per-unit attributes. The 3-D variant lifts the walk into a corkscrew.
• Recurrence dotplot — the only preset that plots a text against itself: a sentence × sentence self-similarity grid that exposes internal echo structure.
• Concordance — a term's dispersion across the text (and across texts/time), with optional KWIC.

Every preset returns a matplotlib Figure and never calls show(), so it renders inline in Jupyter and saves cleanly with fig.savefig(...). The core is headless and dependency-light; heavy analysis (sentence embeddings, graph centrality, communities) lives behind an optional [graph] extra.

Installation

uv add lexograph

The core depends only on numpy, matplotlib, and nltk.

Quickstart

from lexograph import (
    load_demo_text, punctuation_spiral, text_walk, recurrence_plot, concordance,
)

text = load_demo_text()  # Chapter 1 of Pride and Prejudice (public domain)

punctuation_spiral(text)                              # marks on an Archimedean spiral
text_walk(text)                                      # the 2-D space-filling walk
text_walk(text, helix=True, z_step=4.0)              # the 3-D corkscrew
recurrence_plot(text)                                # the text against itself
concordance(text, ["Bennet", "Bingley", "wife"])    # term dispersion

Every call returns a matplotlib Figure. For PageRank-sized, community-coloured, or semantically-recurrent figures, install the [graph] extra and feed lexograph.analyze.analyze_text's arrays into any preset.

The data contract

Every visual channel is fed by a plain per-unit array — a scalar array for size, an array of labels or values for colour, an optional glyph/font. Nothing in the core knows where those numbers came from, so you can drive a spiral or a walk from length, frequency, or your own column with no analysis stack at all. The optional analyze layer and the [kenon] / [chronowords] integrations only produce arrays that satisfy this contract.

Documentation

Full documentation — quickstart, a tutorial per preset, troubleshooting, and the API reference — is at lexograph.readthedocs.io. The sources live in docs/.

Roadmap

Open modelling and packaging decisions are analysed in CHANGES_SUMMARY.md, and the failure modes in PRE-MORTEM.md. The main not-yet-built pieces:

• Vendor the four OFL/Apache handwriting fonts so the handwriting walk works out of the box (the width-step already runs on any TTF).
• integrations/ — thin [kenon] and [chronowords] adapters over the data contract.
• Optional interactive HTML/WebGL export (render/html.py), ported from the source viewers and gated behind a stretch extra.
• A space-filling / non-self-overlapping turn rule for very uniform texts.

Made by

lexograph is made by Crow Intelligence.

License

MIT
