logik 0.1.0

Logik is a light weight FPGA tool chain based on mature open source technologies.

---

Logik is an open source FPGA tool chain with support for high level language parsing, synthesis, placement, routing, bit-stream generation, and analysis. Users enter design sources, constraints, and compile options through a simple SiliconCompiler Python API. Once setup is complete, automated compilation can be initiated with a single line run command.

Logik depends on the Logiklib which contains the architecture descriptions and device setup files needed to drive the Logik flow.

Logik supports most of the features you would expect in a commercial proprietary FPGA tool chain.

Feature	Status
Design languages	SystemVerilog, Verilog, VHDL
ALU synthesis	Supported
RAM synthesis	Supported
Timing constraints (SDC)	Supported
Pin Constraints (PCF)	Supported
Bitstream generation	Supported
IP management	Supported
Remote compilation	Supported
Multi-clock designs	Supported
Supported devices	Logiklib devices

Getting Started

The Logik tool chain is available through PyPi and can be installed using pip.

python -m pip install --upgrade logik

All open source FPGA pre-requisites can be installed via the SiliconCompiler sc-install utility.

sc-install -group fpga

The following example illustrate some essential Logik features. For complete documentation of all options available, see the SiliconCompiler project.

from siliconcompiler import Chip
from logik.flows import logik_flow
from logiklib.demo.K4_N8_6x6 import K4_N8_6x6


def hello_adder():

    # Create compilation object
    chip = Chip('adder')
    chip.create_cmdline(switchlist=['-remote'])

    # Specify design sources
    chip.input('adder.v')

    # Specify pin constraints
    chip.input('adder.pcf')

    # Compiler options
    chip.set('option', 'quiet', True)

    # Select target fpga
    chip.set('fpga', 'partname', 'K4_N8_6x6')

    # Load target settings
    chip.set('option', 'flow', 'logik_flow')
    chip.use(logik_flow)
    chip.use(K4_N8_6x6)

    # Run compiler
    chip.run()

    # Display compiler results
    chip.summary()

if __name__ == "__main__":
    hello_adder()

Examples

• Ethernet: Ethernet MAC compiled for z1000 architecture
• Adder: Small adder example compiled for a virtual VPR architecture.

Documentation

• Logik Documentation
• SiliconCompiler Documentation

Installation

Logik is available as wheel packages on PyPI for macOS, Windows and Linux platforms. For a Python 3.8-3.12 environment, just use pip to install.

python -m pip install --upgrade logik

Running natively on your local machine will require installing a number of prerequisites:

• Silicon Compiler: Hardware compiler framework
• Slang: SystemVerilog Parser
• GHDL: VHDL parser
• Yosys: Logic synthesis
• VPR: FPGA place and route
• FASM: FPGA assembly parser and generator

We recommend using the SiliconCompiler sc-install utility to automatically install the correct versions of all open source FPGA tool dependencies.

sc-install -group fpga

Detailed installation instructions can be found in the SiliconCompiler Installation Guide.

License

Apache License 2.0

Issues / Bugs

We use GitHub Issues for tracking requests and bugs.
